Summary of Contents for NZXT DUET

  • Page 1 Duet U se r’s m a n u a l...
  • Page 3 Dear Valued Customers, Thank you for purchasing our product. With the booming of the gaming market and computer cases, NZXT would like to differentiate ourselves from other case companies by continuously providing innovative next generation cases. With every product, we hope to break more boundaries and limits.
  • Page 4 Duet Specifications Features Aluminum plated front panel Small and compact design Dual positioning, vertical or horizontal depending on home setup Dual use vents for cooling or expandability, Install dual 120mm fan capability or dual hard drives Usb 2.0, Firewire, Intel HD audio and mic support...
  • Page 5: Before Beginning

    Thank you. Removing the front and side panels The NZXT Duet front and side panels needs to be removed when installing devices and fans. Please follow the steps below to remove the panels. 1. With the panel facing forward, use one hand to hold the case in place.
  • Page 6: Motherboard Installation

    Pull the panel to remove. Unscrewing the side panel Pull the side panel to remove it Motherboard Installation The NZXT Duet supports the following motherboard: ATX and MICRO ATX. The Index for the standoff holes are as follows. ( NZXT. 4...
  • Page 7 ) 5. Place your motherboard on top of the brass standoffs and attach it to the tray using screws provided. LED, Speaker, Power and Reset Installation NZXT. 5...
  • Page 8 (Green/White, +/-) 5. Connect the 2 power LED, a four pin Molex connector to the power supply. All White and Black Pin Connectors correspond to ground USB & Audio Installation The Reset button is located inside the door NZXT. 6...
  • Page 9 1. Please first refer to your motherboard manual and match the labels on the audio port connectors on the case with your motherboard. 2. The green input is the speaker input and the pink input is the microphone input, these inputs are located behind the small panel. NZXT. 7...
  • Page 10 Front Right Channel Audio Signal Line out_R BLINE Line L-RET Rear Left Channel Audio Signal out_L BLINE Line R-RET Rear Right Channel Audio Signal out_R ASUS© Motherboard Pin Assignment Twist the Copper standoff to attach it onto the motherboard tray NZXT. 8...
  • Page 11: Power Supply Installation

    Power Supply Installation The power supply is installed at the front of the chassis, please remove with the top panel and front panel before proceeding. 1. Slide in the power from inside the case. NZXT. 9...
  • Page 12 3. Remove the metallic plate. ( warning – edges are sharp and can be harmful. Please use gloves and tools to remove ) 4. Attach the rails to the two sides of the device. If the rails do not fit, use screws to manually attach the rails. NZXT. 10...
  • Page 13 U se a scre w d rive r to m a n u a lly attach i f th e 5 .2 5 ” d e vi c e i s n o t c o m p a ti b le A ttach i n g th e 5 .2 5 ” d e vi c e NZXT. 11...
  • Page 14 P l e a se fol l o w th e d i re cti o n s b e l o w to i n sta l l th e i n te rn al 3 .5 ” d evi ce s: 1. Slide the device in from the inside of the case. NZXT. 12...
  • Page 15 P l e a se fol l o w th e d i re cti o n s b e l o w to i n sta l l th e i n te rn al 3 .5 ” d evi ce s: Line up the fan or hard drive holes with the vent and secure it from the outside. NZXT. 13...
  • Page 16 Front Fan Installation Front Fan Installation 1. Begin the installation process by removing the bottom panel. 2. Unscrew the single screws on the fan cage 3. Take the 80mm fan and snap it into the cage. Remove the cage. NZXT. 14...
  • Page 17 Snap the fan onto the cage. Secure the fan onto the cage with’ fan screws ( not included with the case ) NZXT. 15...
  • Page 18: Support And Service

    You may inquire about replacement parts at rma@nzxt.com. Thank you again for purchasing an NZXT case. If you have any more comments or questions. Please visit our website or send us an email.
