- Page 1 MC3 PCI Card Installation Guide MAN1430 Version 1.1.2...
- Page 2 Guide Proprietary Information The information contained in this document is the property of Aculab plc and may be the subject of patents pending or granted, and must not be copied or disclosed without prior written permission. It should not be used for commercial purposes without prior agreement in writing.
-
Page 3: Table Of Contents
1.1 General..........................4 1.1.1 Target Application for the MC3 PCI card............... 4 1.2 Overview of clock modes on the MC3 PCI card ............... 5 1.3 MC3 PCI card Host Interface..................... 5 2 Card Installation........................6 2.1 Card Installation - General ....................6 3 Switch Driver Installation.................... -
Page 4: Introduction
The idea is that the failed node (or group of failed nodes) is isolated on one physical ring while the remaining good nodes continue to be interconnected over the other physical ring. Note The maximum capacity between H.100 and MC3 of 2048 timeslots is available even when MC3 PCI is operated in self-healing mode. -
Page 5: Overview Of Clock Modes On The Mc3 Pci Card
MC3 interface card connected to the MC3 ring as MC3 clock slave and operating as H.100 clock master When MC3 PCI is operating as H.100 clock master at a node it must source its timing from the MC3 ring — it must slave timing from either ring 1 or ring 2. -
Page 6: Card Installation
• Do not attempt to install or remove the MC3 PCI card unless the mains power supply is completely removed from the host computer. •... -
Page 7: Technical Information
The Host PC System An MC3 PCI card may be fitted to any computer with a PCI bus. The MC3 switch driver is designed for use with Microsoft Windows NT4. The host PC must satisfy the minimum requirement for use with Windows NT4. -
Page 8: Mc3 Pci Card Architecture
MC3 PCI card Reset The MC3 PCI card enters a hardware reset state during power up and power down of the host PC (i.e. any time the RESET line on the PCI bus is asserted) and any time the +5V power supply from the host PC drops below a voltage at which proper operation can be maintained. -
Page 9: Bringing The Card Into Service
SC-type connectors. The topologies of two ring systems are shown in the following diagrams. Optical Bypass Relays are not supplied by Aculab. The current drawn from the MC3 card for an Optical Bypass Relay must not exceed 340mA for guaranteed continuous operation. - Page 10 Connecting multiple cards without Optical Bypass Relays* A possible configuration of multiple cards using Optical Bypass Relays* Note *Optical Bypass Relays are not supplied by Aculab. The current drawn from the MC3 card for an Optical Bypass Relay must not exceed 340mA for guaranteed continuous operation.
-
Page 11: Approvals
This section provides information on the Approval of the MC3 PCI card, and information that may affect the Approval status of the card in use. Failure to use the MC3 PCI card in accordance with any of these instructions may invalidate the Approval for connection. Further details are given in the appendix. -
Page 12: Documentation Release
Guide Documentation Release To ensure operation of the MC3 PCI card consistent with the terms of Approval, it is essential to ensure that the card is accompanied by the correct release of instructions and used in conjunction with the appropriate device drivers. -
Page 13: Appendix A: Regulatory Compliance Information
Appendix A: Regulatory compliance information This section supplies the country-specific information to supplement the general instructions for the MC3 PCI card. This section should always be read in conjunction with the other sections of this 'Installation Guide'. The following appendix cover detailed regulatory requirements for the following countries: Appendix B USA &... -
Page 14: Appendix B: Usa/Canada
Cet appareil numerique de la Classe B respecte toutes les exigences du reglement sur le materiel brouilleur du Canada. Usage and Type The MC3 PCI card is designed for use connected to one H.100 bus and an MC-3 fibre system. There are no direct connections to the PSTN. -
Page 15: Appendix C: European Union Countries
Appendix C: European Union countries Service Requirements In case of equipment malfunction, all repairs should be carried out by Aculab plc. It is the responsibility of users requiring service to report the need for service to our company. Service can be obtained at :... - Page 16 MC3 PCI Card Guide In order to maintain the host independent approval of the MC3 PCI card, it is essential that, when other (non Dual Fibre) expansion cards are introduced that use or generate a hazardous voltage, the minimum creepage and clearances specified above are maintained. A hazardous voltage is one that exceeds 42.4V AC peak or 60V DC If you have any doubt, seek advice from...
-
Page 17: Appendix D: Australia
Appendix D: Australia Service Requirements In case of equipment malfunction, all repairs should be carried out by Aculab plc. It is the responsibility of users requiring service to report the need for service to our company. Service can be obtained at :... - Page 18 MC3 PCI Card Guide In order to maintain the host independent approval of the MC3 PCI card, it is essential that, when other (non Dual Fibre ) expansion cards are introduced which use or generate a hazardous voltage, the minimum creepage and clearances specified above are also maintained. A hazardous voltage is one that exceeds 42.4V AC peak or 60V DC If you have any doubt, seek...
-
Page 19: Appendix E: Technical Specification
1x RJ45 4-way female Switch Capacity Limit • 2048 timeslot connections between MC3 and H.100 (64kbit/s timeslot) • 1024 bi-directional channel connections between MC3 and H.100 (2 timeslots per channel) Clocking • MC3 clock master • MC3 clock slave Ring 1 •...
