1.3
Camera Overview
DC 12V/ PoE
Power LED
Reset Button
Definition
LINE OUT & LINE IN / MIC IN Two-way audio transmission
Power LED
Reset button
AUTO IRIS connector
NETWORK (with PoE)
Network LEDs
I/O
VIDEO (BNC connector)
Micro SD Card slot
Network LEDs
Remarks
Power connection indication (green light)
Reset to factory default
Auto iris lens connector
RJ-45 connector
Network connection and activity indication
Output＋
1
Output－
2
Input＋
3
Input－
4
For video output
For video and snapshots storage
5
