LEX Lighting LexIcon User Manual page 3

Auto Run Mode & Pattern Selection & Speed
Auto mode is where the unit will go through it's pre-programmed pat-
terns one by one, regardless of any sound input. The user can choose
the pattern and the Pattern speed. First lets get your fixture into AUTO
Play mode:
1. Press MENU
2. Scroll through using UP and DOWN buttons until AUTO is
displayed
3. Press ENTER
4. The display will now show "SH_ _" (number)
5. Using the UP and DOWN buttons choose between SH00 -
SH12 (these are different program/pattern modes.
6. Press ENTER.
You Icon will now go each steps of the selected Pattern.
It is possible to adjust the SPEED of the pattern steps. Follow the steps
below:
1. Put the fixture in AUTO as shown above
2. Press MENU until "Addr" is displayed
3. Scroll through using the UP or DOWN buttons until "SPEE" is
displayed
4. Press ENTER
5. The Display will now show "SP_ _" (number)
6. Using the UP and DOWN buttons choose between SP00 -
SP99. (SP00=slowest / SP99=fastest)
Your Icon will now go through each steps of the selected Pattern at the
choosen speed.
- QUICK TIP: The Digital Display of your ICON will turn off after 30 seconds.
To change the speed again simply press any button. The display will turn
back on showing "SP_ _" (speed you chose before)....simply press the UP and
DOWN buttons to alter the speed.
Static Mode / Color Select & Strobe modes
Static mode is where the LED's are Static whcih creates a floodlight
type effect. You can choose what colours or a combination of col-
ours. Follow the steps below:
1. Press MENU until "Addr" is displayed
2. Scroll through using the UP and DOWN buttons until
"COLO" is displayed
3. Press ENTER
4. The Display will now show "C0_ _" (number)
5. Using the UP and DOWN buttons choose between
C001 - C015
6. Press ENTER.
Your icon will now display you choosen colour or combination of col-
ours in a STATIC flood effect. Below are the values of each colour
effect:
C001=WHITE
C002=BLUE
C003=BLUE+WHITE
C004=GREEN
C005=GREEN+WHITE
C006=GREEN+BLUE
C007=GREEN+BLUE=WHITE
C008=RED
C009=RED+WHITE
C010=RED+BLUE
C011=RED+WHITE+BLUE
C012=RED+GREEN
CO13=RED+GREEN+WHITE
C014=RED+GREEN+BLUE
C015=RED+GREEN+BLUE+WHITE (ALL LEDS ON)
When you have selected your desired colour(s), you can either
leave it static as shown above or you can have them flash/strobe.
1. Put the fixture in Static as shown above
2. Press MENU until "Addr" is displayed
3. Scroll through using the UP or DOWN buttons until "FLSH"
is displayed
4. Press ENTER
5. The Display will now show "FL_ _" (number)
6. Using the UP or DOWN buttons choose between FL00 -
FL51. (FL00 Slowest / FL51 Fastest (strobe speed)
