La Crosse 308-1414 Instruction Manual

Wireless color weather station
Hide thumbs
Table of Contents

Advertisement

Quick Links

Outdoor
Temperature,
Humidity
with Trends
&
Temperature
Alerts
AC Power Jack
GPU280500150WD00
Model: 308-1414B/308-1414W

WIRELESS COLOR WEATHER STATION

Color Animated Forecast with
Time, Calendar +
Wall Hanging Holes
Battery
Cover
Base
Stand
Battery
Compartment
3 "AAA"
www.lacrossetechnology.com/support
Tendency
Alarm
Battery Cover
Model: 308-1414
Instruction Manual
DC: 071514
SENSOR
TX141TH-B
LED
Sensor
Compartment
Indoor
Temperature,
Humidity
with Trends
&
Temperature
Alerts
TX
Sensor
Battery
2 "AA"
Page | 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 308-1414 and is the answer not in the manual?

Questions and answers

Related Manuals for La Crosse 308-1414

Summary of Contents for La Crosse 308-1414

  • Page 1: Wireless Color Weather Station

    Model: 308-1414 Instruction Manual DC: 071514 WIRELESS COLOR WEATHER STATION Color Animated Forecast with Tendency Outdoor Indoor Temperature, Temperature, Humidity Humidity with Trends with Trends & & Temperature Temperature Alerts Alerts Time, Calendar + Alarm Wall Hanging Holes SENSOR TX141TH-B...

  • Page 2: Table Of Contents

    Quick Setup Step 1: Insert the 5 volt AC cord (included) into the wall outlet then into the weather station. Step 2: Insert the 3 new AAA Alkaline batteries (not included) into the weather station. Observe the correct polarity. Step 3: Insert the 2 new AA batteries (not included) into the TX141TH-B outdoor sensor.
  • Page 3 Adjust Backlight (HI-LOW-OFF) ......................9 Time Alarm Set ............................9 Deactivate Alarm ............................9 Snooze ................................9 Heat Index/Dew Point ......................... 10 Heat Index ..............................10 Dew Point Temperature ..........................10 Temperature/Humidity Trend indicators ..................10 Search for Outdoor Sensor ......................... 10 MIN/MAX (View, Reset) ........................

  • Page 4: Introduction

    Introduction La Crosse Technology® introduces a Wireless Color Weather Station with precise, real- time backyard weather. Animated color forecasts with trends react to changing barometric pressure. Monitor in/out temperature trends with high and low alert settings. Measure in/out temperature and humidity with daily min/max records -- all on one easy- to-read color display with adjustable brightness.

  • Page 5: Button Functions

    STEP 3:  Ensure that the transmitter is within 10 feet of the Weather station.  Remove battery cover from transmitter. Slide the battery cover down and lift off the front.  Insert two new AA batteries into the TX141TH-B transmitter. Observe the correct polarity.

  • Page 6: (Up) Button

    ▲ (UP) Button Setting-  Press to increase the values during setting.  Hold 2 seconds to quickly adjust values. Default Time Display-  Press to view maximum temperature/humidity.  Hold 2 seconds to clear maximum temperature/humidity memory. Temperature Alert- ...

  • Page 7: Time Zone

    2. WWVB and ON will flash. 3. Press and release the ▼ or ▲ buttons to turn this OFF if you do not WWVB want to receive the WWVB time signal. 4. Confirm with the TIME SET button and move to the Time Zone. Time Zone This station offers seven time zones listed in letter format (default is EST): ...

  • Page 8: Set Calendar

    Set Calendar The date default of the weather station is 1. 1. 2014. To set the calendar: The year will flash. Press and release the ▼ or ▲ buttons to set the year (between years 2000-2039). Press the TIME SET button again to confirm and to enter the month setting. The month will flash.

  • Page 9: Temperature Alert Sounds

    Indoor HI Indoor LO Press the ▲ button to arm the selected alert.  The alert bell appears when each alarm is activated.  Press the ▼ button to disarm the selected alert.  OFF will show in the Alerts area if no alert is active. ...

  • Page 10: Heat Index/Dew Point

    Heat Index/Dew Point The HEAT/DEW button toggles between Heat Index, Dew Point, and Mold Risk. Each feature will display for 10 seconds then return to default display if the button is not pressed again. Heat Index Heat Index combines the effects of heat and humidity. It is the apparent temperature of how hot it feels to a human being.

  • Page 11: Min/Max (View, Reset)

    MIN/MAX (View, Reset) The Weather station provides the daily minimum and maximum temperatures each day starting at midnight (12:00 AM). The Weather station automatically resets the min/max temperatures at midnight (12:00 AM). View MIN data: Press and release the ▼ button to view the minimum Indoor and Outdoor Temperatures.

  • Page 12: Forecast Tendency Indicators (Up, Right, Down Arrows)

    the rainy icon is displayed, it does not mean that the product is faulty because it is not raining. It simply means that the air pressure has dropped and the weather is expected to get worse, but not necessarily rainy. Forecast Tendency Indicators (Up, Right, Down Arrows) Working with the forecast icons, the tendency indicators let you know if the weather is improving, steady or worsening.

  • Page 13: Specifications

     Clean with a soft damp cloth. Do not use solvents or scouring agents.  The product is not a toy. Keep it out of reach of children.  The product is not to be used for medical purpose or for public information. It is intended for home use only.

  • Page 14: Warranty Information

    Warranty Information La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product relating to manufacturing defects in materials & workmanship. View full warranty details online at: www.lacrossetechnology.com/warranty_info.pdf For warranty work, technical support or other information contact:...
