EMAC PPC-E10 User Manual

Arm cortex a8 panel pc

Advertisement

Quick Links

PPC-E10
ARM Cortex A8 Panel PC
User Manual
REV. 2.0
Copyright 2014,
EMAC, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPC-E10 and is the answer not in the manual?

Questions and answers

Summary of Contents for EMAC PPC-E10

  • Page 1 PPC-E10 ARM Cortex A8 Panel PC User Manual REV. 2.0 Copyright 2014, EMAC, Inc.
  • Page 2: Table Of Contents

    Table of Contents PPC-E10 Product Summary ........................3 Features ..................................3 Standard PPC Specifications ............................4 Description ................................... 5 PPC-E10 Product Details ......................... 6 Jumper Configuration & Connector Descriptions ......................6 Power Connectors ................................ 6 Ethernet ..................................7 Serial Ports ................................... 7 USB Host Ports ................................
  • Page 3 Disclaimer EMAC Inc. does not assume any liability arising out of the application or use of any of its products or designs. Products designed or distributed by EMAC Inc. are not intended for, or authorized to be used in, applications such as life support systems or for any other use in which the failure of the product could potentially result in personal injury, death or property damage.
  • Page 4: Ppc-E10 Product Summary

     Analog Resistive Touchscreen and Software Controlled Backlight On/Off & Brightness  JTAG for debug, including real-time trace  FREE Eclipse IDE or QT Creator with GCC & GDB development tools for Linux  Android Available ENG-00178-20P-PPC-E10_User_Manual.docdoc -3- Rev 2.0 © 2014 EMAC, Inc.
  • Page 5: Standard Ppc Specifications

     Driver: Linux  Durability: Over one million touches Ethernet interface  Ethernet MAC: Built-In  Ethernet PHY: Micrel KSZ8041  Ethernet Type: 10/100 Base-T Ethernet  Ethernet Interface: On-Board RJ-45 connector ENG-00178-20P-PPC-E10_User_Manual.docdoc -4- Rev 2.0 © 2014 EMAC, Inc.
  • Page 6: Description

    (SoM) design which extends the longevity and flexibility of the PPC-E10. The PPC-E10 is comprised of a Processor Module and a Carrier board in which the Module plugs into. If more memory is required or speed is required a different pin compatible Module offering these features can be inserted into the Carrier board in place of the standard Module that is provided.
  • Page 7: Ppc-E10 Product Details

    PPC-E10 Product Details Jumper Configuration & Connector Descriptions The PPC-E10 comes factory configured. In the event that jumpers need to be verified or modified this section provides the information required, including instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all the safety precautions before you begin any configuration procedure. See Appendix A for connector pinouts and Appendix B for Jumper Setting descriptions.
  • Page 8: Ethernet

    Serial Ports The PPC-E10 is equipped with four serial ports, one of which terminates to a male DB9 and the other three which terminate to 10pin header connectors (see table 2, 3, & 4 below). Three 10-pin header to male DB9 connector cables are provided, giving easy access to these ports.
  • Page 9: Usb Host Ports

    (HDR5). EMAC can provide a cable (CAB-40-004) to access these ports. In addition to the two USB Host ports, the PPC-E10 provides a USB On-The-Go (OTG) port. This port can be used as either a USB Host or USB Device port.
  • Page 10: Audio Port

    Audio Port The PPC-E10 provides Audio Line Out and Line In capability through two standard audio jacks (JK5 & JK6). Audio Jack JK5 is stereo line level input and Audio Jack JK6 is stereo line level output. The processor interfaces S interface.
  • Page 11: I/O Expansion

    1.14 I/O Expansion The Processor used by the PPC-E10 provides a number of unused I/O lines. The PPC-E10 provides access to these lines on connector HDR1. This 44-pin dual row header contains GPIO lines, SPI bus, I C bus, A/D, interrupts and power pins.
  • Page 12: Software

    Software 1.17 Introduction The PPC-E10 can be programmed in a variety of languages and utilize a variety of Operating Systems. There are a number of free compilers, interpreters, and assemblers available allowing the PPC-E10 to be programmed in C, Java or Assembly languages. EMAC has Board Support Packages available for Linux, Xenomai Real Time Linux and Windows CE.
  • Page 13: Linux Operating System

    The distribution contains everything a user could expect from a standard Linux kernel, powerful networking features, advanced file system support, security, debugging utilities, and countless other features. The PPC-E10 will work out of the box with EMAC’s Embedded Linux distribution, and EMAC provides the most up to date distribution via FTPSVN.
  • Page 14: Android Operating System

    The Linux build for the PPC-E10 is based on the Open Embedded (www.openembedded.org) Linux build system. The current kernel is Linux 2.6.30 or higher patched to support the PPC-E10. Open Embedded is a superior Linux distribution for embedded systems. Custom Linux builds are also available on request.
  • Page 15: Appendix A: Connector Pinouts

    Appendix A: Connector Pinouts 1.23 Ethernet 10/100 Base-T connector (JK2) Signal XMT+ XMT- RCV+ RCV- 1.24 USB Connector (JK3, JK4, HDR5) 1.24.1 PortA (JK3 - Host) Signal USB_PWR (5Vdc) USB_Data- USB_Data+ 1.24.2 PortB (JK3 - Host) Signal USB_PWR (5Vdc) USB_Data- USB_Data+ 1.24.3 PortC (JK4 - OTG) Signal...
  • Page 16: Power Connector (J1)

    1.26 Power Connector (J1) Signal Chassis GND System GND 1.27 MicroSD Socket (SOK1) Signal DAT2 CD/DAT3 VCC (3.3V) SCLK DAT0 DAT1 SD Card Detect 1.28 TTL LCD/Touch/Backlight (CN6) Signal HSYNC VSYNC...
  • Page 17: Lvds Lcd/Touch/Backlight (Hdr6)

    1.29 LVDS LCD/Touch/Backlight (HDR6) Signal Signal 3.3V 3.3V RED - RED + GREEN - GREEN + BLUE - BLUE + CLOCK - CLOCK + VLED +5V VLED +5V BRIGHTNESS EDID DATA EDID CLOCK 3.3V VLED +5V 1.30 PCD-E12 Expansion connector (ABJ1) Signal Reset SPI_MOSI...
  • Page 18: Comb Rs-232 Serial Port (Hdr3)

    1.32 COMB RS-232 Serial Port (HDR3) HD3 Signal DB9 Signal 1.33 COMC RS-232/422/485 Serial Port (HDR4) HD3 Signal DB9 Signal 422/485 TX- 422/485 TX- 232 RX, 422/485 TX+ 232 RX, 422/485 TX+ 232 TX, 422/485 RX+ 422/485 RX- 232 TX, 422/485 RX+ 422/485 RX- 1.34 COMD RS-232 Serial Port (HDR2) HD3 Signal...
  • Page 19: Misc. General Purpose I/O (Hdr1)

    1.35 Misc. General Purpose I/O (HDR1) Signal Signal 3.3V 3.3V GPIO1 GPIO4 GPIO2 GPIO5 GPIO3 GPIO6 INT0 GPIO7 INT1 OSC0 OSC1 ADC4 SPI_MISO SPI_MOSI SPI_CLK SPI_CS3 SPI_CS1 I2C_DAT I2C_CLK *SOM_RSTOUT 5V_VCC 5V_VCC 1.36 Touch Screen Connector (CN1) Signal 1.37 Touch Screen Connector (CN3) Signal 1.38 LCD Backlight Connector (CN4) Signal...
  • Page 20: Appendix B: Jumper Settings

    Appendix B: Jumper Settings Boot0 Source Selection Jumper Position Setting Pins 2 & 3 Serial Boot Loader Download (EBI) Pins 1 & 2* Normal Boot from Flash (DBI) * Default setting Boot1 Option Selection Jumper Position Setting Pins 2 & 3* Flash Enable (FE) Pins 1 &...
  • Page 21: Appendix C: Mechanical Drawing Of Mounting Plate With Dimensions

    Appendix C: Mechanical drawing of Mounting Plate with dimensions...
