CoMPoNENts

1
7
4
eBIkE CoMPoNENts
1. Duo Drive motor
2. Pro ride™ battery
3. information Center Dashboard™
display
4. biosync cadence and gear sensor
4
3
8
6
2
5
5. in-frame charging port
6. battery safety lock
7. DuoDrive Motor quick
disconnect location
8. Dual hydraulic disc brake levers
16
9
14
15
BICYCLE CoMPoNENts
9. rear rack mount
10. suspension forks
11. front tire quick release
12. Chain stay and crank
13. bottom bracket
17
16
10
15
12
11
13
14. rear derailleur
15. Drop outs
16. reflectors X 2
17. Head set
5
