TRB-6P /TRB-5P
This document is printed on chlorine free (ECF) paper with soy ink.
EG
011512
ELECTRIC BASS
SERVICE MANUAL
TRB-6P
CONTENTS
..................................................................... 10
TRB-5P
............................................... 2
............................................. 6
............................................. 8
.................................................... 9
.................................................. 10
HAMAMATSU, JAPAN
0.79K-792
Printed in Japan '00.04
Advertisement
Related Manuals for Yamaha TRB-6PII
Summary of Contents for Yamaha TRB-6PII
-
Page 1: Table Of Contents
ELECTRIC BASS TRB-6P /TRB-5P SERVICE MANUAL TRB-6P TRB-5P CONTENTS OVERALL ASSEMBLY ..........2 ELECTRICAL PARTS ..........6 CIRCUIT BOARD ..........8 CIRCUIT DIAGRAM ............ 9 WIRING ..............10 This document is printed on chlorine free (ECF) paper with soy ink. SPECIFICATIONS .......... -
Page 2: Overall Assembly
TRB-6P /TRB-5P OVERALL ASSEMBLY TRB-6P Bridge Assembly Jack Assembly F08aa F08ac F08ab F08a F02 F04 E26 E27 BALANCE: 20KB EQUALIZER BASS: 50KW EQUALIZER MID: 50KW EQUALIZER TREBLE: 50KW PIEZO MIX: 20KB VOLUME: 5KA... - Page 3 TRB-6P /TRB-5P TRB-6P PART NO. DESCRIPTION REMARKS REF NO. RANK OVERALL ASSEMBLY TRB-6PII Body QC028300 Tuning Machine Assembly GB70L+GB7 (GOLD) Tuning Machine Assembly GB70+GB7 (GOLD) QC028400 03704070 Round Head Wood Screw 2.4X10 (GOLD) QC428100 51mm QC442900 Bridge Assembly BPZ-7 (GOLD)
- Page 4 TRB-6P /TRB-5P OVERALL ASSEMBLY TRB-5P Bridge Assembly Jack Assembly F08aa F08ac F08ab F08a F02 F04 E26 E27 BALANCE: 20KB EQUALIZER BASS: 50KW EQUALIZER MID: 50KW EQUALIZER TREBLE: 50KW PIEZO MIX: 20KB VOLUME: 5KA...
- Page 5 TRB-6P /TRB-5P TRB-5P PART NO. DESCRIPTION REMARKS REF NO. RANK OVERALL ASSEMBLY TRB-5PII Body QC028300 Tuning Machine Assembly GB70L+GB7 (GOLD) Tuning Machine Assembly GB70+GB7 (GOLD) QC028400 03704070 Round Head Wood Screw 2.4X10 (GOLD) QC428000 43mm QC442900 Bridge Assembly BPZ-7 (GOLD) QC443000 Flat Head Tapping Screw 3.5X30 (GOLD)
-
Page 6: Electrical Parts
TRB-6P /TRB-5P ELECTRICAL PARTS PART NO. DESCRIPTION REMARKS REF NO. RANK ELECTRICAL PARTS TRB-6PII/TRB-5PII QC558600 Electrical Unit (1) 3-BAND EQ. (QC55840) QC434900 Hexagonal Nut Wire XH 2P L=150 Tantalum Capacitor 0.1uF/16V FP355100 FP355100 Tantalum Capacitor 0.1uF/16V FX804200 Electlytic Cap. 22u/16V R3A-16V220 FX804200 Electlytic Cap. - Page 7 TRB-6P /TRB-5P PART NO. DESCRIPTION REMARKS REF NO. RANK HF557470 Carbon Resistor 47K 1/6W J HF557150 Carbon Resistor 15K 1/6W J HF557330 Carbon Resistor 33K 1/6W J HF557270 Carbon Resistor 27K 1/6W J Carbon Resistor 47K 1/6W J HF557470 HF557470 Carbon Resistor 47K 1/6W J HF557330...
-
Page 8: Circuit Board
TRB-6P /TRB-5P CIRCUIT BOARD BASS TREB PIEZO PICKUP PIEZO MIX BALANCE Battery 9V OUTPUT jack NECK BRIDGE PICKUP PICKUP VOLUME REAR PICKUP FRONT PICKUP Component side Pattern side EPB-QC55840... -
Page 9: Circuit Diagram
TRB-6P /TRB-5P CIRCUIT DIAGRAM... -
Page 10: Wiring
Neck Thickness ......1-F 20.7 mm, 12-F 25.7 mm PAR TS Hardware ........Gold Nut ..........Bone Bridge ........BPZ-7 (Gold) Strings ........YAMAHA H6010 CONTROLS Volume ........5KA x 1 Balance ........20KB x 1 Piezo Volume ......20KB x 1 Equalizer ........ - Page 11 Neck Thickness ......1-F 20.7 mm, 12-F 25.7 mm PAR TS Hardware ........Gold Nut ..........Bone Bridge ........BPZ-7 (Gold) Strings ........YAMAHA H4050 CONTROLS Volume ........5KA x 1 Balance ........20KB x 1 Piezo Volume ......20KB x 1 Equalizer ........
