Eusso UGS5805-EMC Specifications

--FEATURES--
5 x 10/100/1000Mbps RJ-45 Ethernet ports
Complies with 1000Base-T IEEE802.3ab standard
Complies with 100Base-TX IEEE802.3u standard
Complies with 10Base-T IEEE802.3 standard
All ports support automatic MDI/MDI-X crossover
cable detection function
Dedicated bandwidth of up to 2000Mbps at full
duplex mode for maximum throughput
Advanced Store-and-forward architecture filters
fragment & CRC error package
Supports Full-duplex 802.3x flow control and half
duplex back-pressure
Efficient MAC address learning engine supports 1K
MAC address
Integrated 832K Bits buffer memory and 12K Bytes
Jumbo frame
Supports extensive LED indicators for network
diagnostics
Metal case with compact size design for desktop
--PACKAGE CONTENTS--
One Gigabit 5-port Workgroup Switch
One User's Manual
One External Power Adapter
UGS5805-EMC
5-Port Gigabit SOHO Ethernet Switch
High speed and performance Gigabit switch for SOHO network
--OVERVIEW--
The UGS5805-EMC, 5-port 10/100/1000Mbps desktop Gigabit switch,
provides an excellent solution for expanding your existing 10/100M
network to 1000M Gigabit server backbone without any additional
equipment. Moreover, it provides a backbone link to your switched
workgroup or a server fat-pipe link. With such flexible architecture, user
can easily plan the network without bandwidth and media limitation.
With 10Gbps at full-duplex switch bandwidth, the switch is fully
non-blocking architecture can support every switching port wire-speed
performance. Compare to shared 10/100/1000Mbps networks, the switch
delivers a dedicated 10/100/1000Mbps connection to every attached
client with no bandwidth congestion issue. Store-and-forward switching
mode promises the low latency plus eliminates all the network errors,
including runt and CRC error packets.
The Switch provides half and full-duplex capability on all ports to boost
bandwidth for servers and power users and is fully compliant with all
kinds of network protocols. Moreover, the rich diagnostic LEDs on the
front-panel provide the operating status of individual port and whole
system. It requires no configuration.
UGS5805-EMC designs with an external power feature. It is compact in
size, making it ideal for desktop with limited space. Drop this switch in
place of your current workgroup hub and switch, and you can upgrade
your current network to full Gigabit speeds as necessary.
