❑ Are the DRIVE/AMP or PROGRAM LEVEL (LEVEL/NR/CAB) pa-
rameters be turned to a low value?
❑ Is the volume turned down for another effect?
❑ If an expression pedal is connected, is it turned down?
❑ Is the Mute function activated? Refer to "Bypass and Mute" (p.9)
and cancel the Mute function.
❑ Is the master volume turned down? Set the function selector to
[PROGRAM], and turn the value knob to adjust the master vol-
ume.
3. Effects don't apply
❑ Could an effect be bypassed?
❑ Is the modulation "DEPTH" or the delay/reverb "MIX" set to a low
value?
❑ Is the AX3B in Bypass mode? Refer to "Bypass and Mute" (p.9)
and cancel the Bypass function.
4. Sound connected to the guitar amp is distorted, or sounds
wrong
❑ Is the DRIVE/AMP [VOLUME] setting or the PROGRAM LEVEL
(LEVEL/NR/CAB) [LEVEL] setting raised excessively?

Specifications

Number of effects: Pre-effect types: 10
Drive/Amp Model types: 16
Cabinet Model types: 10
Modulation Effect types: 10
Delay Effect types: 5
Reverb Effect types: 5
Noise Reduction: 1
Number of programs: 80 (40 user/40 preset)
Audio input: INPUT (mono)
Audio output: OUTPUT (stereo)
Signal processing: A/D conversion: 24 bit
D/A conversion: 24-bit
Sampling frequency: 31.25 kHz
Tuner: Detection range : C0–C6
Calibration: A=438–445 Hz
Power supply: Four alkaline AA batteries (continuous use
of eight hours) or DC9V (separately sold)
AC adaptor
Dimensions (W ✕ D ✕ H): 178 ✕ 142 ✕ 43 mm /
7.0 ✕ 5.6 ✕ 1.7 inches
Weight: 340 g / 11.99 oz.
Included items: Owner's manual
Options (separately sold):
EXP-2 foot controller
XVP-10 expression/volume pedal
* Specifications and appearance are subject to change without notice for improve-
ment.
AX3B Owner's manual
DC9V AC adaptor
