Aculab E1/T1 cPCI card
Installation guide
MAN1370 Revision 2.2.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E1 and is the answer not in the manual?

Questions and answers

Related Manuals for aculab E1

Summary of Contents for aculab E1

  • Page 1 Aculab E1/T1 cPCI card Installation guide MAN1370 Revision 2.2.1...
  • Page 2 The development of Aculab Plc products and services is continuous and published information may not be up to date. It is important to check the current position with Aculab Plc. ©...

  • Page 3: Table Of Contents

    E1/T1 cPCI card – Installation guide Contents 1 Introduction ..........................4 1.1 General..........................4 1.2 Uses of the E1/T1 cPCI card ....................5 1.3 Telephone network attachment..................5 1.4 75 ohm network connection ..................... 6 1.5 E1/T1 cPCI card - host interface ..................7 1.6 Call control ........................

  • Page 4: Introduction

    When providing both E1 and T1 network connections from the same cPCI card, standard practice is to set the top module (ports 0-3) as E1 and the bottom module (ports 4-7) as T1. It is not possible to have mixed E1/T1 ports on a single PM module.

  • Page 5: Uses Of The E1/T1 Cpci Card

    Note The E1/T1 cPCI card is not a complete product, and only has usable functionality when associated with a host chassis and an application program. Telephone network attachment The E1/T1 cPCI card with revision 1.5 E1 PM4 Line Interface Modules fitted, attaches to the 2Mbit digital system or Primary Rate (2.048 Mbit/s) Integrated Services Digital Network (ISDN).

  • Page 6: Ohm Network Connection

    Different impedance can be supported on the same E1 variant module; Note The revision 2 modules can simultaneously support both E1 and T1 ports. Earlier revisions could only support either E1 or T1 as they required different E1 or T1 variant modules.

  • Page 7: E1/T1 Cpci Card - Host Interface

    There are two categories of multi-channel path provided by the card. The figures in part 1 below are for one PM4 module. The fitting of a second E1 or T1 PM4 module will increase the call handling capacity accordingly.

  • Page 8: Ctbus Loading

    E1/T1 cPCI card – Installation Guide Full details on the switching of calls using the E1/T1 cPCI card are available in a separate publication ‘Aculab Switch Control API Guide’. This guide can be downloaded from http://www.aculab.com. H.110 CTBus loading The E1/T1 cPCI card has a loading factor of 1 on the H.110 CTBus. The maximum loading allowed on the H.110 CTBus is 20.

  • Page 9: Card Installation

    There is a single blue LED on the end plate of the E1/T1 cPCI card. Only when this LED is lit is the card then ready to be fully removed. Press the red release button to unlock the upper lever, then simultaneously operate both levers and slide out the card to fully remove it.

  • Page 10: E1/T1 Cpci Card Led Usage

    E1/T1 cPCI card LED usage The Aculab E1/T1 cPCI card has a block of eight LEDs visible on the endplate of the card. These LEDs are labelled, and each one corresponds to a port on the card. If the card is fitted with one PM4 module, then the LEDs for those four ports will operate and the LEDs for the unused ports will be off.

  • Page 11: Approval Information

    This section provides information on the Approval of the E1/T1 cPCI card, and information that may affect the Approval status of the card in use. Failure to use the E1/T1 cPCI card in accordance with any of these instructions may invalidate the Approval for connection.

  • Page 12: Network Timing

    H.110 CTBus clock. The jitter performance required to maintain the card's approval status is only guaranteed if the external clock is derived from another Aculab E1/T1 cPCI digital network access card that is connected to the system. Other clock configurations may require further testing to ensure compliance.

  • Page 13: User Responsibilities

    3.14 Speech calls If the E1/T1 cPCI card is used in an application that makes or answers calls with a service code that indicates a speech or telephony call, or any call that may use a partly analogue route, the approval authority may place requirements on the audio signals transmitted.

  • Page 14: Appendix A: Country Specific Information

    Appendix A: Country Specific Information This appendix supplies the country-specific information to supplement the Installation Guide for the E1/T1 PCI card. These appendices should always be read in conjunction with the other sections of 'Instructions for Use'. The appendices are arranged in separate sections detailing regulatory requirements for the following countries: Appendix B - USA &...

  • Page 15: Appendix B: Usa/Canada Approval Details

    There are no user serviceable components on the card. UL requirements This card has been assessed against UL60950-1 and is a listed accessory component under UL file number E178354. The E1/T1 cPCI card should be installed in a UL listed cPCI bus, based computer system. Industry Canada warnings The Industry Canada label identifies certified equipment.
  • Page 16 Service requirements In case of equipment malfunction, all repairs should be carried out by Aculab Plc. It is the responsibility of users requiring service to report the need for service to our company. Contact details for the USA and Canada offices, (Aculab USA Inc) are available from the Aculab company web site at www.aculab.com.
  • Page 17 Canada. Usage and type The E1/T1 cPCI card is principally designed for use connected to a 1544 Kbps T1 service configured for primary rate ISDN (PRI) with National ISDN 2 signalling. Other types of private circuit use are also appropriate, and other signalling systems are available or planned.
  • Page 18 The card is designed to connect to an FCC or IC registered Channel Service Unit (CSU), which is not supplied by Aculab. The default line build out setting is suitable for cables up to 133 feet between the card and the CSU.

  • Page 19: Appendix C: Approval Details For European Union Countries

    E1/T1 cPCI card – Installation guide Appendix C: Approval details for European Union countries This section applies only to the 120 ohm E1 version of the PM4 module.
  • Page 20 E1/T1 cPCI card – Installation Guide...
  • Page 21 DPNSS signaling. The 120 Ohm E1 card described here is principally designed for use connected to a 2048 kb/s integrated services digital network (primary rate ISDN) with ETS300-102 signalling, but other types of private circuit use are also appropriate, and other signalling systems are available or planned.
  • Page 22 Operational code running from RAM Speech calls If the E1/T1 cPCI card is used in an application that makes or answers calls with a service code that indicates a speech or telephony call, or any call that may use a partly analogue route, there is a requirement that audio signals transmitted are encoded using CCITT A-law PCM, and do not exceed a 1 minute mean power level of -9dBm.
  • Page 23 If in doubt, seek advice from a competent telecommunications safety engineer. In order to maintain the host independent approval of the E1/T1 cPCI card, it is essential that when other expansion cards are introduced which use or generate a hazardous voltage, the minimum creepage and clearances specified above are also maintained.
  • Page 24 Refer to section 1.5 for details on the location of these jumpers. Network connection via other apparatus If other apparatus, including cable or wiring, is to be connected between the E1 card and the point of connection to the network, then all of that apparatus must comply with the following: •...
  • Page 25 Service requirements In case of equipment malfunction, Aculab Plc should carry out all repairs. It is the responsibility of users requiring service to report the need for service to our company. Service can be obtained at:...

  • Page 26: Appendix D: Approval Details For Australia & New Zealand

    RAM Speech calls If the E1/T1 cPCI card is used in an application that makes or answers calls with a service code that indicates a speech or telephony call, or any call that may use a partly analogue route, there is a requirement that audio signals transmitted are encoded using CCITT A-law PCM, and do not exceed a 1 minute mean power level of -9dBm.
  • Page 27 E1/T1 cPCI card – Installation guide Many of the speech and fax resource cards that may be used with the E1/T1 cPCI card comply with this requirement. It is the responsibility of the user to ensure that this requirement is complied with, by confirmation via the manufacturer of the card, or by any other suitable means such as independent testing.

  • Page 28: Appendix E: Technical Specifications

    TDM interfaces • H.110 compliant interface supporting connection to any of the 4096 timeslots Switching • Quad trunk 120/96/92 channels between network and TDM interface (E1/T1/T1 PRI) per • Local switching of 240 channels to signalling DSP Clocking • With PM4 module — CT bus master supporting clock fallback...

  • Page 29: Appendix F: Ferrite Clamp Fitting Instructions

    E1/T1 cPCI card – Installation guide Appendix F: Ferrite clamp fitting instructions The following diagram depicts the correct fitting of Aculab part number AC0440 Ferrite clamps. These may be fitted as required, for example, when local EMC testing of a system identifies the need for E1/T1 trunk cable clamping.

  • Page 30: Glossary Of Abbreviations

    Mbps. E1 is the rate used by European CEPT carriers to transmit 32 64 Kb/s channel, 30 of them used for voice and data calls. A PCM system, E1 is used throughout the world with the exception of North America and Japan.
  • Page 31 E1/T1 cPCI card – Installation guide POTS Plain Old Telephone System Primary Rate Interface (23B + 1D T1 or 30B + 1D E1) PSTN Public Switched Telephone Network Public Telephone Operator Random Access Memory Ringer Equivalence Number Registered Jacks (RJ11=6 position, RJ45=8 position)
