Television
Reference Guide
KDL-48W608B / 48W600B / 40W608B / 40W600B

Advertisement

Table of Contents
loading

Summary of Contents for Sony BRAVIA series

  • Page 1 Television Reference Guide KDL-48W608B / 48W600B / 40W608B / 40W600B...
  • Page 2: Table Of Contents

    Introduction Table of Contents Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. Note • Before operating the TV, please read “Safety Information” (page 2). • Instructions about “Installing the TV to the Wall” are included within this TV’s instructions manual.
  • Page 3 AC power outlet (mains socket). • Two or three people are needed to transport a large TV set.  Use only Sony supplied AC power cords (mains lead), not those • When transporting the TV set by hand, hold it as shown below.
  • Page 4 Turn off the TV set and unplug the AC power cord (mains lead) immediately if any of the following problems occur. Ask your dealer or Sony service centre to have it checked by qualified service personnel. • For best picture quality, do not expose the screen to direct illumination or sunlight.
  • Page 5: Precautions

    Wireless Function of the unit you use substitute items, the TV may fall and cause bodily injury to someone or damage to the TV. • Do not operate this unit near medical equipment (pacemaker, • Be sure to assemble the bracket properly following the etc.), as malfunction of the medical equipment may result.
  • Page 6: Connecting Other Devices

    To connect with AV composite cables Connecting Other Devices To connect with an HDMI cable < 21 mm < 12 mm To VIDEO OUT To HDMI OUT To connect with component cables To AUDIO OUT To COMPONENT OUT (P Picture Quality •...
  • Page 7: Installing The Tv To The Wall

    Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation.
  • Page 8 Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 16-18 (Specifications) for the TV’s weight.
  • Page 9 Slim mounting Note • You cannot use some of the terminals on the rear of the TV when using this mounting style.  Screw (+PSW 6 x 20)  Screw (+PSW 6 x 20)  Pulley  Spacer (20 mm) ...
  • Page 10: Wall-Mount Adapter (India Only)

    To Sony Dealers and Contractors Sufficient expertise is required for installing this product. Be sure to read this instruction manual thoroughly to do the installation work safely. Sony is not liable for any damages or injury caused by mishandling or improper installation.
  • Page 11 Prepare necessary items. Wall-Mount Bracket accessories (supplied) Paper Template Wall-Mount Base (2) Pulleys (2) Screw (+PSW 6 × 16) (3) Spacers (2) Band Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV.
  • Page 12 Make a mark on the Paper Template A that indicates the screen centre of your TV. Scale on Paper Template A Mark for KDL-48W600B Mark for KDL-40W600B Tape the Paper Template A to the wall and make holes according to the numbering on the Paper Template A using an electric drill.
  • Page 13 Attach the Pulleys C using the supplied screws D. Attach the Spacers E to the holes indicated by the triangle marks f. Then, attach the Band F using the supplied screw D. × Soft cloth Make sure to connect and bundle the cables before installing the TV on the wall. Bundle the AC Adapter using the cable holders G (supplied with the TV).
  • Page 14 Install the TV on the wall. Confirm the Pulleys C are firmly latched into the Wall-Mount Base B. Then, attach the Band F to the wall using a screw (5 mm in diameter, not supplied). Dimensions for hole positions on the wall Pass the following information to the licensed contractors if necessary.
  • Page 15: Troubleshooting

    TV. If the problem persists, contact your dealer or Rear of TV Sony service centre with the number of times the LED indicator flashes red (interval time is three seconds). Press / on the TV to turn it off, disconnect the AC power cord (mains lead), and inform your dealer or Sony service centre.
  • Page 16: Specifications

    AUDIO OUT/ Audio output (stereo mini jack) Specifications Headphone jack (supports Subwoofer out) System 2 (Except Australia and New Zealand Panel system model) LCD (Liquid Crystal Display) Panel, LED backlight USB port TV system 1 (HDD REC), 2 (Australia and New Zealand Analogue: B/G, I, D/K, M, L model only) Digital: DVB-T/DVB-T2...
  • Page 17: Trademark Information

    • Wi-Fi, Wi-Fi Direct and Miracast are some countries/areas. trademarks or registered trademarks of Wi-Fi Alliance. • “Sony Entertainment Network logo” and “Sony Entertainment Network” are trademarks of Sony Corporation. • MHL, Mobile High-Definition Link and the MHL Logo are trademarks or registered trademarks of MHL Licensing, LLC.
  • Page 20 Customer Support and Contact: ©2014 Sony Corporation Printed in Malaysia 4-528-978-11(1)
