Switching On And Off; Maintenance And Cleaning; Useful Tips - Pro-Ject Audio Systems Xpression II Instructions For Use Manual

Switching on and off

Pressing the power switch (20) alternately starts or stops the motor.
Changing replay speed
To play records at 45 r.p.m. first remove the platter (5). Using the accessory tool provided (3a), hook the belt
(3) over the larger diameter part of the motor pulley (2). Refit the platter. To revert to 33,33 r.p.m. repeat the
proceedings using the smaller step on the pulley.
When the Pro-Ject Speed Box ore the Speed Box SE are used speed change between 33 and 45 r.p.m.
is electronic. There is no need to move the belt manually. For further information see the last page.
*** In addition, 78 r.p.m. is available after fitting a special pulley, which may be purchased as an
optional extra.

Maintenance and cleaning

Your record player requires little or no regular maintenance. Remove dust with a slightly moistened antistatic
cloth. Never use a dry cloth because this will create static electricity which attract more dust! Antistatic
cleaning fluids are available at specialist stores but must be applied sparingly to avoid damage to rubber
parts. It is recommended to fit the needle cover before cleaning or maintenance is carried out to avoid
damage.
If the player is not used over a long period of time the drive belt can be removed to prevent unequal stretching.
Always disconnect the record player from the mains power supply as a precaution before maintenance!

Useful tips

The lid is not only a dust cover but also a resonant structure likely to be excited by, and to pass into the
plinth, the acoustic energy emanating from your loudspeakers during replay. It is therefore recommended
that the lid be removed for optimum sound quality.
The record player should be positioned on a low-resonance surface such as wood or multiple layer ply board
to avoid structural vibrations disturbing replay.
Technical specifications PRO-JECT Xpression II
Nominal speeds
Speed variance
Wow and flutter
Signal to noise
Downforce range
Effective tonearm length
Overhang
Power consumption
Outboard power supply
Dimensions (W x H x D)
Weight
6
© Audio Trade GmbH · Pro-Ject Xpression II · Revision 20.2.06/1.5.06
33,33/45,11 r.p.m.. *** 78 r.p.m. optional
±0,5 %
±0,1 %
-70dB
10 - 30mN
8,6 " (218,5mm)
18,5mm
2W
16V/500mA AC, suitable for your country's mains supply
415 x 118 x 320mm, dust cover open 415 x 365 x 405mm
6,3kg
