CX-402A/402R/402W
FM tuner section
Frequency range (100 kHz space) .................87.5 MHz ~ 108.0 MHz
Usable sensitivity ......................................12.0 dBf (1.1 µV/75 ohms)
50 dB quieting sensitivity ..........................13.5 dBf (1.3 µV/75 ohms)
Signal to Noise ratio (IHF T-200) ................................................75 dB
Selectivity ................................................................................100 dB
Stereo separation (1 kHz) ..........................................................40 dB
AM tuner section
Frequency range (9 kHz space) ..........................531 kHz ~ 1629 kHz
Usable sensitivity.....................................................................27 dBµ
CD Section
Laser Diode .........................................................GaAlAs ( =780 nm)
Digital Filter (D/A)...........................................8 Times Over Sampling
D/A Converter ..............................................................................1 bit
Spindle speed ....................................................500 ~ 200 rpm (CLV)
Wow & Flutter .............................................Below Measurable Limit
Frequency response (±1 dB) ........................................5 Hz ~ 20 kHz
Signal to Noise ratio...................................................................94 dB
Dynamic range...........................................................................94 dB
Stereo separation ......................................................................85 dB
KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice.
KENWOOD CORPORATION
14-6, Dogenzaka 1-chome, Shibuya-ku, Tokyo, 150-8501 Japan
KENWOOD SERVICE CORPORATION
P.O. Box 22745, 2201 East Dominguez Street,
Long Beach, CA90801-5745, U.S.A.
KENWOOD ELECTRONICS CANADA INC.
6070 Kestrel Road, Mississauga, Ontario, Canada L5T 1S8
KENWOOD ELECTRONICS LATIN AMERICA S.A.
P.O. Box 55-2791 Paitilla, Plaza Credicorp Bank Panama,
Piso 9, Oficina 901, Calle 50, Panama, Republic of Panama
KENWOOD ELECTRONICS BRASIL LTDA.
Av. Moema, 170-17˚, Andar-Cobertura "B",
Ed. Maximum Service Center, 04077-020 Moema,
São Paulo-SP-Brasil
KENWOOD ELECTRONICS UK LIMITED
Kenwood House, Dwight Road, Watford,
Herts, WD1 8EB, United Kingdom
KENWOOD ELECTRONICS DEUTSCHLAND GMBH
Rembrücker Str. 15, 63150 Heusenstamm, Germany
KENWOOD ELECTRONICS FRANCE S.A.
13, Boulevard Ney, 75018 Paris, France
KENWOOD ELECTRONICS BELGIUM N.V.
Mechelsesteenweg 418, B-1930 Zaventem, Belgium

SPECIFICATIONS

Audio section
Maximum power output.......................................................40 W x 4
Total harmonic distortion.........................................................0.05 %
Tone action......................................................Bass: ±10 dB (100 Hz)
.......................................................................Treble:±10 dB (10 kHz)
General
Supply voltage...........................................13.2 V DC (negative earth)
Maximum current ......................................................10 A (operating)
.................................................................................2.0 mA (standby)
Dimensions (width x
Weight.......................................................................................1.4 kg
Specifications subject to change without notice.
KENWOOD ELECTRONICS ITALIA S.p.A.
Via G. Sirtori 7/9, 20129 Milano, ltaly
KENWOOD IBÉRICA S.A.
Bolivia, 239-08020 Barcelona, Spain
KENWOOD ELECTRONICS AUSTRALIA PTY. LTD.
(A.C.N. 001 499 074)
16 Giffnock Avenue, Centrecourt Estate, North Ryde,
N.S.W. 2113, Australia
KENWOOD ELECTRONICS (HONG KONG) LTD.
Unit 3712-3724, Level 37, Tower 1, Metroplaza,
223 Hing Fong Road, Kwai Fong, N.T., Hong Kong
KENWOOD ELECTRONICS GULF FZE
P.O.Box 61318, Jebel Ali, Dubai, U.A.E.
KENWOOD ELECTRONICS (THAILAND) CO., LTD.
2019 New Pechburi Road, Bangkapi, Huaykwang,
Bangkok, 10320 Thailand
KENWOOD ELECTRONICS SINGAPORE PTE LTD.
1 Genting Lane, #07-00, Kenwood Building, Singapore 349544
KENWOOD ELECTRONICS (MALAYSIA) SDN BHD
#4.01 Level 4, Wisma Academy Lot 4A, Jalan 19/1,
46300 Petaling Jaya, Selangor Darul Ehsan, Malaysia
length
x
depth) ..................180
x
52
x
155 mm
