Page 1: User Manual
USER MANUAL HDMI Over Ethernet HDE01X 1、Introduction 2、Specifications 3、Package Contents 4、Panel Descriptions 5、 Connection and operation 6、 Application diagram... -
Page 2: Package Contents
1、Introduction HDMI Over Ethernet is based on TCP/IP standard. It transmit your HD display with the high resolutions up to 395 feet (120 meters) away from your HDMI or DVI-D source by using one CAT5e/6 cable. With the advantage of TCP/IP standard，you can extend your HD video to multiple displays by using an Ethernet Switch. - Page 3 4、 Panel Descriptions HDMI Sender 5V/1A Supply power for the Sender RESET Hold down the key for 10 seconds, the model will Restore the default setting IR-OUT Connect IR transmitter to this Port. HDMI - IN Connect HDMI Source to this Port. STATUS When system start up, the Green LED will be on，When transmit video, the led will blink.
- Page 4 5、Connection and operation 1) Connect the HDMI source (such as DVD, PS3, STB ) to the HDMI IN of Sender. 2) Connect the IR sender to the Sender IR OUT Port, and Be Directed at HDMI video source’s IR receiver. 3) Connect the HDMI out of Receiver to HDTV display.
