Fuses

Fuse Locations

If any electrical devices are not working, set
the power mode to VEHICLE OFF (LOCK)
and check to see if any applicable fuse is
blown.
Fuse locations are shown on the fuse box
cover. Locate the fuse in question by the
fuse number and box cover number.
■
Engine Compartment Fuse Box
Located near the brake fluid reservoir. Push
the tabs to open the box.
* Not available on all models
324
■
Circuit protected and fuse rating
Circuit Protected
EPS
−
ABS/VSA Motor
1
ABS/VSA FSR
WIPER
Main Fuse
IG Main
Fuse Box Main
Fuse Box Main 2
Headlight Main
ST/MG SW
2 Rear Defogger
−
Blower
−
Sub Fan Motor
Main Fan Motor
3 −
4 −
5 Starter DIAG, ST MG
6 −
7 −
8 −
9 −
10 −
Circuit Protected
11 Oil Level
Amps
12 Fog Lights
70 A
13
−
14 Hazard
30 A
15 FI Sub
30 A
16 IG Coil
30 A
17 Stop
100 A
18 Horn
50 A
19
60 A
Right Headlight Low Beam
60 A
20
Right Headlight Low Beam (HID)
30 A
21 IGP
30 A
22 DBW
30 A
Left Headlight Low Beam
−
23
Left Headlight Low Beam (HID)
40 A
24
−
25 MG Clutch
20 A
26 WASHER
20 A
27 SMALL
−
28 Interior Lights
−
29 Backup
7.5 A
−
*1:Models with halogen bulb low beam
− headlights
*2:Models with discharge headlights
−
−
−
Amps
7.5 A
* (20 A)
− −
10 A
15 A
15 A
15 A
10 A
− −
*1 10 A
*2 15 A
15 A
15 A
*1 10 A
*2 15 A
− −
7.5 A
15 A
20 A
7.5 A
10 A
