Bowers & Wilkins
To use the AirPlay feature, Zeppelin Air must be
connected to your existing home network (from now
on referred to as 'your home network').
The following procedure will give you a step-by-step
guide to set up the AirPlay feature. This is
accomplished by accessing the Zeppelin Air setup
page using either a MAC or PC. Once accessed you
can then name your Zeppelin Air device and allocate
the home network to be used to provide the
connection.

iOS Device Setup Guide

Before you start please ensure:

You have iTunes® 10.2 or later installed on your
MAC / PC.
You have saved data and closed other programs.
You know the name (also known as SSID) of your
existing home wireless network and any
passwords (also referred to as "network key",
"access code" or "phrase key") required to
access it.
The network name and password must contain
only alphanumeric characters and cannot contain
any special characters (such as
!@£$%^&*()_+':";<>~).
Your wireless network must be operating in
Wireless G only, or Wireless G & N mixed mode.
The recommended wireless security method is
WPA/WPA2 Personal. WPA/WPA2 Enterprise is
not supported.
Your Wi-Fi access point (your hub or router) is
functioning.
Depending on your operating system and browser
the icons and windows may vary from the images
shown in this guide.
If anything goes wrong during this process please
follow the reset instructions at the end of this guide
and try again.
Additional information can be found on the support
pages of the Bowers & Wilkins website -
www.bowers-wilkins.com
Zeppelin Air

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Zeppelin Air and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bowers & Wilkins Zeppelin Air

  • Page 1 Bowers & Wilkins Zeppelin Air iOS Device Setup Guide Before you start please ensure: To use the AirPlay feature, Zeppelin Air must be connected to your existing home network (from now  You have iTunes® 10.2 or later installed on your on referred to as ‘your home network’).
  • Page 2 Unplug every cable from Zeppelin Air, including the power cable. 2. Connect only your power cable. Zeppelin Air will switch on in Standby mode with its indicator showing dim red. 3. Press the power button once. The indicator will blink purple.
  • Page 3 Bowers & Wilkins Zeppelin Air iOS Device Setup Guide 5. Select the Zeppelin Air Setup XXX network. This will disconnect the iPod Touch, iPhone or iPad from the existing network and then connect to the Zeppelin Air. 6. Wait approximately 20 seconds, or until you...
  • Page 4 Device Setup Guide 11. Carefully type your password and press “Join”. When the warning message appears, press “OK”. The light on the Zeppelin Air should change to solid purple. This may take up to 30 seconds. Please be sure that both the network name and password do not contain any special characters (such as !@£$%^&*()_+':";<>~),...
  • Page 5 If anything goes wrong at any stage during this process, you can start again by resetting the Zeppelin Air. To do this, use a paper clip or similar small point and press the reset button located on the back of the device between the USB and Ethernet ports.
