DEV-BF5xx-FPGA:
DEV-BF548DA-Lite: Get ready to program and debug Bluetechnix CM-BF548 Core
EXT-Boards:
Software Support:
BLACKSheep:
LabVIEW:
uClinux:
Upcoming Products and Software Releases:
Keep up-to-date with all the changes to the Bluetechnix product line and software updates at:
www.bluetechnix.com
BLACKFIN Design Service
Based on more than five years of experience with Blackfin, Bluetechnix offers development
assistance as well as custom design services and software development.
Blackfin DEV‐BF548‐Lite & DEV‐BF548DA‐Lite Hardware User Manual
Blackfin Development Board with two sockets for any combination
of Blackfin Core Modules. Additional peripherals are available, such
as SD-Card, Ethernet, USB host, multi-port JTAG including a USB
based Debug Agent, connector for an LCD-TFT Display and
connector for a digital camera system. A large on-board SPARTAN-3
FPGA and Soft IPs make this board the most flexible Blackfin
development platforms ever developed.
Module with this tiny development platform including a USB Based
Debug Agent. The DEV-BF548DA-Lite is a low cost starter
development system including VDSP++ Evaluation Software
License.
The following Extender Boards are available: EXT-BF5xx-Audio,
EXT-BF5xx-Video, EXT-BF5xx-Camera, EXT-BF5xx-Exp, EXT-
BF5xx-ETH-USB, EXT-BF5xx-AD/DA. Additional boards based on
customer request are also available.
The BLACKSheep VDK is a multithreaded framework for the
Blackfin processor family from Analog Devices that includes driver
support for a variety of hardware extensions. It is based on the real-
time VDK kernel included within the VDSP++ development
environment.
LabVIEW embedded support for the CM-BF537E, CM-BF537U and
TCM-BF537 Core Modules is based upon the BLACKSheep VDK
driver Framework.
All the Core Modules are fully supported by uClinux. The required
boot loader and
http://blackfin.uClinux.org.
uClinux can be downloaded from:
