Paslode IM200 User Manual page 2

PARTS LEGEND
1 900356 1 Grill
2 900455 1 Filter
3 901065 4 Shoulder Screw, 10-24 x 1-1/4
4 008388 4 Flat Washer #10
5 900410 1 Cap Assembly
6 404427 3 Screw, Taptite, 8-32 x 5/8
7 006562 3 Washer #8
8 900271 1 Circuit Board Assembly
9 900526 1 Motor & Connector
10 403842 1 Spark Plug Boot
11 401341 1 Spark Plug Assembly
12 401356 1 Sleeve, Motor
13 900470 1 Motor Mount Assembly
14 401355 1 Retaining Ring
15 403146 1 Stem Adapter (Yellow)
16 900004 1 Cylinder Head
*17 404700 2 O-Ring
18 403167 1 Fan Blade Assembly
19 900011 1 Battery Contact Assembly
20 900968 2 Shoulder Screw, 10-32 x 9/16
22 404432 1 Bushing, Actuator
23 900357 1 Actuator
24 404433 1 Pin, Actuator
25 900136 1 Actuator Assembly
27 900179 1 Handle Right Side
28 403156 1 Lanyard
29 403155 1 Battery Cap
30 900138 1 Handle, Left Side
32 900453 3 Thrd. Frm.Screw, 8-16 x 7/8
33 900289 1 Belt Hook
34 901221 1 Screw, 8-32 x 9/16
35 403082 1 Washer
36 403166 1 Bushing
37 401450 2 Pad, Fuel Cell
38 402201 2 Screw, Phillips Head, 2-56 x 5/8
39 404490 1 Trigger Switch Assembly
40 401395 1 Spring
41 900358 1 Trigger
42 403127 1 Retention Cap
43 001641 1 Nut, 8-32
44 900562 1 S. H. C. S. 10-24 x 1-1/8"
45 900552 2 Cover Plate
▲46
004224 5 Screw
47 900549 1 Rail Bracket
48 404698 2 Roll Pin Assembly
49 900551 1 Pivoting Rail Cover Assembly
50 900548 1 Rail & Cover Assembly
51 900532 1 Lower Siding W. C.E.
▲52
402797 1 Retaining Bushing
53 402798 1 Latch, Follower Button
54 402799 1 Spring, Follower Latch
55 402740 1 Roll Pin, 3/32 x 7/16
56 091568 1 Screw, Pan Head, 6-32 x 1/4
57 070545 1 Lockwasher #6
* Denotes normal wear items.
** Make sure warning labels are properly affixed, replace if necessary. Labels available at no charge through the Service Department.
▲
Apply Loctite 242 (Blue).
➔
Denotes new change.
IM200/50 S16 SOLID STATE,
58 091532
59 091534
60 402743
61 402668
62 402796
63 403104
64 403100
65 403099
66 403098
*67 404665
68 403094
69 403084
70 403089
71 403090
72 403092
73 403091
74 404339
75 403106
76 403713
77 404316
78 900411
▲80
004174
81 900534
82 092037
83 402736
84 404319
85 900056
86 004238
87 402629
88 900535
89 404365
▲90
900537
91 900550
92 403822
93 900001
94 404317
95 092176
96 404315
97 900583
98 900280
99 900509
100 404385
**101 900496
103 900651
**104 900517
106 900232
107 404601
108 900166
109 900164
110 900182
111 900142
112 900236
114 900300
115 900468
900078
1 Negator
1 Drum, Negator
1 Pin, Negator Drum
1 Retaining Washer
1 Follower
1 Air Dam
1 Combustion Chamber Assembly
1 Retaining Ring, Piston
1 Piston Ring
1 Piston Driver Blade Assembly
1 Bumper
1 Sleeve/ Midcheck Ring Assembly
1 Seal Washer
2 Wave Washer
2 Retaining Ring, Midcheck
1 Muffler
1 Spring, Chamber Return
1 Cage
3 E-Ring, Retaining
1 Flange, Sleeve
1 Housing Assembly
2 S. H. C. S. 10-24 x 7/8
2 S. H. C. S. 10-32 x 5/8
1 Locknut, 10-32
1 Washer, Flat #10 Black
1 Lower Work Contacting Element
1 No-Mar Tip (Optional)
1 Lockwasher #10
1 Washer, Hardened #10
1 Upper Work Contacting Element
1 Front Guide
2 S. H. C. S. 10-24 x .813
1 Back Plate
1 Pivot Pin
1 Spring, Latch
1 Latch, Front Guide
1 Roll Pin, 5/32 Dia. x 1-3/8
1 Flange, Nose
1 Removable Spark Plug Wire
1 Spark Assembly
1 Nameplate
1 Light Pipe
1 Warning Label
2 Label, Logo
1 International Warning Label
1 Cable Clamp
1 Head Switch Assembly
1 Spring, Combusion Chamber
1 Ring, Head Switch Activating
2 Washer, Trigger
1 Label, Battery
1 Clip Handle
1 Retaining Ring
1 Washer
