KK-E160 Operating Instructions
Radio design :
1. LCD Display
2. Reset
3. M -
4. Key Lock
5. Night Light
6. M +
7. Scan / AL. On/Off
9. Memory
10. Up
Battery Installation :
1.
Please install 2AA batteries.
2.
Please replace batteries if the volume is too low.
3.
Please replace your batteries within 30 seconds, otherwise all memory will be lost.
Radio Reception :
11. Power / Sleep
12. Band/ Mode
13. Down
14. Antenna -
15. Supporting Rack
16. Hand strap
17. Earphone
18. D.C. Jack
19. Battery Compartment
Advertisement
Table of Contents
Related Manuals for kchibo KK-E160
Summary of Contents for kchibo KK-E160
- Page 1 KK-E160 Operating Instructions Radio design : 1. LCD Display 11. Power / Sleep 2. Reset 12. Band/ Mode 3. M - 13. Down 4. Key Lock 14. Antenna - 5. Night Light 15. Supporting Rack 6. M + 16. Hand strap 7.
- Page 2 Power On/Off Press the Power (11) button to turn on or off the radio. Volume Control Rotate the Volume Tuning knob (8) to adjust the volume. Band Selection: Under the radio mode, press the Band button (12) to switch between FM, MW and SW. Frequency Step : FM : 0.1MHz MW : 9KHz...
- Page 3 Under the radio mode, press the Band (12) button to select the band. Press the M+ (6) or M-(3) to select the stored channel. Use of Antenna : AM : The built-in magnetic antenna inside the radio is used. Rotate body to get best reception. FM : Extend the antenna.
- Page 4 Specifications : Frequency Range FM 87.50 -108 MHz AM 522 - 1611 KHz SW 5.95 – 17.90 MHz Memory preset (30) FM (10), AM(10) , SW(10) Noise Limit Sensitivity FM <= 20dBu AM < = 5mV/m SW <= 40dBu Single Signal Selectivity >=10dB Power : DC 3V or 2 x AA batteries (not included) Speaker : 45mm/8ohm/0.5W Earphone jack : 3.5mm 32ohm...
