Blackout Mode
Blackout mode lets you turn off ALL light output regardless of what op-
erating mode it is set in.
1. Press MENU until "Addr" is displayed
2. Scroll through using the UP and DOWN buttons until "BLND" is displayed.
3. Press ENTER
4. The Display will now show "YES" or "NO"
5. Choose YES for Blackout. Choose NO for LED's on
6. Press ENTER to Confirm your choice.

Display Settings

If you mount the fixture upside down it will make it awkward to set the
modes so this feature lets you turn the display upside down too.
1. Press MENU until "Addr" is displayed
2. Scroll through using the UP or DOWN buttons until "dISP" is displayed.
3. Press ENTER
4. The Display will now show "YES" or "NO"
5. Choose "YES" for upside down, "NO" for normal view
6. Press ENTER to confirm your choice
NOTE: when the display is upside down, the MODE button be-
comes the ENTER button and the ENTER BUTTON becomes the
MODE button.
DMX Mode, Channels, Addressing
The icon can be set to operate with 2 DMX Channels or 8 DMX Chan-
nels.
1. Press MENU until "Addr" is displayed
2. Scroll through using the UP or DOWN buttons until "CHnd" is displayed.
3. Press ENTER
4. Choose between 8CH or 2CH
5. Press ENTER to confirm your choice
DMX Mode
DMX (Digital Multiplex) is a universal protocol used as a form of
communication between intelligent fixtures and controllers. A DMX
controller sends DMX data instructions from the controller to the
fixture. DMX data is sent as serial data that travels from fixture to
fixture via the DATA "IN" and DATA "OUT" XLR terminals located on
all DMX fixtures.
The ICON is a DMX enabled fixture and the DMX mode and DMX
address settings are controlled via the Digital control panel. It also
carries the standard 3-pin XLR connections for DMX use.
To set your fixture for use with a universal DMX controller:
1. Press MENU until "Addr" is displayed
2. Press ENTER
3. Display will show "A_ _ _ " (number)
4. Choose between A001 - A512
5. Press ENTER to confirm your choice
Your icon is now set at the DMX value you chose on the DMX uni-
verse.
Please consult the manual of your DMX controller for more informa-
tion on addressing fixtures. See Channel Config table at the rear of
the manual
Master/Slave Mode
Master/Slave is where one ICON will be set to the master and any
other ICONS will copy it. This is achieved by linking each ICON to-
gether using 3 PIN XLR cables and the DMX ports found at the rear.
MASTER ICON
1. Put master into Sound/Auto/Static/Strobe Mode
2. Connect XLR to the DMX OUT port
SLAVE ICON
1. Connect XLR cable to the DMX IN port
2.Press MENU until "Addr" is displayed
3.Scroll through until "SLA" is displayed
4. Press ENTER
Simply add another slave by copying above. Up to 24 Slaves can be
used per one master.
