Axminster Reference No: AW422J
W
A X M I N S T E R
W H I T E
Axminster Devon EX13 5PH UK
FREEPHONE 0800 371822
www.axminster.co.uk
2000
10-22mm Narrow
Crown Stapler
Axminster Reference No: AW422J
2000
w w w. a x m i n s t e r. c o . u k
W
A X M I N S T E R
W H I T E
Advertisement
Related Manuals for Axminster AW422J
Summary of Contents for Axminster AW422J
- Page 1 10-22mm Narrow Crown Stapler Axminster Reference No: AW422J A X M I N S T E R W H I T E Axminster Devon EX13 5PH UK FREEPHONE 0800 371822 A X M I N S T E R Axminster Reference No: AW422J...
- Page 2 Illustrated Parts List... Index of Contents... A X M I N S T E R W H I T E P P a a g g e e N N o o . . Index of Contents.......................... 02 Declaration of Conformity………….………..……..…………..........03 What’s in the Box………….………..……..…………..............04 General Instructions and Recommendations whilst using Air Equipment....................
-
Page 3: Illustrated Parts Breakdown
107 Jienan Street Banan District Chong Qing, China declares that this product: Airnailer 422J manufactured by Chong Qing Hong Yuan Pneumatic Tool Factory is in compliance with the following standards or standardisation documents in accordance with Council Directives 98/37/EG / 98/37/EC 0800 371822 www.axminster.co.uk FREEPHONE... - Page 4 1.Worn bumper. 1.Replace bumper. fastener too deeply equipment list ”What's in the box”, if there are any discrepancies, please contact Axminster 2.Air pressure is too high. 2.Adjust the air pressure. Power Tool Centre using the procedures laid down in the catalogue. Please dispose of the packaging responsibly;...
- Page 5 Using your Air Stapler... General Safety Instructions and Recommendations whilst using Air Equipment... A X M I N S T E R A X M I N S T E R W H I T E W H I T E Using the Oil supplied in the small oiler bottle, put 2-3 drops into the air connector.
-
Page 6: Basic Installation
General Safety Instructions and Recommendations Illustration and Description of the Stapler... whilst using Air Equipment... A X M I N S T E R A X M I N S T E R W H I T E W H I T E Check that cutters, drills, chisels etc., are the correct type and size, are undamaged and are kept Push Latch down clean and sharp, this will maintain their operating performance and lessen the loading on the tool. - Page 7 Illustration and Description of the Stapler... General Safety Instructions and Recommendations whilst using Air Equipment... A X M I N S T E R A X M I N S T E R W H I T E W H I T E Air pulse divertor Main body Quick release...
- Page 8 Axminster No. 600515 (AW422J) Part of the slide plate mechanism is a sprung shoe that pushes against the staples in the magazine tray and forces them into the receiver in the guide body.
