- Page 1 AMP SELECTOR Owner’s Manual Version 1.0...
- Page 3 Level controls for each output provide a convenient way to balance the volume between amps. There is also second input which if used will split the Amp Selector into two separate A/B/Both functions. This is great for applications using two guitars (electric and acoustic, for example) or a stereo signal path.
- Page 4 Tuner Out: Driven from Input-A for tuner or other slave. Ground Lift Switches: Normally ON to ground amplifier. Amp Outputs: Connect to amplifier inputs. Note: Plugging into Input-A powers up the Amp Selector. Unplug this cable when not in use to preserve the battery. OODOO...
- Page 5 Check out the Operation section of this manual for programmable switching options. Connections Connect the output of your guitar into Input-A of the Amp Selector. If you are using pedal effects in front of the amplifier, then connect from the output of your last pedal into Input-A of the Amp Selector.
- Page 6 Powering the Amp Selector on and off is done via the input jack, just like most pedal effects. Insert a cable into Input-A to power on. Remove it to turn the power off. If you are powering the Amp Selector with a battery, always remember to disconnect the Input-A cable to preserve battery life.
- Page 7 Input-A. Ground Problems You should always start with all of the Amp Selector’s Grounds Lift switches in the ON position. This means the output is grounded. If the amp is humming, the first place to look is if there is a two or three position ground switch on the amplifier itself.
- Page 8 Warranty Voodoo Lab warrants this product against any defects that are due to faulty material or workmanship for a period of five years from the date of original retail purchase. This warranty does not include damage to the product resulting from accident or misuse. This warranty is given to the original purchaser only and it is not assignable to any other person.
