Page 13: Chapter 1 Introduction
The keys on the keypad are constructed of a phosphorescent material that can easily be seen in dimly lighted areas. The MX3-CE is a Windows CE compatible computer that can be scaled from a limited function batch computer to an integrated RF scanning computer. A stylus is enclosed with the MX3-CE to assist in entering data and configuring the unit.
Page 14: Components
Components Components Figure 1-1 Front of MX3-CE Endcap Shift LED Display Caps LED Scan or Enter Scanner LED (programmable) Beeper Backup Battery LED On/Off Button Status LED Main Battery LED Alt LED Charger LED Ctrl LED Scan or Enter (programmable)
Page 15: When To Use This Guide
Use this reference guide as you would any other source book -- reading portions to learn about the MX3-CE, and then referring to it when you need more information about a particular subject. This guide takes you through all aspects of installation and configuration for the LXE MX3-CE.
Page 16: Document Conventions
Keyword that indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. DANGER Keyword that indicates a imminent hazardous situation which, if not avoided, will result in death or serious injury. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 17: Getting Started
New batteries must be fully charged prior to use. This process takes up to four hours in an LXE Multi-Charger and up to eight hours using the MX3-CE internal charger. Important If the MX3-CE has AppLock installed, please refer to “Appendix D – AppLock” for setup and processing information before continuing with “Getting Started.” E-EQ-MX3CERG-E...
Page 18: Radio And Network Setup
If the access point uses authentication protocol (WEP, LEAP, etc.) your radio must use the same authentication keys. Please contact your IS department for WEP and LEAP encryption keys before contacting LXE. Symbol Access: Tap Symbol radio icon in taskbar 1.
Page 19: Proxim
LAN (802.11B), make sure your mobile client is communicating with the Access Point. 2. From the Start | Program, run LXE RFTerm or tap the RFTerm icon on the desktop. 3. Select Session | Configure from the application menu and select the "host type" that you require.
Page 20: About Lithium-Ion Batteries
Li-Ion batteries (like all batteries) gradually lose their capacity over time (in a linear fashion) and never just stop working. This is important to remember -- the MX3-CE is always 'on' even when in the Suspend state and draws battery power at all times. Use the Start | Settings | Control Panel | Power Properties | Charge tab to check the battery status and power reading.
Page 21: Insert Main Battery
Press the Power button after the battery is inserted into the MX3-CE. Note: New batteries must be charged prior to first use. This process takes up to four hours in an LXE Multi-Charger and eight hours with an external power source attached to the MX3-CE. Figure 1-5 Main Battery...
Page 22: Figure 1-6 Battery Compartment
Getting Started Figure 1-6 Battery Compartment The MX3-CE Battery Compartment is located at the bottom of the back of the computer. The arrows in the figure above point to the battery contacts in the computer. Figure 1-7 Main Battery Place the battery in the compartment, making sure the side of the battery with six contacts matches up with the battery contacts in the computer battery compartment.
Page 23: Attach Handstrap (Optional)
2. Place the MX3-CE, with the screen facing down, on a flat stable surface. 3. Attach the handstrap to the MX3-CE with the screws and washers provided. 4. Test the strap's connection making sure the MX3-CE is securely connected to each end of the strap connectors.
Page 24: Attach To Hip-Flip (Optional)
#1 flat head screwdriver are not supplied by LXE. A waist belt can be ordered from LXE. Once the MX3-CE is attached to the hip-flip and the hip-flip securely fastened to the user by a belt around their waist, the MX3-CE can be operated at a convenient height, leaving the user's hands free.
Page 25: Connect External Power Supply (Optional)
Figure 1-10 US AC/DC 12V Power Supply and Cigarette Lighter Adapter Figure 1-11 International AC/DC 12V Power Supply The MX3-CE DC power jack is located on the endcap. The cradle power jack is located on the back of the cradle.
Page 26: Connect Audio Jack (Optional)
Please refer to the section titled "Power Modes" later in this manual for a list of the kinds of activities that will return the MX3-CE from Suspend Mode. Troubleshooting The MX3-CE will not turn off – force a Reboot by holding the Power key down for 15 seconds and the MX3-CE will reboot. MX3-CE Reference Guide...
Page 27: Touch Screen Calibration
Getting Started Touch Screen Calibration If the MX3-CE is not responding properly to pen touch taps, you may need to recalibrate your screen. Recalibration involves tapping the center of a target. If you miss the center, keep the stylus on the screen, slide it over the target's center, and then lift the stylus.
Page 28: Set The Display Backlight Timer
OK to save the changes. The first option may be set when the MX3-CE will be running on battery power only. The second option may be set when the MX3-CE will be running on external power (e.g. AC adapter, cigarette adapter, powered cradle).
Page 29: Set The Display Blanking Timer
OK to save the changes. The first option may be set when the MX3-CE will be running on battery power only. The second option may be set when the MX3-CE will be running on external power (e.g. AC adapter, cigarette adapter, powered cradle).
Page 30: Set The Mx3-Ce Power Off Timer
OK to save the changes. The first option may be set when the MX3-CE will be running on battery power only. The second option may be set when the MX3-CE will be running on external power (e.g. AC adapter, cigarette adapter, powered cradle).
Page 31: Set The Audio Speaker Volume
The audio volume can be adjusted to a comfortable level for the operator. The volume is increased or decreased one step each time the volume key is pressed. The MX3-CE has an internal speaker and a jack for an external headset.
Page 32: Endcaps
Labels” for important laser safety information before using the scanner. The MX3-CE supports three COM port options. Two external serial ports are dependent on the end cap chosen. A third serial port is used to support an infrared transceiver (barcode reader). An additional endcap configuration supports serial input/output at 1.5 MBps.
Page 33: Com Port Switching
Com 3 Port Audio Jack The COM 2 port is always the IR port on the back of the MX3-CE, regardless of the type of endcap installed. On the Standard Range Scanner / Serial Port endcap COM 3 is the Integrated Scanner port.
Page 34: Figure 1-20 Scanner Port And Programmable Button Screen
Settings | Control Panel | Scanner | COM .. tab. Scanner Control Main Keys COM1 COM2 COM3 Baud Rate Data Bits Parity 19200 9600 4800 Stop Bits 2400 1200 Power on pin 9 (+5V) Figure 1-21 Assign COM Port Parameters MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 35: Pcmcia Cards
Make sure the proper software is pre-loaded and PC cards are properly configured. There is one PC card slot (Slot 0) and one Compact Flash card slot (Slot 1) in the MX3-CE. Slot 0 powers a radio PC card, PC SRAM card, ATA Flash card or a linear Flash card. The slots hold only one card at a time.
Page 36 2. Use caution not to pull or snag the antenna connector on the Radio card, if installed. If you anticipate keeping the PC card out of the MX3-CE for a long period of time place it in an enclosed storage container. Store in an area that is protected from dirt, moisture, and electrostatic contact.
Page 37: Pcmcia Radio Card
MX3-CE unit. If you anticipate keeping the radio card out of the MX3-CE for a long period of time place it in an enclosed storage container. Store in an area that is protected from dirt, moisture, and electrostatic contact.
Page 38: Data Entry
The keypad is used to manually input data that is not collected otherwise. Almost any function that a full sized computer keyboard can provide is duplicated on the MX3-CE keypad but it may take a few more keystrokes to accomplish a keyed task.
Page 39: Scanner Entry
Scan button. A red laser beam strikes the barcode. Align the red beam so that the barcode is centered within the beam. The laser beam must cross the entire barcode. Move the MX3-CE towards or away from the barcode so that the barcode takes up approximately two-thirds the width of the beam. Following a barcode scan and read the SCNR LED turns green and the MX3-CE beeps, indicating a successful scan.
Page 40: Power Modes
Primary Events and Power Modes Any key on the keypad PC card activity Stylus touch on the touch screen Serial connection Power button tap External device connection (e.g. cradle) COM1 CTS Display activity USB connection COM3 CTS MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 41: On Mode
• when the Main Battery is hot-swapped, the display is turned Off. The MX3-CE After a new MX3-CE has been received, a charged Main Battery inserted, and the Power button tapped, the MX3-CE is always On until both batteries are drained completely of power.
Page 42: Suspend Mode
The Suspend mode is entered when the unit is inactive for a predetermined period of time, the operator taps the Power button, or Start | Suspend is chosen. MX3-CE Suspend timers are set using Start | Settings | Control Panel | Power Properties | Power Off.
Page 43: Critical Suspend Mode
PCMCIA card. When the MX3-CE is in the Critical Suspend state (the Main Battery is in place and the unit is being powered by the Backup Battery), the display turns off, the BATT M LED begins to flash red, all peripherals are shut down, the CPU clock is stopped, and power is removed from the PCMCIA card.
Page 44: Getting Help
LXE website. Contact your LXE representative to obtain the LXE Manuals CD. You can also get help from LXE by calling the telephone numbers listed on the LXE Manuals CD, in the file titled "Contacting LXE". This information is also available on the LXE website www.lxe.com.
Page 45 Power Adapter, Bare Wire 12 VDC 1300A053CBL12ML3 Power Adapter, 24-72 VDC, 20 Watts 1300A301PS24WW Power Adapter, 110-240 VAC 1300A303PSACWW Cables for Cradle and MX3-CE Serial Ports Cable, PC, DA-9F to DA-9F, 6 ft. for download 9000A054CBL6D9D9 USB cable 9000A067CBL48D9USB Cable, D9F to D25F, for printer...
Page 46 Getting Help MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 47: Chapter 2 Physical Description And Layout
Chapter 2 Physical Description and Layout Hardware Configuration System Hardware The MX3-CE hardware configuration is shown in the following figure. PCMCIA Card Compact Flash Card Type I, II Slot 1 Slot 0 D C- C+ Figure 2-1 System Hardware E-EQ-MX3CERG-E...
Page 48: Central Processing Unit
3.7 to 21 MB in size, depending on the amount of flash available and options in the Windows CE image. The computer has one Type II CF+ slot. The MX3-CE supports and auto detects up to 256MB of Type I compact flash memory.
Page 49: Power Supply
MX3-CE with the computer in a powered cradle or with the optional external power sources attached. The main battery pack can be removed from the MX3-CE and inserted in the LXE Multi-Charger which simultaneously charges up to six battery packs in four hours.
Page 50: Pcmcia Slots
Type II or III cards only. Slot 0 accepts PCMCIA 2.4GHz radio cards or SRAM/Flash memory cards. Slot 1 The MX3-CE has one internal compact Flash card port that supports Type I and II CF+ cards. The slot is accessible when the endcap has been removed. MX3-CE Reference Guide...
Page 51: Physical Controls
Hold the Power key down until the display goes out then release the Power button. The display goes out in 5 seconds when the MX3-CE is in optimal condition. When there is a hardware failure, the display goes out in 15 seconds. In either case, the MX3-CE will reboot.
Page 52: Endcaps
DC Power Jack Audio Jack The default COM 2 port is always the IR port on the back of the MX3-CE, regardless of the type of endcap installed on the unit. On the Standard Range Scanner / Serial Port endcap COM 3 is the Integrated Scanner port.
Page 53: Serial Port
DESCRIPTION Carrier Detect Receive Data - Input Transmit Data - Output Data Terminal Ready Signal/Power Ground Data Set Ready Ready To Send Clear To Send Ring Indicator - Input +5V DC Figure 2-4 9-Pin RS-232 Description E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 54: Usb Port
Tethered scanners read barcode scans only when the trigger on the tethered scanner is pressed. To set the MX3-CE to use a tethered scanner, select Start | Settings | Control Panel | Scanner | COM1 (or 2 or 3).
Page 55: Scan Buttons
There are two buttons, one on each side of the display. The buttons are programmable and function as an integrated barcode scanner key or a numeric keypad Enter key. The Scan keys have no effect on scanners tethered to the MX3-CE. When there is no integrated scanner installed, both buttons default to Enter buttons.
Page 56: Button Settings
The default setting for the right button is Enter. The default setting for the left button is Scan. When the MX3-CE does not have an integrated scanner, both buttons default to Enter keys and the Scan selection is greyed out.
Page 57: Keypad
Touch Screen and Keypad Shortcuts Use keyboard shortcuts instead of the stylus when the MX3-CE is running WinCE. Press Tab and an Arrow key to select a file. Press Shift and an Arrow key to select several files. Once you've selected a file, press Alt-Enter to open its Properties dialog.
Page 58: Ctrl Key Function
Caps key sequence first. To cancel a CapsLock function press the Caps key sequence again. When the CapsLock mode is active, the Caps LED illuminates. The CapsLock key sequence is 2 + F1. Keypress Sequences See Appendix A for key maps for all keypads. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 59: Led Functions
Steady Red – low battery. • Blinking Red – power fail. CHGR Charger. When on, the MX3-CE is receiving external power either from the DC power jack or the MX3-CE is seated in a powered cradle. • Red - Main Battery is charging.
Page 60: Display
Display Figure 2-11 MX3-CE Display The MX3-CE Touch Screen Display is an LCD unit capable of supporting VGA graphics modes. Display size is 640 x 240 pixels. The display covering is designed to resist stains. The touch screen allows signature capture and touch input. A pen stylus is included. The touch screen responds to an actuation force (touch) of 4 oz.
Page 61: Touchscreen
Display Touchscreen The touchscreen provides a means of inputting information into the MX3-CE by touching the screen using the LXE approved stylus (the Passive Pen – see Chapter 1 section titled “Accessories.”) Touchscreen operation is not affected by Display Backlighting.
Page 62: Speaker
Figure 2-12 Speaker Location The MX3-CE Speaker has a loudness of at least 90 dB (2700 Hz) at 10 cm measured from the front of the unit. The Speaker volume is adjustable via the keypad or the Control Panel or by an application through the use of an API call.
Page 63: Infrared (Ir) Port
The MX3-CE uses IrDA protocol to send data in both directions, but not simultaneously. When sending data through the IR port, make sure the IR port on the first MX3-CE and the IR port on the second MX3-CE are in close proximity to each other. IrDA is not required and not used by terminal emulation programs.
Page 64: Storage Cradles
Storage Cradles Storage Cradles There are two types of cradles for LXE's MX3-CE mobile computer: a desk top cradle for tabletop charging / communication applications and a vehicle mount cradle for vehicle mounted charging / communication applications. See the "MX3 Cradle Reference Guide."...
Page 65: Chapter 3 Power Supply
Backup Battery inside the MX3-CE that is recharged only by the Main Battery Pack. The MX3-CE maintains the date and time for a minimum of four days using a Main Battery that has reached the Low Warning point and a fully charged Backup Battery. The MX3-CE retains data, during a Main Battery hot swap, for at least 5 minutes.
Page 66: Main Battery Pack
The main battery pack has a rugged plastic enclosure that is designed to withstand the ordinary rigors of an industrial environment. Exercise care when transporting the battery pack making sure it does not come in contact with excessive heat or any power source other than the LXE Multi- Charger or the MX3-CE unit.
Page 67: Critical Suspend State
Suspend state. To resume operation tap the Power key. If the Off Timer expires the MX3-CE will turn itself off and all unsaved information is lost. Insert a fully charged main battery and press the Power button to turn the MX3-CE back on.
Page 68: Maintenance
Maintenance Note: Make sure there is a fully charged main battery in the MX3-CE before running the Backup Battery Discharge Utility. The backup battery can be discharged and charged while the MX3-CE is receiving external power through the Power Jack or from a powered cradle.
Page 69: Battery Chargers
Battery Chargers MX3 Multi-Charger Figure 3-2 MX3 Multi-Charger and MX3 Multi-Charger Plus The MX3-CE Main Battery Pack can be charged in the LXE Multi-Charger and charged/analyzed in the MX3 Multi-Charger Plus. Figure 3-3 Insert Main Battery in Charge Pocket Lower the battery pack straight into the battery charger pocket and push it down firmly until the retaining clip catches on the retaining pins.
Page 70: External Power Supply (Optional)
The MX3-CE DC power jack is located on the endcap. The cradle power jack is located on the back of the cradle.The MX3-CE (and the Desktop Cradle) connect to any of the following power supplies through the DC Power Jack.
Page 71: Chapter 4 System Configuration
Chapter 4 System Configuration Introduction There are several different aspects to the setup and configuration of the MX3-CE. Many of the setup and configuration settings are dependent upon the optional features such as hardware and software installed on the unit. The examples found in this chapter are to be used as examples only, the configuration of your specific MX3-CE computer may vary.
Page 72: Software Load
Microsoft CE, which is Windows CE 3.0 with MFC support. Radio Drivers • Only one radio is installed in the MX3-CE at any one time. The 2.4GHz type of PC radio card resident on the MX3-CE determines the type of radio driver running on the MX3-CE.
Page 73: Persistent Registry
LAUNCH.EXE, REGCLEAR.EXE and REGSAVE.EXE Java Virtual Machine (Optional) The MX3-CE optionally includes the Insignia Jeode Java virtual machine. This VM supports Sun Personal Java specification 1.2, with enhancements unique to the Windows CE environment. The VM is fully integrated with the Pocket Internet Explorer browser, and can also run Java applications from the Windows CE desktop.
Page 74: Desktop
For general use instruction, please refer to commercially available WinCE user's guides or the WinCE on-line Help application installed with the MX3-CE. The MX3-CE Desktop appearance is similar to that of a desktop PC running Windows 95, 98, NT or 2000.
Page 75: Start Menu Program Options
This program is similar to the Microsoft Windows program REGEDIT. LXE cautions the user to edit parameters in the Registry with care, making sure a backup copy is first saved before any changes are made. Contact LXE Customer Support before making changes to the Pocket Registry parameters.
Page 76: Site Survey Tool
Select "Make New Connection" and follow the instructions on the screen to create a connection while following the directions in the section titled "Backup MX3-CE Files" later in this chapter. Remote Networking Remote networking is used to create a connection with a different baud rate than the default baud rate.
Page 77: Terminal
Start Menu Program Options Terminal This option requires a radio card. Use this option to connect the MX3-CE to an online service or intranet that requires TTY or VT-100 terminal emulation. Use this option only when communicating with services that require terminal emulation.
Page 78: Command Prompt
MX3-CE. Microsoft Word templates (.DOT files) are converted to PocketWord templates (.PWT). Click the "?" button to access PocketWord Help. When ActiveSync transfers .pwd files to the desktop from the MX3-CE, the file is converted to .doc files by ActiveSync. MX3-CE Reference Guide...
Page 79: Orinoco Client
Figure 4-2 ORiNOCO Client Setup Tools Edit Wireless Profiles Add / edit the configuration profiles Version Info Displays the version levels of the radio, MX3-CE hardware and software Load/Unload The default is "Load Automatically." Use this option to load the Automatically radio drivers when the MX3-CE is rebooted.
Page 80: Symbol Client
• Allow handheld PC to suspend when wireless network is used Encryption Listed below are the different encryption options for this menu • Open System (No Encryption) – Default • 40-bit Shared Key • 128-bit Shared Key • Keberos MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 81: Ping Menu
A test utility that pings a host using the MX3-CE. Signal Menu A test utility that displays the signal quality between the MX3-CE and the connected access point. AP Menu To connect to the host, select an access point from the list.
Page 82: Taskbar
When the taskbar is auto hidden, press the Ctrl key then the Esc key to make the Start button appear. Figure 4-3 Taskbar Properties Clear Contents of Document Folder Select the Start | Settings | Taskbar | Start Menu tab and tap the Clear button to remove the contents of the Document folder. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 83: Proxim Radio Options (From Taskbar)
PC card goes to sleep. To minimize draw on the vehicle battery, set this to 0. Roam Config Normal Sets the roaming speed. Slow, Normal or Fast About Displays radio card software version number, ROM version and contact information for Proxim Inc. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 84: About
Network Set network driver properties and network access properties. Owner Set MX3-CE owner details. Password Set MX3-CE access password properties. Power Set Power Off, Backlight, Blanking properties. Review battery status and perform backup battery charging/discharging. Regional Settings Set appearance of numbers, currency, time and date based on regional and language settings.
Page 85: Communication
Adjust the settings and click the OK box to save the changes. The changes take effect immediately. PC Connection Please refer to the "Backup MX3-CE Files" section later in this chapter for parameter setting recommendations. Figure 4-5 Communication / PC Connection Tab...
Page 86: Date/Time
Enabled Idle Time 2 minutes Background There is no change from general desktop PC Display Properties / Background options. Adjust the settings and click the OK box to save the changes. The changes take effect immediately. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 87: Appearance
Blank after of continuous idle time. Figure 4-8 Display Properties / Blanking Tab Adjust the settings and click the OK box to save the changes. The changes take effect immediately. This option is also available in Power. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 88: Keyboard
Delay Short Rate Slow Figure 4-9 Keyboard Properties There is no change from general desktop PC Keyboard Properties options. Adjust the settings and click the OK box to save the changes. The changes take effect immediately. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 89: Network
After changing radio card adapter parameters, and when prompted, the radio card must be removed from the MX3-CE slot, pause for three seconds and reinsert the radio card in the MX3- CE. The new radio parameters will then be in effect.
Page 90: Owner
OK box to save the changes. The password is immediately in effect. Password Properties Password Settings Password Password: Confirm Password: At Power On Enable password protection Figure 4-13 Password Properties MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 91: Power
Figure 4-14 Power Properties / Power Off Tab There is no change from general desktop PC Power Properties options. Adjust the settings and click the OK box to save the changes. The changes take effect immediately. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 92: Backlight
This option presents the Voltage and Status of the Main and Backup batteries. The option to charge and discharge the backup battery is available on this Power Properties | Charge tab. Once the backup battery is completely discharged, the MX3-CE automatically begins the Recharge process.
Page 93: Scanner
Adjust the settings and click the OK box to save the changes. The changes take effect immediately. The Scan buttons have no effect on tethered external scanners connected to a serial port on the MX3-CE or the MX3 cradle ports. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 94: Keys
Adjust the settings and click the OK box to save the changes. The changes take effect immediately. The COM 1 display contains the same parameters as the COM 2 and COM 3 Tab. Adjust the settings and click the OK box to save the changes. The changes take effect immediately. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 95: Stylus
There is no change from general desktop PC Mouse / Double Tap Properties display. Follow the instructions on the screen and click the OK box to save the changes. The changes take effect immediately. Calibration Figure 4-18 Stylus Properties / Recalibration Start Figure 4-19 Stylus Properties / Recalibration E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 96: System
Figure 4-21 System Properties / Memory Tab There is no change from general desktop PC System Properties / Memory options. Adjust the settings and click the OK box to save the changes. The changes take effect immediately. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 97: Volume And Sound
Key 1 alpha Card Power Management Select the Profile, adjust the settings on the following screens and click the OK box to save the changes. Help is available by clicking the question mark in the edit window. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 98: Backup Mx3-Ce Files
The default is 57600 baud. This will set up the MX3-CE to use COM 1. If the MX3-CE has a dual-serial port endcap, the Serial 3 @ 115200 can also be selected. Click OK and ensure the check box for "Allow connection with desktop computer when device is attached"...
Page 99: Irda Connection
Select Start | Control Panel | Communications | PC Connection. Click the Change button. From the popup list, choose This will set up the MX3-CE to use the USB port. Click OK and ensure the check box for "Allow connection with desktop computer when device is attached" is checked.
Page 100: Explore
From the ActiveSync dialog, click on the Explore button, which allows you to explore the MX3- CE from the PC side, with some limitations. You can copy files to or from the MX3-CE by drag- and-drop. You will not be allowed to delete files or copy files out of the \Windows directory on the MX3-CE.
Page 101: Troubleshooting
Backup MX3-CE Files Troubleshooting ActiveSync on the host says that a device is trying to connect, but it cannot identify it One or more control lines are not connected. This is usually a cable problem, but on a laptop or other device, it may indicate a bad serial port.
Page 102: Create A Communication Option
Backup MX3-CE Files Create a Communication Option 1. On the MX3-CE, select Start | Programs | Communication | Remote Networking. A window is displayed showing the existing connections. 2. Assuming the one you want does not exist, double-click Make New Connection.
Page 103: Technical Specifications - Connection Cable
Backup MX3-CE Files Technical Specifications – Connection Cable The exact serial cable is crucial. Many commercial null modem cables will not work. LXE recommends the following cable: Serial cable: 9000A054CBL6D9D9 Pinout: DB9 female DB9 female no connection Figure 4-23 Pinout – Serial Cable for Synchronization Some laptop devices do not properly implement all control lines on the serial port –...
Page 104: Mx3-Ce Utilities
The registry information needed is under the key HKEY_LOCAL_MACHINE \ SOFTWARE \ LXE \ Persist, as follows. The main subkey is any text, and is a description of the file. Then 3 values are added: FileName is the name of the CAB file, with the path (usually \IPSM) Installed is a DWORD value of 0, which changes to 1 once auto-launch installs the file FileCheck is the name of a file to look for to determine if the CAB file is installed.
Page 105: Pregedit.exe
See REGSAVE for details on the process of saving the registry. WAVPLAY.EXE Double-tapping a sound file (e.g. WAV) causes WavPlay to open the file and run it in the background. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 106: Mx3-Ce Command-Line Utilities
"...clearing settings...", and at completion it displays a dialog box if the procedure fails. Note that to return your MX3-CE completely to factory defaults, you must perform RegClear to erase the stored settings, followed by ColdBoot, to erase settings stored in DRAM.
Page 107: Appendixa Key Maps
Appendix A Key Maps MX3-CE Keypad Note: This key mapping is used on hand held computers that are NOT running an LXE Terminal Emulator. When using a sequence of keys that includes the 2 key, press the 2 key first then the rest of the key sequence.
Page 108 Appendix A Key Maps Press These Keys and Then To get this key Press this key Shift Ctrl CapsLock Delete Home Left Arrow Right Arrow Page Up Up Arrow Page Down Down Arrow ScrollLock MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 109 Appendix A Key Maps Press These Keys and Then To get this key Press this key Shift Ctrl CapsLock E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 110 Appendix A Key Maps Press These Keys and Then To get this key Press this key Shift Ctrl CapsLock < > : (colon) ; (semicolon) _ (underscore) , (comma) ‘ (apostrophe) ~ (tilde) “ MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 111 Appendix A Key Maps Press These Keys and Then To get this key Press this key Shift Ctrl CapsLock & E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 112 Appendix A Key Maps MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 113: Appendixb Technical Specifications
COM 3) printer. Endcap - incl Scanner (COM 3), 9 Pin “D” (male) Connector. Provides DA-9 or DB-9 Connector (COM connection to external devices such as a printer. Endcap – incl Scanner (COM 3), DA-9 (COM 1) E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 114: Display Specifications
640x240 pixels Size ½ VGA landscape Diagonal Viewing Area 5.92 in (150.4mm) Dot Pitch 0.22mm Dot Size 0.20mm x 0.20mm Color Scale Monochrome - 16 Shades of Gray Transmissive – 256 colors Transflective – 256 colors MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 115: Environmental Specifications
Appendix B Technical Specifications Environmental Specifications MX3-CE and Endcaps Feature Specification Operating Temperature -4°F to 122°F (-20°C to 50°C) monochrome -2°F to 122°F (-10°C to 50°C) color Storage Temperature -22°F to 158°F (-30°C to 70°C) Water and Dust IEC IP65 (with standard endcaps) Operating Humidity Up to 90% non-condensing at 104°F (40°C)
Page 116: International Ac Adapter
2.4 - 2.4835 GHz FH SS RF Data Rates 0.8 / 1.6 Mbps RF Power Level 100 mW (varies by country) Channels Operating Temperature see MX3-CE Environmental Specs Storage Temperature see MX3-CE Environmental Specs Connectivity TCP/IP, Ethernet, NDIS Antenna Internal...
Page 117: Pcmcia Lucent 2.4 Ghz Type Ii
1 / 2 Mbps RF Power Level 100 mW nominal (varies by country) Channels 11 US, 13 Europe, 4 France, 1 Japan Operating Temperature see MX3-CE Environmental Specs Storage Temperature see MX3-CE Environmental Specs Connectivity NDIS, TCP/IP, Ethernet Antenna Internal PCMCIA Cisco 2.4GHz Type II...
Page 118 Appendix B Technical Specifications MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 119: Appendixc Api Calls
Appendix C API Calls Introduction This appendix documents only the LXE-specific API calls for the MX3-CE. It is intended as an appendix to the standard Microsoft Windows CE API documentation. Details of many of the calls in this appendix to the MX3-CE Reference Guide may be found in Microsoft’s documentation.
Page 120: Lxebatterydischargebackup
This value reflects the distance between fully charged (100%) and discharged to the critically low voltage trip point (0%). This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 121: Pcmcia Api
The card is then detected by the PCMCIA driver and power restored to the slot, restoring the card to normal operation. This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 122: Lxepcmciawriteprotect
This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 123: Power Management Api
This function generates a system event which causes the power management driver to start handling backlight on/off timing and events normally, usually after a BacklightAlwaysOn command, below. This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 124: Lxepowermgrbacklighton
This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 125: Lxepowermgrprimaryevents
The values within the bitmask are given above, under LXEPowerMgrPrimaryEvents. This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 126: Lxeforcepowerkeyprimaryevent
Note that this event has no effect on the computer going into suspend, only the display / backlight controls. This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 127: Scanner Api
LXEScannerStop API call (below) is executed. This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 128: Lxescannergetstatus
Scanner control panel. This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 129: Lxescannerkeystatus
Using this call on any other port returns an error. This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 130: Lxescannerattachport
The function then generates the event necessary to cause the driver to reload its registry information, so that the new value takes effect immediately. This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 131: Lxescannersetserial
This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 132: Lxescannersetwindow
This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. Note: WM_LXE_SCANFULL is an updated replacement for WM_LXE_SCANDONE. WM_LXE_SCANDONE is retained in this API for backwards compatibility. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 133: Serial Ports Api
Serial Ports API For the most part, all of the standard Win32 API calls for serial ports will work on the MX3-CE serial ports. If the scanner wedge is running, it will lock the ports it is configured to monitor, and will prevent those from being opened, since Windows CE lacks the ability to share serial ports.
Page 134: Version Control Api
This function will return the version number of the OAL code and OS image, and format the number into a string like: MX3-CE vn.n.n ARM SA1100 04/01/2002 12:35 The date and time specified are the actual date and time that the OAL was compiled. The space for this string may be allocated using the global value from LXEAPI.h, as follows:...
Page 135: Lxeversionfpga
This function will return the version number of the API library, and format the number into a string like: MX3-CE xxxxxxxxxx ARM SA1100 04/01/2002 12:35 The date and time specified are the actual date and time that the API was compiled. The space for this string may be allocated using the global value from LXEAPI.h, as follows:...
Page 136: Lxeinfogetcpuinfo
OsBase and OsSize return the base address and allocated size for the operating system image partition of flash. RegistryBase and RegistrySize return the base address and allocated size for the Persistent Memory registry configuration backup partition. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 137: Lxeinfogetraminfo
0. VirtualSize and VirtualFree return the total size and bytes free values for virtual memory. This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 138: Lxeinfogetuuid
The space for this string may be allocated using the global value from LXEAPI.h, as follows: Char UUIDString[GUID_STRSIZE] This function returns 0 on error, or 1 on success. GetLastError() may be used to get a detailed error message. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 139: Miscellaneous Api
Note that it is up to the application making this call to validate the usage of it, provide a warning, ask for a password, etc. Calling this function arbitrarily can result in loss of data, requiring a lot of time to correct. This function returns 0 on error, or 1 on success. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 140: Lxeshowtaskbar
Convenience function to show or hide the taskbar, similar to PocketPC. Flag is SW_SHOW or SW_HIDE, like standard Win32 API calls. HIDE must occur before main app window is created (right after RegisterClass(), or similar) SHOW should happen right before PostQuitMessage() MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 141: Reflash The Mx3-Ce
When reflashing, LXE recommends using a Compact Flash card that is greater than 16MB. 1. Remove the endcap from the MX3-CE being very careful not to damage the leads to the external power jack, the headphone jack or the antenna. The antenna may be taped to the endcap so great care must be taken when removing the endcap.
Page 142: Clearing Persistent Storage
Remove compact flash card to reboot The computer will then startup with the new image. There may be a pause at the bootup screen for an extra 10-15 seconds while the persistent storage drive reformats itself. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 143: Appendixd App Lock
MX3-CE user. AppLock also contains a component which sets configuration parameters as specified by the Administrator. If the MX3-CE is reset to factory default values, the Administrator may need to reconfigure the AppLock application. Note: To reset an MX3-CE to factory default values, please refer to Chapter 4 “System Configuration”...
Page 144: Administration Mode
End-user mode locks the end-user into the configured application. The end user can still reboot and respond to dialog boxes. The single application is automatically launched, and runs in full screen mode, when the MX3-CE boots up. The user cannot unintentionally or intentionally exit the application nor can the end user execute any other applications.
Page 145: Administration And Configuration
Command Line: Administrator Control panel Use the Control tab options to select the application to launch when the MX3-CE boots up. Move the cursor to the Application text box and either type the application path or click the Browse icon (the … icon). The standard Windows CE Browse dialog is displayed. After selecting the application from the Browse dialog, click OK.
Page 146: End User Internet Explorer
For example, if the ‘Ctrl’ key is pressed followed by ‘A’, “Ctrl+A” is entered in the text box. If another key is pressed after a normal key press, the hotkey sequence is cleared and a new hotkey sequence is started. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 147 If they do not match, a dialog box is displayed notifying the user of the error. After the user closes the dialog box, the Security Panel is displayed and the password can then be entered and confirmed again. If the passwords match, the password is encrypted and saved. See Also: Passwords E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 148: Status Panel
Process Processing status shows the flow control of AppLock components and is mainly intended for LXE Customer Service when helping customers troubleshoot problems with their AppLock program. Extended Extended status provides more detailed information than that logged by Process Logging.
Page 149: Passwords
To summarize, if an error occurs that prevents AppLock from switching to user mode, the password will not timeout and AppLock will wait until the correct password is entered. Troubleshooting Forgotten the password that has been set? Enter this LXE back door key sequence: Ctrl+L Ctrl+X Ctrl+E E-EQ-MX3CERG-E...
Page 150: Error Messages
\Windows directory and reboot the unit. Deleting applock.exe triggers the applock system to reload. Address of keyboard hook Applock successfully retrieved the address of the LOG_EX procedure OK keyboard filter initialization procedure. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 151 Unable to decrypt password. LOG_ERROR Decrypt acquired context OK Decryption process ok. LOG_EX Decrypt create hash failure Unable to decrypt password. LOG_ERROR Decrypt created hash OK Decryption process ok. LOG_EX Decrypt failure Unable to decrypt password. LOG_ERROR E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 152 AppLock launches the application and has to wait until it has created and initialized its main window. This message is logged when the function that waits for the application initialization is entered. Enter DecryptPwd Entering the password decryption process. LOG_PROCESSING MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 153 Processing is at the end of the function that retrieved the LOG_PROCESSING application information from the registry. Exit password dialog Exiting password prompt processing. LOG_PROCESSING Exit password dialog-cancel Exiting password prompt w/cancel. LOG_PROCESSING Exit password dialog-OK Exiting password prompt successfully. LOG_PROCESSING E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 154 Processing the hotkey and backdoor entry LOG_EX Hot key set event failure When the administrator changes the hotkey LOG_ERROR configuration the hotkey controller must be notified. This notification failed. Hotkey press message received The user just pressed the configured hotkey. LOG_PROCESSING MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 155 The keyboard hook uses an embedded default if the value is not set in the registry. Read registry failure-app name AppName registry value does not exist or is empty. LOG_ERROR This constitutes a failure for switching into user mode. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 156 The taskbar is now being made visible and enabled. LOG_PROCESSING Switching to admin-backdoor The system is currently in user mode and is now LOG_PROCESSING switching to admin mode. The switch occurred because of the backdoor key presses were entered by the administrator. MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 157 If user mode is being entered via a hotkey press, the LOG_EX line change administrator may have left the configured application open. If so, AppLock does not launch the application again unless a new application or command line has been specified; otherwise, it just locks it. E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 158 The window handle that is passed to the enumeration LOG_EX enumwindows=%x function. This message can be used by engineering with other development tools to trouble shoot application lock failures. WM_WINDOWPOSCHG Output the window size after it has been adjusted by LOG_EX adjusted=%x AppLock MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 159: Applock Registry Settings
Appendix D AppLock AppLock Registry Settings This system application runs at startup via the “launch” feature of LXE Windows CE devices. When the launch feature is installed on the device, the following registry settings are created. The launch feature registry settings are embedded in the MX3-CE OS image: HKEY_LOCAL_MACHINE\\Software\\LXE\\Persist\\Filename=AppLock.exe...
Page 160 Appendix D AppLock MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 161: Index
Top..............2, 21 Barcode Components, Location.......... 2 Data Entry ............26 Connect............... 64 Barcode Scanner Connect Using ............ 73 Integrated ............40 Control Panel options ......... 72 Tethered ............40 Controls, Physical..........39 Batteries ............102 E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 162 External Connectors/Interface ......101 Hot Swapping Main Battery ....... 54 External Power ........... 79 Hot-swapping and Critical Suspend Mode..31 External Power Supplies........13 How To Radio Card ............25 HyperTerminal ........... 89 Factory Default Settings MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 163 SCNR function..........29, 47 Orinoco Client ............ 67 SHFT function ..........29, 47 Owner ..............72 STAT function ..........29, 47 Left ..............81 Li-Ion 1400 mAh ............37 Lithium-Ion (Li-Ion)........... 53 Parameters Location, Components........ 2, 3, 21 NET.CFG E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 164 WW AC to DC..........104 Storing PC Cards ..........24 Radio Specifications stylus..............8 2.4 GHz............105 Stylus ..........8, 26, 48, 72 Rate..............76 Suspend Mode ............ 30 Reboot..............39 Suspend Timer............ 79 Recalibrate ............15 Symbol Client............. 68 MX3-CE Reference Guide E-EQ-MX3CERG-E...
Page 165 When to use this guide ......... 3 Type II radio ............25 WHOAMI.EXE ..........94 WinCE on-line Help ........... 59 Windows 95 SR2..........86 Windows Explorer..........69 User Name ............77 Wireless .............. 72 Word Pocket ............... 66 E-EQ-MX3CERG-E MX3-CE Reference Guide...
Page 166 Index MX3-CE Reference Guide E-EQ-MX3CERG-E...

LXE MX3-CE Reference Manual

Chapter 1 Introduction

Chapter 2 Physical Description and Layout

Chapter 3 Power Supply

Chapter 4 System Configuration

Appendix A Key Maps

Appendix B Technical Specifications

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for LXE MX3-CE

Summary of Contents for LXE MX3-CE

Table of Contents
