  • Page 1 Aculab Prosody PCI card Installation guide MAN1330 Version 2.2.6...
  • Page 2 Prosody PCI card – Installation Guide Proprietary information The information contained in this document is the property of Aculab Plc, and may be the subject of patents pending or granted, and must not be copied or disclosed without prior written permission.

  • Page 3: Table Of Contents

    Prosody PCI card – Installation Guide Contents 1 Introduction ..........................4 1.1 General..........................4 1.2 Uses of the Prosody PCI card .................... 5 1.3 Speech processing functions ..................... 5 1.3.1 Playback and recording of speech data including ..........5 1.3.2 Tone generation and detection................

  • Page 4: Introduction

    The serial number of the Prosody PCI card is used when configuring the device driver to uniquely identify a Prosody PCI card in the system. The serial number of the card is located on the reverse of the card (no components) on the top edge and has the format P/N ACXXXX S/N XXXX WONXXX.

  • Page 5: Uses Of The Prosody Pci Card

    Uses of the Prosody PCI card The Prosody PCI card is a plug-in card suitable for use in many different types of PCI compatible computer, and provides a platform in which to carry out a range of speech processing functions.

  • Page 6: Matrix Conferencing With Echo Suppression And Noise Gating

    Telephone Network Attachment Each port on an Aculab E1/T1 cPCI card, fitted with revision 2 E1/T1 PM 4 line interface modules, attaches to either an E1 (2Mbit) or T1 (1.544Mbit) digital system. It is available with 4 or 8 primary rate ports and subject to each port configuration may make or receive between 92 and 240 separate calls at a time.

  • Page 7: Prosody Pci Card - Host Interface

    CAUTION An Aculab screened RJ45 T piece must always be grounded through a screened patch cable connecting to the Aculab card; failure to do so could affect signal integrity on the trunk. Prosody PCI card - host interface A device driver program, running on the host computer, controls the behaviour of the Prosody PCI card.

  • Page 8: H.100/Mvip Ctbus Termination

    BE less than 7 inches. It is also recommended that the ribbon cable be no longer than required to interconnect the chain of H.100 CTBus devices. If the Prosody PCI card is the first or last device at either end of an H.100 CTBus, then the card MUST BE placed in terminated bus mode.

  • Page 9: Ctbus Loading

    H.100 CTBus. The loading limit of H.100 means that no more than six pre-revision 1.4 Prosody PCI cards can be used in the same host. The loading that each rev 1.4 card presents is only 1 allowing in theory a maximum of 20 cards in a system, however other software driver limitations restrict the loading to a maximum of 16 Prosody PCI cards in the same host.

  • Page 10: Card Installation

    However, in general: • Do not attempt to install or remove the Prosody PCI card unless the mains power supply is completely removed from the host computer and any network ports are disconnected from the network.

  • Page 11: Installing/Upgrading Modules

    SHARC modules onto an Aculab Prosody PCI card. Note Any work carried out on this assembly which results in any damage whatsoever will invalidate any claims under the Aculab Plc warranty. The SHARC module retaining clamp is a bracket that fits on top of the post normally used to retain the DSP module.
  • Page 12 PCI base card M3 x 6mm The configuration of modules fitted to the PCI Prosody card determines the orienteering of the clamp (1 or 2) and the length of the retaining screw used: - Base card only, no SHARC modules fitted...

  • Page 13: Installing A Card Into A Host

    Prosody PCI card endplate LED usage The endplate of the Prosody PCI card displays a block of eight LED’s. The red LED’s correspond to the network ports. With the exception of ISUP firmware, the LEDs will be on until firmware has been successfully downloaded to the corresponding port. For ISUP, the LEDs will be on until an active E1 link has been connected to the port.

  • Page 14: Approval Information

    This section provides information on the Approval of the Prosody PCI card, and information that may affect the Approval status of the card in use. Failure to use the Prosody PCI card in accordance with any of these instructions may invalidate the Approval for connection. These instructions refer only to the Aculab Prosody PCI card.

  • Page 15: Network Timing

    H.100 CTBus, MVIP bus or SC-Bus clock. The jitter performance required to maintain the card's approval status is only guaranteed if the external clock is derived from another Aculab E1/T1 Digital Access card that is connected to the network.

  • Page 16: User Responsibilities

    3.14 Speech calls If the Prosody PCI card is used in an application that makes or answers calls with a service code that indicates a speech or telephony call, or any call that may use a partly analogue route, the approval authority may place requirements on the audio signals transmitted.

  • Page 17: Appendix A: Country Specific Information

    Appendix A: country specific information This appendix supplies the country-specific information to supplement the Installation Guide for the Prosody PCI card. These appendices should always be read in conjunction with the other sections of 'Instructions for Use'. The appendices are arranged in separate sections detailing regulatory requirements for the following countries: Appendix B - USA &...

  • Page 18: Appendix B: Usa/Canada Approval Details

    ISDN (PRI) 6.0N 04DU9-1SN UL requirements This card has been assessed against UL60950-1 and is a listed accessory component under UL file number E178354. The Prosody PCI card should only be installed in a UL listed PCI bus, based computer system.
  • Page 19 Ringer Equivalence Number of all the devices does not exceed 5. Service requirements In case of equipment malfunction, all repairs should be carried out by Aculab Plc. It is the responsibility of users requiring service to report the need for service to our company.
  • Page 20 Canada. Usage and type The Prosody PCI card is principally designed for use connected to a 1544 Kbps T1 service configured for primary rate ISDN (PRI) with National ISDN 2 signalling. Other types of private circuit use are also appropriate, and other signalling systems are available or planned.
  • Page 21 FCC or IC registered Channel Service Unit (CSU), which is not supplied by Aculab. The default line build out setting is suitable for cables up to 133 feet between the card and the CSU.

  • Page 22: Appendix C: Approval Details For European Union Countries & Uk

    Prosody PCI card – Installation Guide Appendix C: Approval details for european union countries & UK This section applies only to the 120 Ohm and 75 Ohm E1 version of the PM 1/2/4 module.
  • Page 23 The following files are examples of the signalling software that has to be loaded into RAM for connection to the various types of network: Mercury CAS (PD1) PD1.UPR DASS-2 DASS_USR.UPR DPNSS M1DPNSS.UPR Please contact Aculab for details of other supported protocols. CAS functionality • Call initiation • Call clearing • Call answering •...
  • Page 24 Operational code running from RAM Speech calls If the Prosody PCI card is used in an application that makes or answers calls with a service code that indicates a speech or telephony call, or any call that may use a partly analogue route, there is a requirement that audio signals transmitted are encoded using CCITT A-law PCM, and do not exceed a 1 minute mean power level of -9dBm.
  • Page 25 If in doubt seek advice from a competent telecommunications safety engineer. In order to maintain the host independent approval of the Prosody PCI card, it is essential that, when other expansion cards are introduced which use or generate a hazardous voltage, the minimum creepage and clearances specified above are also maintained.
  • Page 26 Service requirements In case of equipment malfunction, all repairs should be carried out by Aculab Plc. It is the responsibility of users requiring service to report the need for service to our company.
  • Page 27 No changes or modification to the Prosody PCI card are allowed without explicit written permission from Aculab, as these could void the end user's authority to operate the device.

  • Page 28: Appendix D: Approval Details For Japan

    Prosody PCI card – Installation Guide Appendix D: Approval details for Japan...
  • Page 29 Mount Farm, Milton Keynes MK1 1PT, UK Aculab has received approval by JATE for connection to public primary rate ISDN as specified in this appendix, and the 'Instructions for Use' subject to the conditions set out in these documents. Usage and type...
  • Page 30 Prosody PCI card – Installation Guide Line interface Each network port on the card carries one 23-channel service connection via a screened twisted pair cable of 100 ohm characteristic impedance. There is one transmit pair and one receive pair. The card is designed to connect to a Data Service Unit (DSU) (NT1) as supplied by NTT.

  • Page 31: Appendix E: Approval Details For Australia & New Zealand

    Operational code running from RAM Speech calls If the Prosody PCI card is used in an application that makes or answers calls with a service code that indicates a speech or telephony call, or any call that may use a partly analogue route, there is a requirement that audio signals transmitted are encoded using CCITT A-law PCM, and do not exceed a 1 minute mean power level of -9dBm.
  • Page 32 If a 'cross-over' cable is to be produced to connect two Prosody PCI cards 'back-to-back', for example, when one card is to run an exchange end emulation and the other card a user end application, the cable may be wired as follows.

  • Page 33: Appendix F: Technical Specifications

    DSP32 module 0.8A max (+5V DC +/- 5%) Physical dimensions All Aculab PCI products conform to PCI local bus specification revision 2.1 Overall dimensions (excluding face plate): Height 106.68mm +/- 0.127mm Depth (including retainer) 340.74mm +/- 1.57mm Depth (excluding retainer) 312mm +/- 0.127mm...

  • Page 34: Appendix G: Ferrite Clamp Fitting Instructions

    Prosody PCI card – Installation Guide Appendix G: Ferrite clamp fitting instructions The following diagram depicts the correct fitting of Aculab part number AC0440 Ferrite clamps. These may be fitted as required, for example, when local EMC testing of a system identifies the need for E1/T1 trunk cable clamping.

  • Page 35: Glossary Of Abbreviations

    Prosody PCI card – Installation Guide Glossary of abbreviations: Australian Communications Authority A-Law The PCM coding and companding standard in Europe Bayonet Neill Concelman (Locking bayonet co-axial connector) Channel Associated Signalling CCITT Committee on International Telegraphy and Telephony Common Channel Signalling...
  • Page 36 Prosody PCI card – Installation Guide PSTN Public Switched Telephone Network Public Telephone Operator Random Access Memory Ringer Equivalence Number Registered Jacks (RJ11=6 position, RJ45=8 position) SELV Safety Extra Low Voltage SCBus Dialogic specific version of MVIP bus American 1.55Mbits/s 24 channel standard...
