Bulb Replacement – Read Carefully!
Take care when replacing the lamp in order not to damage the bulb connection.
Lens Cap
1. Disconnect headlamp from battery pack.
2. To remove the bulb, carefully unthread the lens cap. Do not allow the bulb
to rotate. It may be necessary to press down gently on the bulb while
unthreading the cap.
3. Unplug the used bulb and discard it.
4. To install the bulb, first insert the two prongs of the retainer clip into the
larger holes on the ceramic socket. Next, insert the bulb lead wires into the
smaller holes in the socket.
5. Rethread lens cap onto housing. Make sure the lens cap thread is fully
engaged with the housing. Do not plug the lamp into the battery until after
this step is complete.
For technical support, call 1-800-727-2453 from 9am - 6pm Monday through Friday.
Bulb
Phillips Head Screw
Bulb Retainer Clip
Ceramic Socket
Housing
Allen Head Bolt
Exploded View
®
www.performancebike.com
Assembly
Base
