USER MANUAL REV.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Garage Door Opener and is the answer not in the manual?

Questions and answers

Summary of Contents for GOGOGATE Garage Door Opener

  • Page 1 USER MANUAL REV.5...
  • Page 2: What's In The Box

    - DO NOT let children use the GOGOGATE product and app without adult supervision. - ONLY Operate your GOGOGATE device when you are in clear view of your garage or gate and you have verified that there are no objects obstructing the operation of the door. ALWAYS wait for garage door or gate to be completely closed.
  • Page 3 GoGogate device. Power input: Connects the 5VDC power supply to the device. NOTE: your GOGOGATE has no power on/off switch. The device consumes very little power and needs to be always Reset button: Press this button during on for your app to open and close your garage when you need it.
  • Page 4 Use a screw driver to open or unscrew your garage door wall button. (You may have 1 ,2 or 3 wall mounted buttons depending on the number of garage doors you have. The GOGOGATE works with up to 3 garages.)
  • Page 5 WALL BUTTON EXAMPLE 1 WALL BUTTON EXAMPLE 2 garage door wall mounted buttons maybe of different colors, for the GogoGate product this does not matter. (ie. polarity or color are not important). Attach the cables pro- vided with your product to either of the 2 cables found on the back of your garage buttons.
  • Page 6 GARAGE OPENER WALL BUTTON EXAMPLE 1 GARAGE OPENER WALL BUTTON EXAMPLE 2 Reconnect your wall mount button to the wall. (show photo)
  • Page 7 2 with all wall buttons before inserting the cable connector into the gogogate device. Make sure connector is Pushed in all the way. Snap the green cable connector (provided) into the GOGOGATE cable slot.
  • Page 8 CABLE POWER CONECTOR SUPPLY “Garage Door 1” “Garage Door 2” “Garage Door 3” BUTTON 1 BUTTON 3 BUTTON 2 Plug your wireless adapter antenna in your gogogate and then connect your gogogate to the power supply outlet . See drawing.
  • Page 9 STEP 2 WIRELESS DOOR SENSOR Attach your wireless sensors to your garage door as per drawing below. LED LIGHT FACING DOWN EXCLUSIVE FOR GARAGE DOORS Always install your wireless door sensors with the garage doors in a closed position. Put the provided AAA battery into the sensor. Place the sensors on the upper part of your garage door wall.
  • Page 10 1-2 seconds. The LED should also blink fast for 2 seconds when you close the garage. Please note that the status light on your GoGogate will blink fast ONLY when there is a change in the door status from closed to open or open to closed.
  • Page 11 STEP 3: Program your GOGOGATE in 3 simple steps Double click to open your app Press the settings button Select (bottom right of screen) “BEGIN YOUR INSTALLATION”...
  • Page 12 We have pre-selected WPA which is the most common security setting. Select WEP if WPA does not work. (Note that your GoGogate only works with WEP 128 bits.). Select “Open” if your home network is not password protected. There is a 4 digit code on the front of your Wireless door sensor (included).
  • Page 13 At that point you may remove your phone. You are done. During the programming of your GOGOGATE you will hear an automated WARNING: You have 5 seconds voice saying “programming”, until the sequence is completed. to place your phone on the GOGOGATE Upon successful completion of the programming sequence device.
  • Page 14 CONNECTED No Wireless Door Sensor assigned PLEASE NOTE: You may have to open and close your garage door via the GOGOGATE app “once” to synchronize the wireless NOT CONNECTED sensors with the actual status of your garage No Wireless Door Sensor assigned...
  • Page 15 GOGOGATE in the same Network, you can choose another port. The available ports are between 8001 and 65534. IP SETTINGS In advanced mode, you have to put a static IP for GOGOGATE, DHCP is disabled. By default, in Standard settings, DHCP is enabled.
  • Page 16 GOGOGATE WEB PAGE Please note that if you had already programmed “garage door 1” when you bought your GoGoGate and are now adding 1 or 2 more door sensors, you will only need to enter the information (4 digit code and name) of your...
  • Page 17 FOLLOW THE STEPS BELOW IF YOU ALREADY SUCCESFULLY PROGRAMED YOUR GOGOGATE: This option is suitable for all those customers who already installed a GoGogate but have a weak Wi-Fi signal or prefer to have a wired connection to their existing home network.
  • Page 18 Connect your Ethernet adaptor to the USB slot in your GoGogate. Reset the GoGogate unit by pressing the RESET button for 5 seconds until you hear 1 beep. The GoGogate will connect automatically to your Network and your USB Ethernet will start blinking.
  • Page 19: Edit Devices

    We know that with time things may change. The Edit Devices menu will give you the flexibility you need. SELECT Change your device name or password “Edit Devices” Delete existing device. GoGogate must be added or programmed again if deleted. HOME BEACH...
  • Page 20: Standard Mode

    1) Download the GOGOGATE app on the smartphone The GoGogate name and 2) They will need to have access to your home network via Wi-Fi Password are case sensitive. 3) They will need your GOGOGATE name and password. SELECT “Add GoGogate” STANDARD MODE...
  • Page 21: Remote Access

    Make sure your app is connected via Wi-Fi to your GoGogate device. Under this scenario the connected garage door buttons in your app should be displayed in black and you should see a “Find GoGogate” button at the bottom of your apps main screen (see photo).
  • Page 22: The Configuration Section

    The Configuration section: The configuration section is the control panel for the GoGogate. Make changes to your wifi settings, Here you will be able to change all functions of your device. IP settings and encryption. Your video will time out after approx 1m. to avoid using too Set up your device to work as a wired system much data..Press reload to start streaming again.
  • Page 23: Troubleshooting

    You may have to re-start your installation by pressing “begin your installation” and “start”. If you still cannot program your GoGoGate device after several attempts, you may want to refer to page •...
  • Page 24 • Gogogate is out of range of your WiFi network. You can check this by looking at your Smartphone. If your Smartphone has WiFi coverage where your GoGogate device is located, then your GoGogate device should also be within range of your network.
  • Page 25: Limited Warranty And Return Policy

    5) Limited warranty and return policy The gogogate product comes with a one (1) year warranty against mechanical and electrical defects provided the products have been used in accordance with the documentation provided. The 1 year warranty period begins as of the purchase date by the user of the device. If customer does not have original proof of purchase, REMSOL will determine warranty eligibility via the manufacturing date.
  • Page 26 Caution electric shock/tire hazard! For indoor use only. Do not expose to moisture, Liquid, or heat. Do not use any other power supply with your product. • Install the wires connecting to your garage door wall buttons with all equipment powered off (garage door opener and gogogate). • Please read carefully all these instructions before installing and starting to use GoGogate.
  • Page 27 • For more information on product safety and troubleshooting, please go to www.gogogate.com/support. CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions Use and Handling Do not touch the Player or connected cables during an electrical storm.
