  • Page 2: Forword

    Forword This series product is specific on network video surveillance including wired box ip camera, wireless box ip camera, wired dome ip camera wired IR waterproof ip camera, etc. It uses processor with high-performance chips to realize audio/video capture, compression, transmission, and the standard Motion-JPEG coding algorithm can confirm the clear-fluent effect of video transmission.

  • Page 3: Table Of Contents

    Forword ............................- 1 - 2 Features ............................. - 3 - 3 Appearance and interface ......................- 5 - 3.1 Device appearance ......................- 5 - 3.2 Device interface ......................- 5 - 4 Network connection ........................- 6 - 4.1 Connection instruction ....................

  • Page 4: Features

    Product Overview IP Camera is designed as web server running on network, it can transmit real-time video to anywhere through internet, and user can view real-time live video via web browser any time. It is available to large stores, schools, factories, houses, etc. Basic function: IPCAM can transmit real-time live video data to remote place through internet with hardware compression method MJPE which providing high-quality video image and 25fps frame rate on LAN/WAN (local area network/wide area...
  • Page 5 ● support network protocols: HTTP/TCP/IP/UDP/STMP/DDNS/SNTP/DHCP/FTP Three-level account, password and user authority security management Built-in unique lifelong free DDNS，no need Oray，no Built-in ddns worry about frequent offline and good speed. Such as （free） http://demo.ipcam.hk, the series number is "demo" Mobile phone No need to install software，IE multi-view and System feature platform（free）...

  • Page 6: Appearance And Interface

    3 Appearance and interface 3.1 Device appearance Picture 1- device appearance 3.2 Device interface Picture 2- device interface DC 5V/2A ：external power adapter power 10/100M self-adaptable Ethernet interface，can connect to many network Ethernet interface： devices, such as hub, router, switch, etc. flickering when network connecting ：...

  • Page 7: Network Connection

    4 Network connection Picture 3- network connection guide 4.1 Connection instruction Connect camera to router and connect power adapter before accessing IP Camera， and check the network light and power light if it is normal, confirm the cable status is good.

  • Page 8: Connect Network Via Adsl

    computer-1 can access camera-1，then configure router-1（do port forwarding in router-1） ，to transfer the computer-2’s access apply to go through router-1 then to camera-1. Normally, computer-2 only can reach router-1 without port forwarding for camera-1. 4.3 Connect network via ADSL Connect camera to router through cable. Configure parameters via IP Camera tool (refer to: 5.1 IPcamera tool).

  • Page 9: Ipcamera Tool

    Software operation 5.1 IPcamera tool In picture 3，camera-1 and computer-1 are in different subnets，run Devfind.exe in CD，click search，then select searched IP Camera to modify the parameters，refer to picture 4. Picture 4- LAN configuration interface Note： the default parameters of camera: IP 192.168.1.126，port 81 Details：...

  • Page 10: Login Device

    5.2 Login device IPCAM can be accessed from “open” function in camera finder or directly by inputting access link (IP added port) via browser. The two sentences should be in ,same size,same font ,right? Picture 5 login interface MH3E-E-A2 - 9 -...

  • Page 11: Operations

    5.3 Operations Record: click Snapshot: click Listen: click ，it will change into ，then we can listen sound coming from camera terminal on computer monitoring interface, click again to disable the function. Talk: click ， it will change into ， then we can talk to camera terminal via headset on computer terminal.

  • Page 12: Basic Network Configuration

    5.4 Basic network configuration Basic network configuration IP address: it can support manually modifying IP, mask, gateway, DNS, etc. Http port: In most cases, the default port is 81. but if the current network limits the port, we should select other port ranged 0 to 65535, such as 8080，85，8888, etc. Picture 10- network parameters configuration Wireless network configuration The settings interface as picture 11，...

  • Page 13: Ddns Configuration

    5.5 DDNS configuration In picture 3，router-1 obtain wide area network IP address through ADSL，the IP address is dynamic，we could not know the real-time IP address of the device from internet，therefore，we need to obtain the address through DDNS server in internet， camera-1 will send message to the DDNS server for each defined-interval time，the DDNS server analyze the IP address of router-1 it connected，then we can obtain the IP address from DDNS server.

  • Page 14: E-Mail Service Configuration

    5.6 E-mail service configuration Picture 14- email service configuration The information in picture 14 is must，if some options are not correct，the settings would not work. Note: it is best test the settings in Outlook Express before configuration to confirm the settings working.

  • Page 15: Installation Steps

    Software condition: Windows2000/WindowsXP/Windows2003/Windows Vista/Windows 7，recommendation Windows XP Installation steps Double click installation package，it pops up as below: Select path then click “next”. After installation, it creates an icon on desktop as below: At program list as below: 6.3 Login and Logout MH3E-E-A2 - 14 -...

  • Page 16: Software Interface

    【Login】the default user is admin and no password，click “ok”to access software main interface. 【Logout】only admin authority can logout，user and guest authority can not It needs to input administrator user and password when logout. Software interface Software interface includes six blocks: 1 system button list 2 label list 3 devices list...
  • Page 17 Click to change to preview interface Click to change to playback interface Click to change to map operating interface Click to change to configuration interface Click to change to log operating interface Logout or change user Click to logout Devices list: ◆...

  • Page 18: Device Management

    Circle view button, single click to enable/disable Devices list fold/unfold button, click to fold/unfold Alarm information list fold/unfold button, click to fold/unfold 2.3 DEVICE MANAGEMENT 2.3.1 Add device Firstly click “Config” button on label list to access device management page. 6.5 Device management Add device Firstly click “Config”...
  • Page 19  b utton to add device to area. Add device manually: ◆ Click  b utton then pop up add device dialog, as below: 【Name】Device name, support custom, length less than 30 byte. Only display name instead of IP after input name. 【Channel】Support different channel on case that one device has many channels, presently device only supports one channel.

  • Page 20: Image Preview

    After add groups, configure groups Configuration: select group, click “+” in front of device IP or name, then select Channel 01, click button to add device channel to group. Notice: single group can support 16-picture view Add device channel to the group Remove the device channel from the group Adjust the order to display devices in the group, selected device exchanges position with the front device...
  • Page 21 1. Non-cycle preview Click “+” in front of device’s name or IP, then double click Channel 01 or drag Channel 01 to the window to view video. It displays a blue triangle after device connected Channel 01, if the display as , it means device does not connect.
  • Page 22 ： Connected All connect device in selected area 【 】 Disconnected All disconnect device in selected area 【 】 Arm All devices in selected area arm 【 】 Disarm All devices in selected area disarm 【 】 Start Manual Record of Area enable manual record in selected area 【...

  • Page 23: Ptz Control

    changes into label of disable-manual-record label. Main Stream connect device with main stream, on tick means current selection 【 】 is main stream. Sub Stream connect device with sub stream, on tick means current selection is 【 】 sub stream. Auto Adjust selected channel auto adjusts view proportion 【...
  • Page 24 Enlarge aperture, need device hardware support Narrow aperture, need device hardware support Enlarge focus, need device hardware support Narrow focus, need device hardware support Focus forward adjustment, need device hardware support Focus back adjustment, need device hardware support Light button, click to light on/off, need device support Wiper button, click to wiper on/off, need device support 2.5.2 Preset position configuration Client software supports 256 preset positions, for actual amount of preset...

  • Page 25: Video Management

    Goto preset position Select window to call preset position, then select preset 【 】 position number, click “Goto” button. Del preset position Select window to delete preset position, then select preset 【 】 position number, click “Del” button. 1. Image color configuration Click “Color”...
  • Page 26 record”, picture as above: enable plan record Select channel to record, then left click to drag out a green 【 】 box(the box range is the time to record). Click “Save” to finish. disable plan record Untick “Enable the plan of record”, then click “Save”. Or 【...
  • Page 27 default path is D:\. Note: Software can support 20 pieces of disk partitions. 1. Alarm Record Alarm Type: Motion Detection Alarm on motion detection 【 】 Input Alarm Alarm on external input signal 【 】 Lost Connect Alarm on lost connection 【...

  • Page 28: Playback

    Alarm Duration Time Alarm duration time, default is 10 seconds, selecting 【 】 range is 5-60 seconds. Pre-recorded alarm Length Pre-recording’s length on alarm, default is 5 【 】 seconds, selecting range is 1-15 seconds. Arm and Disarm Press “Preview”, select area or device for arming, after arming it will 【...
  • Page 29 Snapshot button; select windows then press this button for snapshot Enlarge button; press this button then select area for enlarging on windows Full screen button; press this button for full screen show, double click on single windows for one windows full screen Drop down options for selecting playing speed, default is normal Sound button;...

  • Page 30: Electron Map

    Step 1: select file type and device channel Step 2: select searching time then click “Search”, the eligible files should list on device tree Step 3: select playback windows then double click record file to view video, it can support one video displaying on four windows at the same time 6.10 Electron map 1.
  • Page 31 6.11 Parameters configuration To connect device for configuration on parameters configuration page (double click device channel, the image should display on right side image frame). 1. Color Brightness drag slider to select best brightness 【 】 Saturation drag slider to select best saturation 【...
  • Page 32 Stream Type support main stream and second stream 【 】 Resolution different resolution for different model 【 】 Frequency support 50Hz and 60Hz, default is 50Hz 【 】 Bit Rate different bit rate for different model 【 】 Frame Spaced N standard or 60Hz device has range 1-30fps, P standard or 【...
  • Page 33 Camera Name tick to enable adding name on image 【 】 Time OSD tick to enable adding time on image 【 】 OSD Name input OSD name then click Apply button, it can support 18 bit 【 】 iii. Network To configure network parameters on current condition, the software only displays network parameters of current device, despite it is manually configured or DHCP.
  • Page 34 Step 4: click “Linkage Alarm” to select alarm type Step 5: enable arm function for device, otherwise it can not support alarm linkage For ptz control, it should be fulfill with right parameters, different ptz has different protocol, protocol code and baud rate. System After select time, click “Set Time”...

  • Page 35: User Management

    6.12 User management Factory set administrator name is admin, no password. Login with administrator then add, delete and configure user authority. User authority includes three levels: admin, user and guest. “admin” authority: administrator, enable to manage device, manage user, view video, playback video, configure map, inquire log, and exchange user and exit software “user”...

  • Page 36: Other Settings

    All logs record all information of system 【 】 System log record information of user login, logout and user configuration, 【 】 etc. Operation log record user operations 【 】 Alarm log record device alarm information 【 】 2.11.1 Log Retention Time Step 1: click “Config”...

  • Page 37: Port Forwarding

    Time verify tick and configure time, software verify time to all devices at 【 】 appointed time to match time on PC Snapshot format format of snapshot, support JPG and BMP 【 】 Snapshot save path the save path of snapshot 【...

  • Page 38: Warranty Instruction

    Please adjust video parameters for camera（mode, brightness, contrast, saturation, etc）. If the background light is too strong，please adjust the range to view. The camera finder can not find device. Please check if the camera and computer are in the same subnet. And if the cable or power adapter 【Normally, the power light （yellow）is always is not good, it will cause the problem too.

  • Page 39: Warranty Card

    8.3 Warranty card Please cut the below form for information and return with device Product model Manufacture date Client agency User name User address Contact (TEL/mobile phone) maintain time Problem details result note: MH3E-E-A2 - 38 -...
