- Page 1 2 Mega Pixel HD-SDI Water-proof IR Camera User Manual...
- Page 2 Thank you for purchasing our product. This manual is only applicable to SDI water-proof IR cameras. Some models of this series may support internal focal adjustment. If the model you get doesn’t support to adjust zoom and focus, please skip the descriptions related to focal adjustment. There may be several technically incorrect places or printing errors in this manual.
- Page 3 User Manual of SDI Water-proof IR Camera product please read...
- Page 4 User Manual of SDI Water-proof IR Camera...
- Page 5 User Manual of SDI Water-proof IR Camera...
-
Page 6: Table Of Contents
Introduction............1 Package Content ..........1 Main Features ...........1 Overview............2 Installation............4 Menu Setup............7 Power On/Off ...........7 Basic Operating Instruction .......7 Lens Setup ............8 Exposure ............8 White Balance ..........11 Day & Night .............12 Special ............13 Image Adjustment..........14 Reset .............16 Specification ..........16... -
Page 7: Introduction
User Manual of SDI Water-proof IR Camera 1 Introduction 1080P CMOS sensor of Panasonic and support 1080P real-time image capture and transmission with SDI video output port. 1.1 Package Contents Please verify the package for the following contents and make sure that the device in the package is in good condition and all the assembly parts are included. -
Page 8: Overview
User Manual of SDI Water-proof IR Camera ● Adopt high-performance sensor and with high resolution (up to 1080P) whichbrings high-quality images. ● Support HD-SDI video output. ● Support High Light Control (HLC) which makes you see the image around the glare point more clearly. ●... - Page 9 User Manual of SDI Water-proof IR Camera CVBS Video Cable Lens Cover Sun Shield HD-SDI Video Cable Fixed Ring Power Cable Mounting Base Focus Direction Key Zoom Direction Key: Push the ‘OK’ button up (hereinafter referred as Push up) to make the cursor move up. Push the ‘OK’...
-
Page 10: Installation
User Manual of SDI Water-proof IR Camera Cable Connection: Monitor DC12V Monitor SDI DVR 2 Installation Some models of this series may not support to adjust focus and zoom. If you get such kinds of camera, please skip the steps of focus and zoom adjustment. Before start, please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. - Page 11 User Manual of SDI Water-proof IR Camera Step 2: Route the cables and connect the power cable and video cable. And then secure the mounting base with camera to the ceiling or wall with screws. Ceiling Wall Step 3: Bracket adjustment. Before adjustment, preview the image of the camera on a monitor and then loosen the fixed ring to adjust.
- Page 12 User Manual of SDI Water-proof IR Camera ● Loosen the fixed ring to adjust the panning position of the camera. The adjustable range is from 0° to 360°. ● Loosen the fixed ring to adjust the tilting position of the camera.The adjustable range is from 0°...
-
Page 13: Menu Setup
User Manual of SDI Water-proof IR Camera 3 Menu Setup 3.1 Power On/Off 3.2 Basic Operation Instruction SETUP MANUAL LENS EXPOSURE WHITE BAL DAY&NIGHT SPECIAL IMAGE ADJUST RESET... -
Page 14: Lens Setup
User Manual of SDI Water-proof IR Camera pushing the Push enter 3.3 Lens Setup Support manual IRIS and DC lens. Please setup according to the use of lens. User can select the lens type by pushing right. 3.4 Exposure Exposure setup includes: Shutter, AGC, Sens-up, WDR, Defog and Backlight. - Page 15 User Manual of SDI Water-proof IR Camera...
- Page 16 User Manual of SDI Water-proof IR Camera that, press Enter button to setup the area size. Push up or left to reduce the area, but press down or right to enlarge the area. If parameters of BLC setup are out of order, please select Default and press Enter button to reset settings.
-
Page 17: White Balance
User Manual of SDI Water-proof IR Camera 3.5 White Balance Select WHITE BAL and push left or right to choose White balance mode including ATW, AWC SET, Indoor Outdoor and Manual ATW: In this mode, the camera will constantly monitor the color temperature among about 2500~ 9500K of color temp and adjust white balance automatically. -
Page 18: Day & Night
User Manual of SDI Water-proof IR Camera 3.6 Day & Night Mode: Three options: Auto, Color, B/W, EXT. The default mode is EXT mode. Auto: When selecting Auto, the camera will change into color mode in the Daytime or B/W mode at night so that user can get the best and clearest images. -
Page 19: Special
User Manual of SDI Water-proof IR Camera 3.7 Special language, camera title, motion, privacy Special setup includes and defect setup. Language: There are three languages: English, CHT and CHS. Camera title: When selecting “On”, the title edition and the position selection of the title is effective. User can press the direction button to self-define the camera name. -
Page 20: Image Adjustment
User Manual of SDI Water-proof IR Camera • Default: Reset all settings of Motion to the default value. • Return: Return to the previous interface. Privacy: If a user wants to mask some areas, please select On and press Enter button to go into the privacy setup interface. •... - Page 21 User Manual of SDI Water-proof IR Camera User can setup 3D NR, sharpness, brightness, Gamma, blue gain, red gain, lens shading and NTSC/PAL. 3D NR: Select it and press Enter button to go into 3D NR interface. Select D NR level and push left/right to increase or decrease the NR level in the daytime.
-
Page 22: Reset
User Manual of SDI Water-proof IR Camera 3.9 Reset This function is reset all setups to the default status. If 4 Specification... - Page 23 User Manual of SDI Water-proof IR Camera Water proof IR Model HD SDI Camera Sensor 1/3"CMOS Pixel 2010(H)x 1092(V) Shutter 1/25s or 1/30s~1/67500s 0 LUX (LED ON) Min illumination Resolution 1000TVLines Lens driver DC driver Camera f = 6mm,4mm, 8mm, 3.3-12mm, etc Lens White balance ATW, indoor, outdoor, manual, etc...
- Page 24 450013000145 A0...
