❑ Is the master volume turned down? Set the function selector to
[PROGRAM], and turn the value knob to adjust the master vol-
ume.
3. Effects don't apply
❑ Could an effect be bypassed?
❑ Is the modulation "DEPTH" or the delay/reverb "MIX" set to a low
value?
❑ Could the [MIC&BODY] DEPTH be set to 0?
❑ Is the AX3A in Bypass mode? Refer to "Bypass and Mute" (p.10)
and cancel the Bypass function.
4. High frequencies are distorted when using [MIC&BODY]
❑ Depending on the guitar you're using, the high frequencies may
distort if the [TONE] TREBLE or XCITER effect parameter val-
ues are raised excessively. If this occurs, lower the settings.
5. Sound connected to the guitar amp is distorted, or sounds
wrong
❑ Could the [TONE] values or the PROGRAM LEVEL (LEVEL/NR/
NOTCH) be excessively high?
12

Specifications

Number of effects:
Number of programs:
Audio input:
Audio output:
Signal processing:
Sampling frequency:
Tuner:
Calibration:
Power supply:
Dimensions (W ✕ D ✕ H):
Weight:
Included items:
Options (separately sold):
* Specifications and appearance are subject to change without notice for improve-
ment.
Pre-effect types: 10
Mic&Body Model types: 10
Tone: 1
Notch Filter: 1
Modulation Effect types: 10
Delay Effect types: 5
Reverb Effect types: 5
Noise Reduction: 1
80 (40 user/40 preset)
INPUT (mono)
OUTPUT (stereo)
A/D conversion: 24 bit
D/A conversion: 24-bit
31.25 kHz
Detection range : C1–E6
A=438–445 Hz
Four alkaline AA batteries (continuous use
of eight hours) or DC9V (separately sold)
AC adapter
178 ✕ 142 ✕ 43 mm /
7.0 ✕ 5.6 ✕ 1.7 inches
340 g / 11.99 oz.
Owner's manual
DC9V AC adapter
EXP-2 foot controller
XVP-10 expression/volume pedal
