- Page 1 User Manual of SDI Box Camera...
- Page 2 Thank you for purchasing our product. This Manual is only applicable to SDI box cameras. There may be several technically incorrect places or printing errors in this manual. The updates will be added into the new version of this manual. We will readily improve or update the products or procedures described in the manual.
- Page 3 User Manual of SDI Camera product please read...
- Page 4 User Manual of SDI Camera...
- Page 5 User Manual of SDI Camera...
-
Page 6: Table Of Contents
Introduction ............1 1.1 Package Content ..........1 1.2 Main Features ...........1 1.3 Rear Panel Instruction .........3 1.4 Side Panel Instruction ........4 Operation Instruction ........5 2.1 Power On/Off .............5 2.2 Basic Operating Instruction .........6 2.3 Lens Setup ............7 2.4 Exposure ............7 2.5 White Balance ...........9 2.6 Day&Night ............10 2.7 Special ..............12 2.8 Image Adjust .............13... -
Page 7: Introduction
User Manual of SDI Camera 1080P CMOS sensor of Panasonic and support 1080P real-time image capture and transmission with SDI video output port. Terminal block Mounting block 1080P real-time image with high definition and good color reproduction. The sensibility is up to 0.001LUX due to the installation of the high quality of the built-in removable optical filter. - Page 8 User Manual of SDI Camera HD-SDI video output...
-
Page 9: Rear Panel Instruction
User Manual of SDI Camera Rear Panel Instruction... -
Page 10: Side Panel Instruction
User Manual of SDI Camera Number Description Direction button. Change direction to select item. Enter button. Confirm selection. Video out port. Connect to monitor. Power indicator. When power supply is normal, the light is red. Alarm out port. Connect to external alarm. Power input. -
Page 11: Operation Instruction
User Manual of SDI Camera Damp- Damp+ Driver + Driver- 1. Focus Adjusting: When it still fails to realize focusing after having confirmed the correct lens interface, the back focus adjustment may be required. Operate the following steps: tighten the lens firstly and then loose the fixed back focus ring; rotate the lens slowly until the video image turns to be clear, and finally tighten and lock the back focus ring. -
Page 12: Basic Operating Instruction
User Manual of SDI Camera SETUP MANUAL LENS EXPOSURE WHITE BAL DAY&NIGHT SPECIAL IMAGE ADJUST RESET pressing the Press... -
Page 13: Lens Setup
User Manual of SDI Camera enter Support manual IRIS and DC lens. Please setup according to the use of lens. User can select the lens type by pressing right button. 2.4 Exposure Exposure setup includes: Shutter, AGC, Sens-up, WDR, Defog and Backlight. Shutter: Options include auto, 1/3, 1/60, FLK, 1/250,1/500, 1/1000, x 2. - Page 14 User Manual of SDI Camera WDR: Lighten the dark area and control the highlight area. There are four options: low, middle, high, off. Defog: In foggy weather, you can setup this function to see the object behind fog clearly. There are four options: low, middle, high, off.
-
Page 15: White Balance
User Manual of SDI Camera and the low brightness will be enhanced at the same time. As a result, the image in a certain area will be exposed properly. (Please use the fixed IRIS Lens). This function can be used to shoot license plate number. -
Page 16: Day&Night
User Manual of SDI Camera color temperature among about 2500~ 9500K of color temp and adjust white balance automatically. This mode is prior to other modes. AWC → SET: Select it and press Enter button to go into the lock mode of white balance. Now the camera locks the reference value of red and blue under the current color temperature and stops monitoring color temperature. - Page 17 User Manual of SDI Camera Auto: When selecting Auto, the camera will change into the Daytime or B/W mode at night so that user can get the best and clearest images. Select Auto and press Enter button to enter into the auto setup interface.
-
Page 18: Special
User Manual of SDI Camera 2.7 Special Press right/left button to setup language, camera title, motion, privacy and defect. Language: There are three languages: English, CHT and CHS. Camera title: Select it and press Enter button to select On/Off. When selecting “On”, the title edition and the position selection of the title is effective. -
Page 19: Image Adjust
User Manual of SDI Camera • Motion view: If enabled, there will be some red square appearing when there are something moving. • Default: Reset all settings of Motion to the default value. • Return: Return to the previous interface. Privacy: If a user wants to mask some areas, please select On and press Enter button to go into the privacy setup interface. - Page 20 User Manual of SDI Camera Select Image Adjust and press Enter button to go into Image Adjust interface. User can setup 3D NR, sharpness, brightness, Gamma, blue gain, red gain, lens shading and NTSC/PAL. 3D NR: Select it and press Left/Right button to increase or decrease the NR level.
-
Page 21: Reset
User Manual of SDI Camera 2.9 Reset This function is reset all setups to the default status. If parameters of the camera are out of order and the camera cannot display images, user may use this function to reset all setups. Please select Reset and press Enter button to go into its setup interface. - Page 22 User Manual of SDI Camera HD SDI Box Camera Model Sensor 1/3"CMOS Pixel 2010(H)x 1092(V) Shutter 1/60s~1/67500s 0.01LUX Min illumination Resolution Camera 1000TVLines Lens driver DC driver C/CS port Lens port White balance ATW, indoor, outdoor, manual, etc Day&Night >50dB S/N ratio 3D NR Support...
- Page 23 User Manual of SDI Box Camera 450013000025 A1...
