Page 1: User Manual
HDMI Extender by TCP/IP USER MANUAL HDMI Extender over Single UTP 120M HDE01X... -
Page 2: Specifications
HDMI Extender by TCP/IP HMDI Extender by TCP/IP Dear curtomer Thank you for purchasing this product. For optimum performace and safety,please read these instructions carefully before connecting,operating or adjusting this product.Please keep this manual for future reference. 1.0 INTRODUCTION HDMI Extender by TCP/IP is base on TCP/IP standard .It extends your HD display with the resolutions of 1080p/60Hz up to 395feets (120 meters)away from your HDMI or DVI-D source by using one CAT5e/6 cable. -
Page 3: Package Contents
HDMI Extender by TCP/IP Mechanical Size(L-W-H) 103X100X24mm Weight(Net) 800g Environmental Operating Temperature 0 °C-70°C Operation Humidity 10%-85%RH(no condensation) Storage Temperature -10 °C+80°C Storage Humidity 5%-90%RH(no condensation) Power Requirement External Power Supply DC 5V@1A x2 Power consumption(Max) 2.5W Accessories Adapter Use manual English Version 3.0 PACKAGE CONTENTS Before attempting to use this unit, please check the packaging and make sure the following... - Page 4 HDMI Extender by TCP/IP 1:DC5V Power supply for sender 2:IR IR extender input 3:LED Power Led display 4:HDMI IN HDMI input port connect HMI source to this port 5:RS232 RS232 input port 6:CAT Out Connect the sender to the receiver or Ethernet router or hub by using a Cat5E/6 cable Receiver...
-
Page 5: Connection And Operation
HDMI Extender by TCP/IP 1:DC5V Power supply for receiver 2:IR IR extender output 3:LED Power Led display 4:HDMI out HDMI out port connect HMI sink device to this port 5:RS232 RS232 output port 6:CAT in Connect the Receiver to the Sender or Ethernet router or hub by using a Cat5E/6 cable 5.0 Connection and Operation 1) Connect the HDMI source (such as DVD,PS3,STB)to the HDMI IN of the Sender 2) Connect the HDMI out of receiver to HDTV display... -
Page 6: Connection Diagram
HDMI Extender by TCP/IP 2)Operation: Note: The RS232 commands can be sent from TX to RX or RX to TX are both available. a) From Sender(TX) send data to Reviver(RX): First write Receiver IP address (192.168.168.56), HEX format C0 A8 A8 38, then write your data (ASCII CODE), and then press “send”...
