Component Locations; Wiring Diagram - Linear Access AK-31 Installation And Programming Instructions

COMPONENT LOCATIONS

RED/GREEN
POWER/ACCESS
INDICATOR
KEYPAD

WIRING DIAGRAM

POWER
SUPPLY
ELECTRIC
DOOR
STRIKE
TO ALARM
ALARM
SYSTEM
CONTACT
REQUIRED WIRING
NOTES:
1. ALARM SHUNT SET FOR AUXILIARY RELAY
OPTIONAL WIRING 2. GRAY WIRE SET FOR DOOR SENSE
OTHER WIRING
YELLOW
"LOCKOUT"
INDICATOR
1
4 5 6
7 8 9
0
Figure 1. Component Locations
TYPICAL DOOR INSTALLATION WIRING
AK-31 TERMINALS
TERMINAL
BLOCK 1
1 - AC OR DC
2 - AC OR DC
3 - N.O.
MAIN RELAY
5 AMPS @
4 - COM
28 VDC MAX.
5 - N.C.
6 - N.O.
AUXILIARY
RELAY 1 AMP
7 - COM
@ 28 VDC MAX.
8 - N.C.
Figure 2. Wiring Diagram
MASTER CODE
RESET JUMPER
(P5)
TERMINAL
BLOCK #1
(TB1)
MOUNTING
PLATE
WIRES
12-24 VOLT
SENSE - 8
AC OR DC
GROUND - 7
POWER
REQUEST-TO-EXIT - 6
GROUND - 5
GROUND - 4
OUTPUT #3 - 3
OUTPUT #4 - 2
GROUND - 1
BEEPER
LEVEL
JUMPER (P4)
GRAY
BLACK
VIOLET
BLACK
BLACK
BLUE
AUXILIARY
GREEN
OUTPUTS
100 mA MAX.
BLACK
TO COMMON
CAUTION
IF THE UNIT IS AC POWERED,
MAKE SURE THE SECONDARY OF THE
SYSTEM TRANSFORMER IS ISOLATED
FROM EARTH GROUND
N.C. DOOR
SWITCH
REQUEST
TO EXIT
BUTTON
GROUND
STAKE
1
