KK-S60L Operating Instructions
Radio design :
1. Reset
2. LCD Display
3. Scan/ AL On/Off
4. Key Lock
5. Meter Band
6. 0 ...9
8. Memory
9. Volume +
10. Up
11. Power/Sleep
12. Volume -
Battery Installation :
1.
There is a lithium battery built-in to the radio. Installation not required.
13. Down
14. Band/Time Set
15. Light Sensor
16. Page -
17. Page +
18. Clear
19. Antenna
20. Battery Compartment
21. Supporting Rack
22. Earphone Jack
23. External Power Jack
Advertisement
Table of Contents
Related Manuals for kchibo KK-S60L
Summary of Contents for kchibo KK-S60L
- Page 1 KK-S60L Operating Instructions Radio design : 1. Reset 13. Down 2. LCD Display 14. Band/Time Set 3. Scan/ AL On/Off 15. Light Sensor 4. Key Lock 16. Page - 5. Meter Band 17. Page + 6. 0 ...9 18. Clear 7.
- Page 2 Connect the charger with wall outlet. 2. Connect the charger with the radio. 3. When charging, you will see the battery indicator blinking. 4. When finished, the battery will stop blinking. (It will take around 8 hours to fully charge the battery. Battery will last for around 20 hours for each charge) Power On/Off Short press the Power/Sleep button (11)to turn on the radio.
- Page 3 Manual Search : Press UP (10) or DOWN (13) once at a time until you locate the station. For each time you press, the frequency will increase or decrease by one step. Memory Presets : The radio has 160 pages. Each page can store 10 stations. Total 1600 stations. (FM, SCH, AM , SW –...
- Page 4 Under the radio off mode, press Band/Time Set button (14) three times. The hour digit will blink. Press the UP (10) or DOWN (13) to set the hour. Press the Band/Time Set button (14) four times , the minute digit will blink. Press the UP (10) or DOWN(13) to set the minute.
- Page 5 Memory preset (1600) FM (400), SCH(400) , AM(400), SW (400) Noise Limit Sensitivity FM <= 10uV SCH <= 14uV AM < = 4mV/m SW <= 40dBu Single Signal Selectivity >=10dB Power : DC 5V or built-in lithium battery (3.6V) Speaker : 45mm/4ohm/0.25W Earphone jack : 3.5mm 32ohm Measurement : 110 x 68 x 19mm Weight : 160g (excluding batteries)
