Summary of Contents for Sinovision HDE02A
-
Page 1: User Manual
USER MANUAL 3D HDMI Extender 60M over single Cat5E/6 HDE02A... - Page 2 Dear customer, Thank you for purchasing this product. For optimum performance and safety, please carefully read these instructions before use this product. Please keep this manual for future reference. 1.0 INTRODUCTION This HDMI Extender by uses one piece of CAT-6 Lan cable to extend the HDTV display up to 60M(Max) for 3D 1080P/60Hz.
-
Page 3: Package Contents
l Frequency ………………………………………………………………………….. 24/50/60Hz l Product dimensions(LxWxH)……………………………………………………. 82x45x21mm l Product net weight………………………………………………………………………… 0.3kg l Operating temperature range…………………………………………………….. 0℃ to +70℃ l Operating humidity range…………………………………10% to 85 % RH (no condensation) l Power adapter…………………………………………………………………………..5V DC /1A l Power (Max)…………………………………..............5W Note: 1: In order to achieve the high transmission quality, please choose the shielded CAT-6 cable. - Page 4 6.0 CONNECTION DIAGRAM...
