PagePro 1350W
Technical guide
www.konicaminolta.com/printer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PagePro 1350W and is the answer not in the manual?

Questions and answers

Related Manuals for Konica Minolta PagePro 1350W

Summary of Contents for Konica Minolta PagePro 1350W

  • Page 1 Sales Guide PagePro 1350W Technical guide www.konicaminolta.com/printer...
  • Page 2 Trademark Statement All rights reserved. Specifications are subject to change without notice. The Konica Minolta logos, used trademarks, are trademarks or registered trademarks of Konica Minolta Holdings, Inc. All other trademarks or registered trademarks are the property of their respective owners or manufacturers.

  • Page 3: Table Of Contents

    Duty cycle Print speeds First page out time Physical dimensions Operating environment conditions Printer memory Host computer requirements Print media Non-printable regions Supported media sizes Paper path Printer driver Status Display Printer control panel Cancel button Toner cartridge OPC drum cartridge...

  • Page 4: Introduction

    The PagePro 1350W is a compact yet very fast personal laser printer. At 20 pages per minute, this printer rivals the speed and print quality of much larger laser printers that customers may have used in the past.

  • Page 5: Specs At A Glance

    An overview of the PagePro 1350W printer features The PagePro 1350W is based on the Minolta NC-L701L laser printer engine. The engine features selectable resolutions of 600 x 600, 1200 x 600, and 1200 x 1200 dpi. (At 1200 x 1200 dpi, the print speed reduces by approximately half.)

  • Page 6: Engine

    PagePro 1350W print engine. The PagePro 1350W is based on the Minolta NC-L701L laser printer engine. The engine features selectable resolutions of 600 x 600, 1200 x 600, and 1200 x 1200 dpi. (At 1200 x 1200 dpi, the print speed reduces by approximately half.)

  • Page 7: Physical Dimensions

    Physical dimensions Packaging Width Depth 496 mm (19.5”) 396 mm (15.6”) Printer (multipurpose tray extended) Width Depth 386.8 mm (15.2”) 405 mm (15.9”) Weight Shipping 9.3 kg (20.5 lbs) Printer w/ consumables 7.8 kg (17.2 lbs) Printer w/o consumables 7 kg (15.4 lbs)
  • Page 8 Clearance dimensions (side view) Clearance dimensions (top view)

  • Page 9: Controller

    Naltec N-1 ASIC for imaging the document. Printer memory The PagePro 1350W includes 8 MB of RAM on the controller. This memory is sufficient for printing all supported page sizes at all supported resolutions. There is no need for installing additional memory in the printer.

  • Page 10: Paper Handling

    The PagePro 1350W includes a 150-sheet multipurpose tray for paper and other print media. The tray accommodates all supported page sizes up to 216 mm x 356 mm. Print media The PagePro 1350W supports a range of print media to handle a variety of applications. Supported media Normal paper...

  • Page 11: Supported Media Sizes

    The PagePro 1350W’s design motto was “Easy to own, easier to use”. Supported media sizes The table at right refers to X and Y dimensions of the media as diagrammed above. Cut sheet x-dimension 210 mm B5 (JIS) 182 mm...

  • Page 12: Paper Path

    Paper path The PagePro 1350W handles both standard weight and thick stock through the paper path. Lift the printer’s rear cover to remove a paper jam.

  • Page 13: Printer Control

    CD-ROM shipped with the printer: Printer driver The driver for the PagePro 1350W is very easy to use – see below for descriptions of each tab. The PagePro 1350W features a tabbed layout that conforms to Microsoft standards making it very simple to understand.

  • Page 14: Status Display

    All paper handling settings are found under the “Paper” tab. Status Display The Status Display provides detailed information about the printer including current levels for consumables and explanations of any errors that may occur. The Status Display automatically establishes communication with the...

  • Page 15: Printer Control Panel

    Printer control panel The PagePro 1350W has two LEDs that indicate the status of the printer. Cancel button Press and hold the current job. In the event of a paper mismatch error (a paper size requested by the job is not loaded in the printer) or when manually duplex printing (using the PagePro 1350W driver), press the less than 5 seconds after reloading paper in the printer.

  • Page 16: Consumables

    Toner cartridge The PagePro 1350W includes a starter cartridge that holds enough toner for an average of 1,500 prints (5% coverage, A4-size, continuous printing). Two different replacement toner cartridges are available:...

  • Page 17: On-Line Support

    GLOBAL SITE Visit http://printer.konicaminolta.com/ for the latest news, updates and drivers for the PagePro 1350W, and information about other printers. PRODUCT CONFIGURATOR To configure your PagePro 1350W to suit your specific printing requirements, use our Product Configurator –...

  • Page 18: Information

    Konica Minolta Business Solutions Spain S.A. Tel: (+34) 91 327 73 00 Fax: (+34) 91 327 09 00 Sweden Konica Minolta Business Solutions Nordic AB Tel: (+46) 8 – 622 51 00 Fax: (+46) 8 – 622 51 24 Switzerland Konica Minolta Printing Solutions B.V.
