  • Page 1 FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limitations are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if no installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 2 CE Declaration of conformity This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022 class A for ITE, the essential protection requirement of Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility.

  • Page 3: Table Of Contents

    Table of Contents 1. Unpacking Information 2. Introduction To 16-Port NWay Switch General Description Key Features The Front Panel 2.3.1 System LEDs 2.3.1.1 Power LED 2.3.2 Port LEDs 2.3.2.1 100M LED 2.3.2.2 Link/Act LED The Rear Panel 2.4.1 Power Connecting 3.

  • Page 4: Unpacking Information

    1. Unpacking Information Thank you for purchasing the 16-port NWay switch. Before you start, please check all the contents of this package. The product package should include the following: 1. One 16-port NWay switch 2. One power adapter 3. User’s Manual 4.

  • Page 5: Introduction To 16-Port Nway Switch

    2. Introduction To 16-Port NWay Switch 2.1 General Description The device is a powerful, high-performance Fast Ethernet switch, with all 16 ports capable of 10 or 100Mbps auto-negotiation operation (NWay) which means the switch could automatically negotiate with the connected partners on the network speed and duplex mode.

  • Page 6: Key Features

    2.2 Key Features The switch provides the following key features: Complies with 10BASE-T specifications of the IEEE802.3 standard Complies with 100BASE-TX specifications of the IEEE802.3u standard Complies with IEEE802.3x Full Duplex operation and Flow Control 16 * RJ-45 ports for 100BASE-TX and 10BASE-T connectivity Supports NWay protocol for speed (10/100Mbps) and duplex mode (Half/Full) auto-detection All Supports MDI/MDI-X auto crossover...

  • Page 7: The Front Panel

    2.3 The Front Panel The front panel of the switch is shown as below. The auto-negotiation feature of the switch allows each port of the device running at one of the following four operation modes: 1. 100Mbps full-duplex 2. 100Mbps half-duplex 3.

  • Page 8: Link/Act Led

    2.3.2.2 Link/Act LED Every port has a Link/Activity LED. Steady green indicates that the port has good linkage to its associated devices. Flashing green indicates there is traffic transverses the port. The following table is a summary of Port LEDs. Operation 100M Link speed is 100Mbps (Green)

  • Page 9: Installing And Using 16-Port Nway Switch

    3. Installing And Using 16-Port NWay Switch 3.1 Installing The 16-Port NWay Switch The switch does not require software configuration. Users can immediately use any of the features of this product simply by attaching the cables and turning the power on. 3.1.1 Desktop Installation Locate the switch on the desktop and place the switch on a clean, flat desk or table close to a power outlet.

  • Page 10: Installing Network Cables

    3.1.2 Installing Network Cables After placing the switch on the desktop, then we need to know how to connect the device to network. 3.1.2.1 Station Connections with Twisted-Pair Cable Connect each station to the switch by a twisted-pair straight cable (10BASE-T or 100BASE-T cables).

  • Page 11: Network Application

    3.1.2.3 Network Application...

  • Page 12: Mac Address Table & Learning

    4. Switch Operation 4.1 MAC Address Table and Learning The switch is implemented with a MAC address table, which is composed of many entries. Each entry is used to store the address information of network nodes on the network, including MAC address, port ID, etc. The information is the most important base to do packet filtering and forwarding.

  • Page 13: Product Specifications

    5. Product Specifications Standard IEEE802.3, 10BASE-T IEEE802.3u, 100BASE-TX IEEE802.3x Full Duplex operation and Flow Control Interface 16 * RJ-45 NWay switching ports Cable Connections RJ-45 (10BASE-T) : Category 3,4,5 UTP/STP RJ-45 (100BASE-TX) : Category 5 UTP/STP Network Data Rate Auto-negotiation (10Mbps, 100Mbps) Transmission Mode Auto-negotiation (Full-duplex, Half-duplex)
