bizhub C30P
User's Guide
A011-9566-00A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIZHUB C30P and is the answer not in the manual?

Questions and answers

Related Manuals for Konica Minolta BIZHUB C30P

Summary of Contents for Konica Minolta BIZHUB C30P

  • Page 1 C30P User’s Guide A011-9566-00A...

  • Page 2: Trademarks

    KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. Notice KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. reserves the right to make changes to this guide and to the equipment described herein without notice. Considerable effort has been made to ensure that this guide is free of inaccuracies and omissions. However, KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.

  • Page 3: Software License Agreement

    SOFTWARE LICENSE AGREEMENT This package contains the following materials provided by Konica Minolta Business Technolo- gies, Inc. (KMBT): software included as part of the printing system, the digitally-encoded machine-readable outline data encoded in the special format and in the encrypted form (“Font Programs”), other software which runs on a computer system for use in conjunction with the...

  • Page 4: About Adobe Color Profile

    11. Notice to Government End Users: The Software is a “commercial item,” as that term is defined at 48 C.F.R.2.101, consisting of “commercial computer software” and “commercial computer software documentation,” as such terms are used in 48 C.F.R. 12.212. Consis- tent with 48 C.F.R.
  • Page 5 4. DISCLAIMER OF WARRANTY Adobe licenses the Software to you on an “AS IS” basis. Adobe makes no representation as to the adequacy of the Software for any particular pur- pose or to produce any particular result. Adobe shall not be liable for loss or damage aris- ing out of this Agreement or from the distribution or use of the Software or any other materials.

  • Page 6: Icc Profile For Toyo Ink Standard Color On Coated Paper (Toyo Offset Coated 2.1)

    9. GOVERNING LAW This Agreement will be governed by and construed in accordance with the substantive laws in force in the State of California as such laws are applied to agree- ments entered into and to be performed entirely within California between California resi- dents.

  • Page 7: For Eu Member States Only

    5. All company names and product names used in this document is the trademarks or regis- tered trademarks of their respective holder. This ICC Profile made by GretagMacbeth ProfileMaker and granted TOYO INK certain license to distribute by GretagMacbeth AG. TOYO Offset Coated 2.1 ©...

  • Page 9: Table Of Contents

    Contents Trademarks Copyright Notice Notice SOFTWARE LICENSE AGREEMENT About Adobe Color Profile ICC Profile for TOYO INK Standard Color on Coated paper (TOYO Offset Coated 2.1) For EU member states only 1 Introduction ... 1 Getting Acquainted with Your Printer 2 Space Requirements Printer Parts Front View 4...
  • Page 10 PCL Drivers PPD Files Utilities and Documentation CD-ROM 9 Utilities System Requirements 12 Selecting Driver Options/Defaults (for Windows) 13 Windows XP/Server 2003/2000/NT 4.0 13 Uninstalling the Printer Driver (for Windows) 15 Windows XP/Server 2003/2000/NT 4.0 15 Displaying Printer Driver Settings (for Windows) 16 Windows XP/Server 2003 16 Windows 2000/NT 4.0 16...
  • Page 11 4 Printer Control Panel and Configuration Menu ... 27 About the Control Panel 28 Control Panel Indicators and Keys Message Window Help Screens Configuration Menu Overview 32 Main Menu PROOF/PRINT MENU Printing/Deleting a Stored Job Entering the Password PRINT MENU PAPER MENU QUALITY MENU MEMORY DIRECT...
  • Page 12 Loading Envelopes 111 Loading Label Sheets/Postcards/Thick Stock/Glossy Media and Transpar- encies 115 Loading Banner Paper 118 Tray 2 Loading Plain Paper 121 Tray 3/4 (Optional Lower Feeder Units) Loading Plain Paper 123 Duplexing 126 Output Tray 127 Finishing 128 Job Separation Printing Offset Printing Staple printing Media Storage 130...
  • Page 13 Media Misfeed Messages and Clearing Procedures Clearing a Media Misfeed in Tray 2 181 Clearing a Media Misfeed in Tray 3/4 185 Clearing a Media Misfeed from the Duplex Option 187 Clearing a Media Misfeed from the Fuser Unit 188 Clearing a Media Misfeed from Tray 1 (Manual Feed Tray) and Transfer Roller 191 Relay Unit 193...
  • Page 14 Contents...

  • Page 15: Introduction

    Introduction...

  • Page 16: Getting Acquainted With Your Printer

    Space Requirements To ensure easy operation, consumable replacement and maintenance, adhere to the recommended space requirements detailed below. 100 mm (3.9") 100 mm (3.9") 704 mm (27.7") 284 mm 420 mm (16.5") (11.2") Front View 1175 mm (46.3") 475 mm (18.7") 480 mm (18.9") 420 mm (16.5") Front View with Options...
  • Page 17 846 mm (33.3") 100 mm (3.9") 526 mm (20.7") Side View with Options The options appear shaded in the above illustrations. Getting Acquainted with Your Printer...

  • Page 18: Printer Parts

    Printer Parts The following drawings illustrate the parts of your printer referred to through- out this guide, so please take some time to become familiar with them. Front View 1—Control panel 2—Output tray 3—Fuser unit 4—Right side cover 5—Tray 1 (Manual feed tray) 6—Transfer roller 7—Transfer belt unit 8—Tray 2...

  • Page 19: Rear View

    Rear View 1—KONICA MINOLTA Digital Cam- era Direct Print Port 2—Power switch 3—Ozone filter 4—Power connection 5—Parallel port 6—10Base-T/100Base-TX/ 1000Base-T Ethernet Interface port 7—USB port 8—Ventilation grilles Front View with Options 1—Duplex option 2—Lower feeder units (Tray 3 and Tray 4) 3—Staple Finisher...

  • Page 21: About The Software

    About the Software...

  • Page 22: Printer Driver Cd-Rom

    PostScript Drivers Operating System Windows XP/Server 2003/2000 Windows XP for 64bit Windows Server 2003 for 64bit A specific PPD file has been prepared for applications (such as Page- Maker and Corel Draw) that require that a PPD file be specified when printing.

  • Page 23: Ppd Files

    Operating System Windows XP/Server 2003/2000/NT Macintosh OS 9/X Linux For details on the installation of the Windows printer drivers, refer to the bizhub C30P Installation Guide on the Utilities and Documentation CD-ROM. Utilities and Documentation CD-ROM Utilities Utility Download Manager (Windows XP/Server 2003/2000/NT 4.0, Macintosh OS 10.2.x or later)
  • Page 24 With a Web browser, the status of printers can be checked, and the vari- ous settings can be changed. For details, refer to the bizhub C30P Reference Guide on the Utilities and Documentation CD-ROM. Using the TCP/IP and IPX protocols, basic network printer settings can be specified.
  • Page 25 Utility Use/Benefit PageScope Direct Print This application provides functions for sending PDF and TIFF files directly to a printer to be printed. For details, refer to the PageScope Direct Print Users Guide on the Utili- ties and Documentation CD-ROM. Utilities and Documentation CD-ROM...

  • Page 26: System Requirements

    – 10Base-T/100Base-TX/1000Base-T Ethernet interface port – USB Revision 2.0 compliant port – Parallel (IEEE 1284) port For details of the Macintosh and Linux printer drivers, refer to the bizhub C30P Reference Guide on the Utilities and Documentation CD-ROM. System Requirements...

  • Page 27: Selecting Driver Options/Defaults (For Windows)

    (Windows 2000/NT 4.0) From the Start menu, choose Settings and then Printers to display the Printers directory. Right-click the KONICA MINOLTA bizhub C30P PCL6 or KONICA MINOLTA bizhub C30P PS printer icon and choose Properties. – PostScript printer driver for Windows NT 4.0 is not supported.
  • Page 28 Depending on the version of the operating system, Apply may not appear. If this is the case, continue with the next step. With Windows NT 4.0, right-click the KONICA MINOLTA bizhub C30P PCL6 printer icon in the Printers directory, and then click Document Defaults.

  • Page 29: Uninstalling The Printer Driver (For Windows)

    (for Windows) This section describes how to uninstall the KONICA MINOLTA bizhub C30P printer driver if necessary. Windows XP/Server 2003/2000/NT 4.0 Close all applications. Choose the Uninstall Program as follows: – (Windows XP/Server 2003) From the Start menu, choose All programs, KONICA MINOLTA, bizhub C30P, and then Uninstall Printer Driver.

  • Page 30: Displaying Printer Driver Settings (For Windows)

    Printers directory. Display the printer driver settings: Windows 2000—Right-click the KONICA MINOLTA bizhub C30P PCL6 or KONICA MINOLTA bizhub C30P PS printer icon and choose Printer Properties. Windows NT 4.0—Right-click the KONICA MINOLTA PCL6 printer icon and choose Document Defaults.

  • Page 31: Using The Postscript And Pcl Printer Driver

    Common Buttons The buttons described below appear on each tab. Click to exit the Properties dialog box, saving any changes made. Cancel Click to exit the Properties dialog box without saving any changes made. Apply Click to save all changes without exiting the Properties dialog box. Depending on the version of the operating system, Apply may not appear.

  • Page 32: Paper View

    Paper View Click the button to display a sample of the page layout in the figure area. This button does not appear on the Advanced, Watermark, Quality, and Version tabs. Printer View Click the button to display an image of the printer (with all installed options) in the figure area.

  • Page 33: Basic Tab

    Specify user authentication and account track settings Print on the back side of paper that has already been printed on Use paper that has been printed on with bizhub C30P. In addition, the page printed with this setting is not guaranteed.

  • Page 34: Cover Page Tab

    Specify whether or not blank pages are printed (PCL printer driver only) Adjust the binding margin (PCL printer driver only) Adjust the printing position (PCL printer driver only) Cover Page Tab The Cover Page Tab allows you to Print front and back cover pages and separator pages Specify the Lower Feeder Unit that contains the paper for the front and back cover pages and separator pages Overlay Tab...

  • Page 35: Quality Tab

    Print the watermark on only the first page Print the watermark repeatedly throughout the all pages (PostScript printer driver only) Quality Tab The Quality Tab allows you to Switch between color and grayscale printing Control the darkness of an image (Brightness) Specify the printer color settings (Quick Color) Specify the resolution for the printout Perform color separation...
  • Page 36 Using the Postscript and PCL Printer Driver...

  • Page 37: Using The Status Monitor (Windows Only)

    Using the Status Monitor (Windows Only)

  • Page 38: Working With The Status Monitor

    The Status Monitor shows information about the current status of the printer. The Status Monitor can be installed from the Utilities and Documentation CD-ROM. For details on the installation, refer to the bizhub C30P Reference Guide on the Utilities and Documentation CD-ROM. Operating Environment The Status Monitor can be used on computers running Windows XP/ Server 2003/2000/NT 4.0 connected to the printer using an Ethernet connec-...

  • Page 39: Recognizing Status Monitor Alerts

    Recovery Instructions—Provides you with explanations of what you need to do in order to correct problems and recover from error conditions. Consumables Tab Displays the usage status (approximate percentage remaining) of each toner consumables. Refresh—Rechecks the supplies and displays their status. Click Help to display windows containing explanations of the Status Monitor functions.

  • Page 41: Printer Control Panel And Configuration Menu

    Printer Control Panel and Configuration Menu...

  • Page 42: About The Control Panel

    The control panel, located on the top of the printer, allows you to direct the printer’s operation. In addition, it displays the current status of the printer, including any condition that needs your attention. Control Panel Indicators and Keys Indicator MESSAGE WINDOW MENU...
  • Page 43 About the Control Panel Function Cancels the currently displayed menu or menu choice Allows you to cancel one or all print jobs that are currently being printed or processed: 1. Press the Cancel key. 2. Press the keys to select either RENT JOB ALL JOBS 3.

  • Page 44: Message Window

    If the operator or service representative must be called, the sym- If a warning occurs, the symbol When a digital camera is connected to the KONICA MINOLTA Digital Camera Direct Print Port with a USB cable, the sym- When a USB memory device is plugged into the KONICA MINOLTA Digital Camera Direct Print Port, the symbol pears on the right side of the message window.

  • Page 45: Help Screens

    Details Key information is displayed. The approximate amount of toner remaining is displayed. Help Screens The help screens appear when the such as a media misfeed, so that the error can be corrected. About the Control Panel key is pressed after an error occured,...

  • Page 46: Configuration Menu Overview

    The bizhub C30P configuration menu accessible from the control panel is structured as shown below. Main Menu READY PROOF/ PRINT MENU PRINT MENU PAPER MENU QUALITY MENU MEMORY DIRECT CAMERA DIRECT INTERFACE MENU SYS DEFAULT MENU MAINTENANCE MENU SERVICE MENU * This menu item appears only if an optional hard disk drive is installed.
  • Page 47 MEMORY DIRECT CAMERA DIRECT user access has not been permitted through authentication settings. For details on the authentication settings, refer to the bizhub C30P Reference Guide on the Utilities and Documentation CD-ROM. Configuration Menu Overview...

  • Page 48: Proof/Print Menu

    PROOF/PRINT MENU This menu item appears only if an optional hard disk drive is installed. With this menu item, print jobs that were set to be saved on the hard disk by using Job Retention on the Basic tab of the printer driver can be printed or deleted.
  • Page 49 Press Key Press until the desired user name appears. Press until the desired job name appears. Select PRINT PRINT DELETE Press the (Settings: Press the Menu/Select key. Printing begins. Select Press the Menu/Select key. was selected, the print job is deleted. was selected, the again.

  • Page 50: Entering The Password

    Entering the Password If the print job selected in the screen for entering the password appears. Follow the procedure described below to type in the four-digit password specified from the printer driver. Press the password. Press the Press the password. Continue these steps until all four digits of the password are specified.

  • Page 51: Print Menu

    PRINT MENU With this menu, printer information, such as the configuration page and the demo page, can be printed. PRINT MENU CONFIGURATION STATISTICS PAGE FONT LIST MENU MAP DIRECTORY LIST * This menu item appears only if an optional hard disk drive is installed.
  • Page 52 MENU MAP DIRECTORY LIST Settings PRINT/CANCEL Prints the menu map. Settings PRINT/CANCEL Prints the directory list of the hard disk. Configuration Menu Overview...

  • Page 53: Paper Menu

    PAPER MENU With this menu, the paper used for printing can be managed. PAPER MENU PAPER SOURCE DUPLEX COPIES **** COLLATE FINISHING SEPARATION IMAGE ****** ROTATION Configuration Menu Overview DEFAULT TRAY TRAY 1 ***** TRAY 2 ***** TRAY 3 TRAY 4 TRAY CHAINING TRAY MAPPING PAPER SIZE...
  • Page 54 * This menu item appears only when you select from the CUSTOM menu. TRAY 1/PAPER SIZE ** These menu items appear only if one or both of the optional lower feeder units are installed. *** This menu item appears only if the optional duplex unit (Duplex Option) is installed.
  • Page 55 All factory default values are shown in bold. PAPER DEFAULT SOURCE TRAY TRAY 1 Configuration Menu Overview Settings TRAY 1/TRAY 2/ TRAY 3/TRAY 4 The Lower Feeder Unit that is normally used can be specified. TRAY 3 TRAY 4 optional lower feeder units are installed. Settings PAPER ANY/LETTER/LEGAL/...
  • Page 56 Specify the paper size when custom-sized CUSTOM paper is loaded into Tray 1. SIZE The setting units can be switched between millimeters and inches with the DEFAULT MENU/PAPER/UNIT OF setting. MEASURE Setting range for MILLIMETERS (default) – 210 mm INCHES (default) –...
  • Page 57 TRAY 2 TRAY 3 TRAY 4 TRAY CHAINING Configuration Menu Overview Settings PAPER ANY/PLAIN PAPER/ TYPE RECYCLED/THICK 1/ THICK 2/LABEL/ TRANSPARENCY/ ENVELOPE/POSTCARD/ LETTERHEAD/GLOSSY 1/ GLOSSY 2 Select the setting for the type of paper loaded into Tray 1. Settings PAPER LETTER/A4 SIZE Select the setting for the size of paper...
  • Page 58 TRAY MAPPING Settings DUPLEX LONG EDGE of the paper for long-edge binding. SHORT EDGE sides of the paper for short-edge binding. The setting specified in the printer driver will override this menu setting. Settings COPIES Specify the number of copies to be printed. The setting specified in the printer driver will override this menu setting.
  • Page 59 Settings FIN- ISHING When tray. When put tray. When tray with each copy slightly shifted. When main output tray. The setting specified in the printer driver will override this menu setting. Settings SEPA- The paper is fed to the main output tray with each print job slightly RATION shifted.

  • Page 60: Quality Menu

    QUALITY MENU With this menu, settings for the print quality can be specified. QUALITY MENU COLOR MODE BRIGHTNESS HALFTONE EDGE ENHANCEMENT EDGE STRENGTH ECONOMY PRINT GLOSSY MODE PCL SETTING IMAGE PRINTING TEXT PRINTING GRAPHICS PRINTING IMAGE PRINTING TEXT PRINTING GRAPHICS PRINTING CONTRAST IMAGE PRINTING...
  • Page 61 PS SETTING Configuration Menu Overview TEXT PRINTING RGB SOURCE RGB INTENT RGB GRAY GRAPHICS RGB SOURCE PRINTING RGB INTENT RGB GRAY IMAGE PRINTING RGB SOURCE RGB INTENT RGB GRAY DESTINATION PROF TEXT PRINTING RGB SOURCE RGB INTENT RGB GRAY DESTINATION PROF GRAPHICS RGB SOURCE...
  • Page 62 CALIBRATION COLOR SEPARATION All factory default values are shown in bold. Settings COLOR MODE and white. Settings BRIGHT- NESS The brightness of the printed image can be adjusted. HALFTONE IMAGE PRINTING SIMULATION TONE CALIBRATION AIDC PROCESS CMYK DENSITY COLOR/GRAYSCALE is selected, the pages are printed in full color. COLOR is selected, the pages are printed in black GRAYSCALE...
  • Page 63 TEXT PRINTING GRAPHICS PRINTING EDGE IMAGE ENHANCE- PRINTING MENT Configuration Menu Overview Settings LINE ART/DETAIL/ SMOOTH Select how halftones in text are reproduced. is selected, halftones are LINE ART reproduced with high precision. is selected, halftones are DETAIL reproduced with detail. is selected, halftones are SMOOTH reproduced with smoothness.
  • Page 64 TEXT PRINTING GRAPHICS PRINTING Settings EDGE STRENGTH Select the desired amount that edges are emphasized. average amount. Settings Select whether text edges are emphasized. is selected, the edges are empha- sized. is selected, the edges are not emphasized. Settings Select whether graphic edges are emphasized.
  • Page 65 Settings ECONOMY PRINT Select whether to print graphics with a reduced density by reducing the amount of toner that is used. printing. when printing. Settings GLOSSY MODE Select whether to relax the limitations on the amount of toner used in order to widen the color reproduction range and produce glossy prints.
  • Page 66 CONTRAST SETTING IMAGE PRINTING Settings -15%/-10%/-5%/0%/ +5%/+10%/+15% The contrast of the image can be adjusted. Settings DEVICE COLOR/ SOURCE sRGB Specify the color space for RGB image data. DEVICE COLOR selected, no color space is specified. If RGB source profiles are downloaded with the Download Manager, they are available from the list of settings.
  • Page 67 TEXT PRINTING Configuration Menu Overview Settings COMPOSITE GRAY BLACK/BLACK AND GRAY/ BLACK ONLY Specify how black and grays are reproduced in RGB image data. COMPOSITE BLACK selected, black is reproduced using the CMYK colors. BLACK AND GRAY selected, black and gray are reproduced using black only.
  • Page 68 GRAPHICS PRINTING Settings VIVID/ INTENT PHOTOGRAPHIC Specify the characteristic applied when converting RGB text data to CMYK data. is selected, a vivid VIVID output is produced. PHOTOGRAPHIC selected, a brighter output is produced. Settings COMPOSITE GRAY BLACK/BLACK AND GRAY/ BLACK ONLY Specify how black and grays are reproduced in RGB text data.
  • Page 69 Configuration Menu Overview Settings VIVID/ INTENT PHOTOGRAPHIC Specify the characteristic applied when converting RGB GRAPHICS data to CMYK data. is selected, a vivid VIVID output is produced. PHOTOGRAPHIC selected, a brighter output is produced. Settings COMPOSITE GRAY BLACK/BLACK AND GRAY/ BLACK ONLY Specify how black and grays are reproduced in RGB...
  • Page 70 IMAGE SETTINGS PRINTING Settings DEVICE COLOR/ SOURCE sRGB/ AppleRGB/ AdobeRGB1998/ ColorMatchRGB BlueAdjustRGB Specify the color space for RGB image data. DEVICE COLOR selected, no color space is specified. If RGB source profiles are downloaded with the Download Manager, they are available from the list of settings.
  • Page 71 Configuration Menu Overview Settings COMPOSITE GRAY BLACK/BLACK AND GRAY/ BLACK ONLY Specify how black and grays are reproduced in RGB image data. COMPOSITE BLACK selected, black is reproduced using the CMYK colors. BLACK AND GRAY selected, black and gray are reproduced using black only.
  • Page 72 TEXT PRINTING Settings DEVICE COLOR/ SOURCE sRGB/ AppleRGB/ AdobeRGB1998/ ColorMatchRGB BlueAdjustRGB Specify the color space for RGB text data. DEVICE COLOR selected, no color space is specified. If RGB source profiles are downloaded with the Download Manager, they are available from the list of settings.
  • Page 73 Configuration Menu Overview Settings COMPOSITE GRAY BLACK/BLACK AND GRAY/ BLACK ONLY Specify how black and grays are reproduced in RGB text data. COMPOSITE BLACK selected, black is reproduced using the CMYK colors. BLACK AND GRAY selected, black and gray are reproduced using black only.
  • Page 74 GRAPHICS PRINTING Settings DEVICE COLOR/ SOURCE sRGB/ AppleRGB/ AdobeRGB1998/ ColorMatchRGB BlueAdjustRGB Specify the color space for RGB image data. DEVICE COLOR selected, no color space is specified. If RGB source profiles are downloaded with the Download Manager, they are available from the list of settings.
  • Page 75 Configuration Menu Overview Settings COMPOSITE GRAY BLACK/BLACK AND GRAY/ BLACK ONLY Specify how black and grays are reproduced in RGB image data. COMPOSITE BLACK selected, black is reproduced using the CMYK colors. BLACK AND GRAY selected, black and gray are reproduced using black only.
  • Page 76 SIMULATION Settings SIMU- NONE/SWOP/ LATION Euroscale/ PROF CommercialPre ss/TOYO/DIC Specify the simulation profile. is selected, no NONE simulation profile is specified. If simulation profiles are downloaded with the Download Manager, they are available from the list of settings. Settings SIMU- RELATIVE LATION COLOR/...
  • Page 77 CALIBRA- TONE TION CALIBRATION AIDC PROCESS Configuration Menu Overview Settings CMYK COMPOSITE GRAY BLACK/BLACK AND GRAY/ BLACK ONLY Specify how black and grays are reproduced using the four CMYK colors. COMPOSITE BLACK selected, black is reproduced using the CMYK colors. BLACK AND GRAY selected, black and gray are reproduced using black only.
  • Page 78 CMYK DENSITY Settings COLOR SEPARA- TION contents of a color page is separated into the color pages for yellow, magenta, cyan and black, and each is printed with black gradations as individual pages. The printing order is yellow, magenta, cyan, then black. normal color separation is performed.

  • Page 79: Memory Direct

    In addition, this menu item does not appear if public user access has not been permitted through authentication settings. For details on the authentica- tion settings, refer to the bizhub C30P Reference Guide on the Utilities and Documentation CD-ROM. With this memu, settings for “memory direct” function can be specified.
  • Page 80 DUPLEX: COPIES:1 Settings LETTER/LEGAL/EXECUTIVE/A4/ A5/A6/B5(JIS)/B6(JIS)/GOVT LETTER/STATEMENT/FOLIO/SP FOLIO/UK QUARTO/FOOLSCAP/ GOVT LEGAL/16K/PHOTO 10×15/ KAI 16/KAI 32/ENV C5/ENV C6/ENV DL/ENV MONARCH/ENV CHOU#3/ENV CHOU#4/B5(ISO)/ ENV #10/ENV YOU#4/JPOST/ JPOST-D/CUSTOM Change the size of the paper. Depending on the setting selected for DEFAULT MENU/PAPER/UNIT OF MEASURE PHOTO 10×15 PHOTO 4×6 This menu item does not appear if the...
  • Page 81 COLLATE MAIN TRAY Settings TYPE Select the type of files to be displayed. FILES Configuration Menu Overview Settings ON/OFF Select whether to collate the copies. is selected, collated printing is performed. is selected, collated printing is not performed. This menu item appears only if the optional hard disk drive or a CompactFlash card of 1GB or more is installed.

  • Page 82: Camera Direct

    In addition, this menu item does not appear if public user access has not been permitted through authentication settings. For details on the authentica- tion settings, refer to the bizhub C30P Reference Guide on the Utilities and Documentation CD-ROM. With this menu, settings for “camera direct” function can be specified.
  • Page 83 All factory default values are shown in bold. Settings PAPER SOURCE Select the Lower Feeder Unit that is used for camera direct printing. Settings LAYOUT Specify the number of images printed on a single sheet of media. When set to sheet of media.
  • Page 84 GLOSSY MODE SOURCE INTENT RGB GRAY Settings ON/OFF Select whether to relax the limitations on the amount of toner used in order to widen the color reproduc- tion range and produce glossy prints. is selected, glossy prints are produced. is selected, glossy prints are not produced. is selected, the amount of toner used is not reduced when printing, even if is set to...
  • Page 85 HALFTONE Configuration Menu Overview Settings LINE ART/DETAIL/SMOOTH Select how halftones are reproduced. is selected, halftones are reproduced LINE ART with high precision. is selected, halftones are reproduced DETAIL with detail. is selected, halftones are reproduced SMOOTH with smoothness.

  • Page 86: Interface Menu

    INTERFACE MENU With this menu, interface settings can be specified. Restart the printer after changing settings in the INTERFACE MENU JOB TIMEOUT ETHERNET MEMORY DIRECT CAMERA DIRECT ** This menu item appears only if the optional hard disk drive or a CompactFlash card is installed.
  • Page 87 All factory default values are shown in bold. Settings TIME- Specify the timeout interval for a print job being received. ETHER- TCP/IP Configuration Menu Overview 5 seconds-15 seconds-300 seconds Settings ENABLE YES/NO is selected, TCP/IP is enabled. is selected, TCP/IP is disabled. Setting 000.000.000.000 ADDRESS...
  • Page 88 NETWARE ENABLE APPLE TALK SPEED/ DUPLEX Settings MEMORY DIRECT Select whether to enable or disable memory direct printing. ENABLE DISABLE Settings CAMERA DIRECT Select whether to enable or disable camera direct printing. ENABLE DISABLE Settings TELNET ENABLE/DISABLE Select whether to enable or disable Tel- net transmissions.

  • Page 89: Sys Default Menu

    SYS DEFAULT MENU With this menu, settings can be specified to adjust the operation of the printer, such as the display language of the message window and the time until the machine enters Energy Saver mode. SYS DEFAULT MENU LANGUAGE EMULATION PAPER GRAYSCALE...
  • Page 90 HOLD JOB TIMEOUT ENERGY SAVER ENERGY SAVER TIME MENU TIMEOUT CONTRAST SECURITY CLOCK HDD FORMAT CARD FOR- RESTORE DEFAULTS CHANGE PASSWORD LOCK PANEL DATE (xx.xx.xx) TIME TIME ZONE USER AREA ONLY USER AREA ONLY RESTORE NETWORK RESTORE PRINTER RESTORE ALL Configuration Menu Overview...
  • Page 91 ENABLE WARNING * These menu items appear only if an optional hard disk drive is installed. ** This menu item appears when you select except ENERGY SAVER *** This menu item appears only if an optional CompactFlash card is installed. **** These menu items appear only if corresponding optional lower feeder unit is installed.
  • Page 92 All factory default values are shown in bold. Settings LAN- GUAGE The display language of the message window can be changed to the selected language. The language selections appear in the message window in the corresponding language. For example, DEUTSCH EMULA- DEF.
  • Page 93 Configuration Menu Overview Settings CR/LF CR=CR LF=LF/CR=CRLF MAP- LF=LF/CR=CR PING LF=LFCR/CR=CRLF LF=LFCR Select the definitions of the CR/LF codes in the PCL language. Settings LINES 5-60-128 Specify the number of lines per page in the PAGE PCL language. Settings FONT FONT SOURCE NUMBER...
  • Page 94 PAPER DEFAULT PAPER Settings PAPER LETTER/LEGAL/EXECU- SIZE TIVE/A4/A5/A6/ B5(JIS)/B6(JIS)/GOVT LETTER/STATEMENT/ FOLIO/SP FOLIO/UK QUARTO/FOOLSCAP/GOVT LEGAL/16K/PHOTO 10×15/KAI 16/KAI 32/ ENV C5/ENV C6/ENV DL/ ENV MONARCH/ENV CHOU#3/ENV CHOU#4/ B5(ISO)/ENV #10/ENV YOU#4/JPOST/JPOST-D/ CUSTOM Select the size of media that is normally used. Depending on the setting selected SYS DEFAULT MENU/ PAPER/UNIT OF MEASURE PHOTO 10×15...
  • Page 95 Configuration Menu Overview Specify the media size when CUSTOM is set to SIZE SIZE The setting units can be switched between millimeters and inches with the DEFAULT MENU/PAPER/UNIT OF setting. MEASURE Setting range for MILLIMETERS (default) – 210 mm INCHES (default) –...
  • Page 96 UNIT MEA- SURE Settings GRAY SCALE Specify the operation to be performed for black-and-white PAGE pages in a job specified for color printing. AUTO ing to the first page of the job. GRAYSCALE PRINT automatically performed depending on each page. COLOR PRINT for a black-and-white page.
  • Page 97 Settings HOLD TIME Specify the length of time until print jobs saved on the hard disk are deleted. If at a specific time. Settings ENERGY SAVER according to the length of time specified for TIME mode. Settings ENERGY SAVER TIME Specify the length of time until the machine enters Energy Saver mode.
  • Page 98 SECU- CHANGE RITY PASS- WORD LOCK PANEL CLOCK DATE (xx.xx. TIME TIME ZONE USER FORMAT AREA ONLY CARD USER FORMAT AREA ONLY Specify the password for locking the control panel. If the password is set to 0000 panel is not locked. In order to lock the control panel, be sure to specify a password other than Settings OFF/MINIMUM/ON...
  • Page 99 RESTORE RESTORE DEFAULTS NETWORK RESTORE PRINTER RESTORE ENABLE PAPER WARNING EMPTY TONER I-UNIT Configuration Menu Overview Reset the network settings to their defaults. When this menu item is selected, the printer is automatically restarted. Reset the printer settings to their defaults. When this menu item is selected, the printer is automatically restarted.

  • Page 100: Maintenance Menu

    MAINTENANCE MENU With this menu, maintenance on this printer can be performed. In order to use this menu, the administrator password must be entered. MAINTENANCE MENU PRINT MENU ALIGNMENT EVENT LOG HALFTONE 64 CYAN/MAGENTA/ YELLOW/BLACK 64 HALFTONE 128 CYAN/MAGENTA/ YELLOW/BLACK 128 HALFTONE 256 CYAN/MAGENTA/ YELLOW/BLACK 256...
  • Page 101 SUPPLIES Configuration Menu Overview DUPLEX PASS MANUAL DUPLEX IMG ADJ CYAN THICK MAGENTA YELLOW BLACK IMG ADJ BLACK REPLACE TRANS. BELT TRANS. ROLLER FUSER UNIT ENVELOPE LABEL GLOSSY 1 GLOSSY 2 PLAIN PAPER PLAIN PAPER THICK 1 THICK 2 POSTCARD ENVELOPE LABEL GLOSSY 1...
  • Page 102 All factory default values are shown in bold. PRINT EVENT MENU HALF- TONE HALF- TONE HALF- TONE GRADA- TION ALIGN- MENT ADJUST MENT Settings PRINT/CANCEL Prints the event log. Settings CYAN/ PRINT/CANCEL MAGENTA/ Print cyan/magenta/yellow/black half- YELLOW/ tones at 64 gradations. BLACK Settings CYAN/...
  • Page 103 LEFT ADJUST MENT LEFT DUPLEX TRANS- POWER Configuration Menu Overview Settings LEFT -15-15 When printing on media in Tray 1, specify TRAY1 the size of the left margin. Settings LEFT -15-15 When printing on media in Tray 2, specify TRAY2 the size of the left margin.
  • Page 104 Settings THICK When printing on thick 1 using simplex pass, correct the sec- ondary image transfer current. Settings THICK When printing on thick 2 using simplex pass, correct the sec- ondary image transfer current. Settings POST- CARD When printing on postcard using simplex pass, correct the secondary image transfer current.
  • Page 105 Configuration Menu Overview Settings MANUAL PLAIN DUPLEX PAPER When printing on plain paper using manual duplex pass, correct the secondary image transfer current. Settings THICK When printing on THICK 1 using manual duplex pass, correct the secondary image transfer current. Settings THICK When printing on THICK 2...

  • Page 106: Service Menu

    THICK BLACK SUP- PLIES PLACE SERVICE MENU With this menu, the service representative can adjust the printer and perform maintenance operations. This menu cannot be used by the user. Settings GLOSSY When printing on GLOSSY 2 using manual duplex pass, correct the secondary image transfer current.

  • Page 107: Camera Direct

    Camera Direct...

  • Page 108: Camera Direct

    If a digital camera with PictBridge (1.0 or later) is connected to the printer through the Camera Direct Print port, images stored on the digital camera can be printed directly from the printer. For details on using the digital camera, refer to your digital cameras manual.

  • Page 109: Memory Direct

    Memory Direct...

  • Page 110: Memory Direct

    For details on specifying settings with the control panel, refer to “MEMORY DIRECT” on page 65. Printing From a Connected USB Memory Device Plug the USB memory device into the KONICA MINOLTA Digi- tal Camera Direct Print Port. The USB icon appears in the upper-right corner of the mes- sage window, and the menu appears.

  • Page 111: Using Media

    Using Media...

  • Page 112: Media Specifications

    What types and sizes of media can I load? Media Letter Legal Statement Executive B5 (JIS) Folio SP Folio Foolscap UK Quarto Government Letter Government Legal Photo Size 4 /10 x 15 " " 16 K Kai 16 Kai 32 Japanese Postcard Japanese Postcard-D B5 (ISO)

  • Page 113: Media Types

    For custom sizes, use the printer driver to specify the settings within the ranges shown in the above table. Media Types Before purchasing a large quantity of special media, do a trial print with the same media and check the print quality. Keep media on a flat, level surface in its original wrapper until it is time to load it.
  • Page 114 Carbon backed Unapproved iron-on transfer media (such as heat-sensitive paper, heat-pressure paper, and heat-press transfer paper) Cold-water-transfer paper Pressure sensitive Designed specifically for inkjet printers (such as superfine paper, glossy paper, glossy film, and postcards) Paper that has already been printed on –...

  • Page 115: Thick Stock

    Thick Stock Paper thicker than 90 g/m thick stock to ensure acceptable performance and to ensure that the image does not shift. Capacity Tray 1 (Manual Feed Tray) Tray 2/3/4 Orientation Face down Driver Thick 1 (91-150 g/m Media Type Thick 2 (151-210 g/m Weight 91–210 g/m²...

  • Page 116: Labels

    Duplexing Not supported Glossy Not supported Mode Use envelopes that are Common office envelopes approved for laser printing with diagonal joints, sharp folds and edges, and ordinary gummed flaps Because the envelopes pass through heated rollers, the gummed area on the flaps may seal. Using envelopes with emulsion-based glue avoids this problem.

  • Page 117: Letterhead

    Driver Label Media Type Weight 60–163 g/m² (16–43 lb bond) Duplexing Not supported Glossy ON/OFF Mode Use label sheets that are Recommended for laser printers Letter or A4 size (adhesive label stock) DO NOT use label sheets that Have labels that easily peel off or have parts of the label already removed Have backing sheets that have peeled away or have exposed adhesive Labels may stick to the fuser, causing them to peel off and media misfeeds to occur.

  • Page 118: Postcards

    Weight 60–90 g/m² (16–24 lb) Duplexing See page 98 for supported sizes. Glossy ON/OFF Mode Postcards Try printing your data on a sheet of plain paper first to check placement. Capacity Tray 1 (Manual Feed Tray) Tray 2/3/4 Orientation Face down Driver Postcard Media Type...

  • Page 119: Transparencies

    Transparencies Do not fan transparencies before loading them. Resulting static elec- tricity may cause printing errors. If you touch the face of the transparencies with your bare hands, print quality may be affected. Keep the printer path clean. Transparencies are especially sensitive to a dirty media path.

  • Page 120: Glossy Media

    Glossy Media Test all glossy media to ensure acceptable performance and to ensure that the image does not shift. Capacity Tray 1 (Manual Feed Tray) Tray 2/3/4 Orientation Face down Driver Glossy 1 Media Type Glossy 2 Weight Glossy 1 (100–150 g/m²) Glossy 2 (128–210 g/m²) Duplexing Not supported...

  • Page 121: What Is The Guaranteed Imageable (Printable) Area

    What Is the Guaranteed Imageable (Printable) Area? The printable area on all media sizes is up to 4 mm (0.157") from the edges of the media. Each media size has a specific image- able area, the maximum area on which the printer can print clearly and without distortion.

  • Page 122: Loading Media

    Loading Media How do I load media? Take off the top and bottom sheets of a ream of paper. Holding a stack of approx- imately 100 sheets at a time, fan the stack to prevent static buildup before inserting it in a tray. Do not fan transparencies.
  • Page 123 Slide the media guides to pro- vide more space between them. Press down on the center of the paper-lifting plate until the left and right locking tabs (white) lock into place. Load the paper face down in the tray. Loading Media...

  • Page 124: Other Media

    Do not load paper above the line. Up to 100 sheets (80 g/m paper can be loaded into the tray at one time. Slide the media guides against the edges of the paper. Select PAPER MENU/PAPER SOURCE/TRAY 1/PAPER SIZE PAPER TYPE the size and type of paper that are loaded.

  • Page 125: Loading Envelopes

    Loading Envelopes Pull the lever, and then open the right side cover. Before opening the right side cover, fold up Tray Open the door at the side of the right side cover. Loading Media...
  • Page 126 Turn the two dials on the fuser unit to the setting for envelopes. Plain paper Envelope Close the door at the side of the right side cover. Loading Media...
  • Page 127 Close the right side cover. Open Tray 1. Slide the media guides to pro- vide more space between them. Loading Media...
  • Page 128 Press down on the center of the paper-lifting plate until the left and right locking tabs (white) lock into place. Load the envelopes flap side up in the tray. Before loading enve- lopes, press them down to make sure that all air is removed, and make sure that the folds of the flaps are firmly pressed;...

  • Page 129: Loading Label Sheets/Postcards/Thick Stock/Glossy Media And Transparencies

    Slide the media guides against the edges of the envelopes. Before printing on plain paper, be sure to return the dials on the fuser unit to the setting for plain paper. Select PAPER MENU/PAPER SOURCE/TRAY 1/PAPER SIZE PAPER TYPE the size and type of paper that are loaded. See also “PAPER MENU” on page 39.
  • Page 130 Slide the media guides to pro- vide more space between them. Press down on the center of the paper-lifting plate until the left and right locking tabs (white) lock into place. Load the media face down in the tray. Up to 20 sheets can be loaded into the tray at one time.
  • Page 131 Slide the media guides against the edges of the media. Select PAPER MENU/PAPER SOURCE/TRAY 1/PAPER SIZE PAPER TYPE the size and type of paper that are loaded. See also “PAPER MENU” on page 39. When printing from Tray 1 with the corresponding Paper Source set- ting in the printer driver Tray1 (Manual Feed), it is not necessary to change the configuration menu setting.

  • Page 132: Loading Banner Paper

    Loading Banner Paper Paper up to 1200 mm long can be loaded into the bypass tray and printed one at a time. Open Tray 1. Slide the media guides to pro- vide more space between them. Press down on the center of the paper-lifting plate until the left and right locking tabs (white) lock into place.
  • Page 133 With the side of the banner paper to be printed on facing down, insert the end of the paper as much as possible into the feed slot. One sheet of banner paper can be loaded into the tray at one time. In order to avoid toner smudges, do not load curled paper.
  • Page 134 Secure the banner paper with the left and right media guides. When printing multiple copies on banner paper, repeat the procedure starting from step 2. Select Tray 1(Manual Feed) from the Paper Source list and specify a cus- tom size in the Original Size list of the printer driver, and then print. Loading Media...

  • Page 135: Tray 2

    Tray 2 Loading Plain Paper Pull out Tray 2. Press down the media pressure plate to lock it into place. Loading Media...
  • Page 136 Load the paper face up in the tray. Do not load above the M mark. Up to 500 sheets (80 g/m paper can be loaded into the tray at one time. Close Tray 2. Select PAPER MENU/PAPER SOURCE/TRAY 2/PAPER SIZE PAPER TYPE the size and type of paper that are loaded.

  • Page 137: Tray 3/4 (Optional Lower Feeder Units)

    Tray 3/4 (Optional Lower Feeder Units) Loading Plain Paper Pull out Tray 3 (Tray 4). Press down the media pressure plate to lock it into place. Slide the media guides to pro- vide more space between them. Loading Media...
  • Page 138 Load the paper face up in the tray. Do not load above the M mark. Up to 500 sheets (80 g/m paper can be loaded into the tray at one time. Slide the media guides against the edges of the paper. [22 lb]) of plain Loading Media...
  • Page 139 Close Tray 3 (Tray 4). Select PAPER MENU/PAPER SOURCE/TRAY 3 TRAY 4 in the configuration menu, and then select the setting for PAPER TYPE the type of paper that is loaded. See also “PAPER MENU” on page 39. Loading Media...

  • Page 140: Duplexing

    Select paper with high opacity for duplex (Double-Sided) printing. Opacity refers to how effectively paper blocks out what is written on the opposite side of the page. If the paper has low opacity (high translucency), then the printed data from one side of the page will show through to the other side. Check your application for margin information.

  • Page 141: Output Tray

    In addition, if “N-up” has been set to “Booklet”, autoduplex printing is per- formed. The following Order settings are available when “Booklet” is selected. Load plain paper into the tray. From the printer driver, specify duplex (Double-Sided) printing (Layout tab in Windows).

  • Page 142: Finishing

    When the optional staple finisher is installed, job separation, offset and staple printing can be performed. For the installation procedure, refer to “Staple Fin- isher” on page 244. Settings can be specified for job separation, offset and staple printing by selecting MENU Use the following paper with job separation, offset and staple printing.

  • Page 143: Offset Printing

    Offset Printing If offset printing is selected, the paper is fed out shifted as shown below. When PAPER MENU/COLLATE in sets as shown below. - When COLLATE Staple printing Pages are stapled and fed out by job or by copy set as shown below. Page in the portrait orientation are stapled in the upper-left corner.

  • Page 144: Media Storage

    Media Storage How do I store media? Keep media on a flat, level surface in its original wrapper until it is time to load it. Media that has been stored for a long time out of its packaging may dry up too much and cause misfeeding.
  • Page 145 Replacing Consumables...

  • Page 146: Replacing Consumables

    Note Failure to follow instructions as outlined in this manual could result in voiding your warranty. Note If an error message ( appears, print out the configuration page, and then check the status of the other consumables. For details on the error messages, refer to “Error Messages (Warning:)”...
  • Page 147 When replacing a toner cartridge, refer to the following table. For optimum print quality and performance, use only approved KONICA MINOLTA toner cartridges for your specific printer type, as listed in the table below. You can find your printer type and the toner cartridge part numbers on the consum- ables reorder label inside the front cover your printer.
  • Page 148 Level during handling and storage. Do not hold, stand or store cartridges on their ends or turn them upside down; the toner inside the cartridges may become caked or unequally distributed. Away from salty air and corrosive gases such as aerosols. Replacing Consumables...

  • Page 149: Replacing A Toner Cartridge

    Replacing a Toner Cartridge Note Be careful not to spill toner while replacing a toner cartridge. If toner spills, immediately wipe it off with a soft, dry cloth. on the TONER LOW , the message toner) appears when toner cartridge becomes empty. Follow the steps below to replace the toner cartridge.
  • Page 150 Lower the lever to release the lock. Grab the handle of the toner car- tridge to be replaced, and then pull out the cartridge. Note Dispose of the used toner cartridge according to your local regulations. Do not burn the toner cartridge. For details, refer to “About Toner Cartridges”...
  • Page 151 Shake the cartridge to distribute the toner. Make sure that the toner car- tridge is the same color as the printer compartment, and then insert the toner cartridge into the printer. Make sure that the toner car- tridge is securely installed, and then peel off the protective film.
  • Page 152 Raise the front lever to its origi- nal position. Pull the lever to the left to lock it in place. The front lever should be securely returned to its original position; other- wise, the front cover of the printer cannot be closed.

  • Page 153: Replacing A Print Unit

    Replacing a Print Unit When replacing a print unit, refer to the following table. For optimum print quality and performance, use only approved KONICA MINOLTA print units for your specific printer type, as listed in the table below. You can find your printer type and the print unit part numbers on the consumables reorder label inside the front cover your printer.
  • Page 154 Open the printer’s front cover. Pull the front lever to the right. Lower the lever to release the lock. Replacing Consumables...
  • Page 155 Press down the area marked “Push” on the print unit to be replaced, and then slide the unit all the way out of the printer. Note Dispose of the used print unit according to your local regulations. Do not burn the print unit. Check the color of the new print unit to be installed.
  • Page 156 Hold the print unit with both hands, and then shake it twice as shown in the illustration. Do not grab the bottom of the bag; otherwise, the print unit may be dam- aged, resulting in decreased print quality. Remove all packing tape from the print unit.
  • Page 157 Make sure that the new print unit to be installed is the same color as the printer compartment, and then install the print unit in the printer. Raise the front lever to its origi- nal position. Pull the lever to the left to lock it in place.
  • Page 158 Close the front cover. Replacing Consumables...

  • Page 159: Replacing The Waste Toner Bottle

    Replacing the Waste Toner Bottle When the waste toner bottle becomes full, the message FULL/REPLACE BOTTLE stops and will not start again until the waste toner bottle is replaced. Open the printer’s front cover. Turn the dial on the waste toner bottle counterclockwise until it is in the unlock position.
  • Page 160 Open the left and right handles of the waste toner bottle. Grab the left and right handles of the waste toner bottle, and then slowly pull out the bottle. Be careful since some waste toner may spill if the lock is closed when the waste toner bottle is removed.
  • Page 161 Slide the waste toner bottle all the way into the printer. Turn the dial clockwise until the waste toner bottle is in the locked position. Unlock Lock Replacing Consumables...

  • Page 162: Replacing The Transfer Roller

    Close the front cover. If the waste toner bottle is not fully inserted or if the dial is not locked, the front cover cannot be closed. Replacing the Transfer Roller When the time to replace the transfer roller is reached, the message TRANS.ROLLER/END OF LIFE after this message appears;...
  • Page 163 While pushing the levers to the inside, move the roller presser toward you. While continuing to press the levers, remove the transfer roller. Prepare a new transfer roller. While pressing the levers, insert the shaft of the transfer roller into the bearings. Replacing Consumables...
  • Page 164 Move the levers away from you until it snaps into place. Close the right side cover. Reset the counter in the REPLACE/TRANS. ROLLER Replace the ozone filter, using the following procedure. MAINTENANCE MENU/SUPPLIES/ menu. Replacing Consumables...

  • Page 165: Replacing The Ozone Filter

    Replacing the Ozone Filter Remove the ozone filter from the printer. Slide the new ozone filter into the printer until it snaps into place. Replacing Consumables...

  • Page 166: Replacing The Transfer Belt Unit

    Replacing the Transfer Belt Unit When the time to replace the transfer belt unit is reached, the message TRANS. BELT/END OF LIFE this message appears; however, since the print quality is reduced, the trans- fer belt unit should be replaced immediately. Open the printer’s front cover.
  • Page 167 Using a coin, remove the four screws on the left side. Be careful not to lose the screws. Remove the left-side cover. Pull the lever, and then open the right side cover. Before opening the right side cover, fold up Tray 1. Replacing Consumables...
  • Page 168 Use a coin to loosen the screws securing the transfer belt unit. On the left side, pull to the right the blue shutter lever for the transfer belt unit. Do not remove the blue lever. From the side where the left side cover was removed, hold the arm, and then carefully pull out the transfer belt unit.
  • Page 169 Remove all packing tape from the transfer belt unit. Remove the protective cover from the transfer belt unit. Prepare a new transfer belt unit. Be careful not to touch the surface of the belt. Do not remove the blue lever. Insert the new transfer belt unit along the rails.
  • Page 170 On the left side, pull to the left the blue shutter lever for the transfer belt unit. From the right side cover side, tighten the screws to secure the transfer belt unit and then close the right side cover. Close the right side cover. Replacing Consumables...
  • Page 171 Attach the left-side cover. Tighten the four screws on the left side. Install the print unit and waste toner bottle. For details on installing the print unit or waste toner bottle, refer to “Replacing a Print Unit” on page 139 or “Replac- ing the Waste Toner Bot- tle”...

  • Page 172: Replacing The Backup Battery

    Close the front cover. Reset the counter in the REPLACE/TRANS. BELT Replacing the Backup Battery If the backup battery is dead, the printer’s date and time cannot be retained. Follow the procedure described below to replace the backup battery. Note It’s very important to protect the printer controller board and any associated circuit boards from electrostatic damage.
  • Page 173 Using a screwdriver, remove the screw. Then, slide the rear cover to the right and remove it. Using a screwdriver, loosen the seven screws. (Do not remove them from the printer.) Slide the panel slightly to the right and lift it off the printer. Replacing Consumables...
  • Page 174 Remove the hook, and then remove the backup battery. Insert a new backup battery. When inserting the new backup battery, be sure that the + side faces toward the left. Reinstall the panel and tighten the seven screws. Attach the rear cover. Reconnect all interface cables.

  • Page 175: Replacing The Staple

    on the DATE and use TIME time. Replacing the Staple When there are no more staples, the message Replace the staple cartridge. Open the stapler cover. Pull out the stapling unit. Replacing Consumables SYS DEFAULT MENU/CLOCK on the SYS DEFAULT MENU/CLOCK menu to set the date, menu to set the appears.
  • Page 176 Pull out the stapler. Remove the empty cartridge, and then insert the new one. Replacing Consumables...
  • Page 177 Install the stapler. Install the stapling unit. Close the stapler cover. Replacing Consumables...

  • Page 179: Maintaining The Printer

    Maintaining the Printer...

  • Page 180: Maintaining The Printer

    CAUTION Read all caution and warning labels carefully, making sure to follow any instructions contained in them. These labels are located on the inside of the printer’s covers and the interior of the printer body. Handle the printer with care to preserve its life. Abuse handling may cause damage and void your warranty.
  • Page 181 Do not leave the printer’s covers open for any length of time, especially in well-lit places; light may damage the toner cartridges. Do not open the printer during printing. Do not tap media stacks on the printer. Do not lubricate or disassemble the printer. Do not tilt the printer.

  • Page 182: Cleaning The Printer

    If you get toner on your skin, wash it off with cool water and a mild soap. CAUTION If you get toner in your eyes, wash it out immediately with cool water and consult a doctor. Make sure any parts removed during cleaning are replaced before you plug in the printer.

  • Page 183: Media Rollers

    Media Rollers The accumulation of paper dust and other debris on the media rollers can cause media-feeding problems. Cleaning the Media Feed Rollers (Manual Feed Tray) Open Tray 1. Press down on the center of the paper-lifting plate until the left and right locking tabs (white) lock into place.
  • Page 184 Clean the media feed rollers by wiping them with a soft, dry cloth. Close the tray. Cleaning the Printer...

  • Page 185: Cleaning The Media Feed Rollers (Tray 2/3/4)

    Cleaning the Media Feed Rollers (Tray 2/3/4) Pull out the tray. Clean the media feed rollers by wiping them with a soft, dry cloth. Close the tray. Cleaning the Printer...

  • Page 186: Cleaning The Duplex Option Feed Rollers

    Cleaning the Duplex Option Feed Rollers Open the duplex cover. Clean the feed rollers by wiping them with a soft, dry cloth. Close the duplex cover. Cleaning the Printer...

  • Page 187: Cleaning The Media Transfer Rollers For Tray 3 And 4

    Cleaning the Media Transfer Rollers for Tray 3 and 4 Open the right side cover of Tray 3 (Tray 4). Before opening the right side cover of Tray 3 (Tray 4), fold up Tray 1. Clean the media transfer rollers by wiping them with a soft, dry cloth.

  • Page 188: Cleaning The Laser Lens

    Cleaning the Laser Lens This printer is constructed with four laser lenses. Clean all lenses as described below. The laser lens cleaning tool should be attached to the inside of the front cover. Open the printer’s front cover and remove the cleaning tool from the machine’s front cover.

  • Page 189: Troubleshooting

    Troubleshooting...

  • Page 190: Introduction

    This chapter provides information to aid you in resolving printer problems you may encounter, or at least guide you to the proper sources for help. Printing the configuration page Preventing media misfeeds Understanding the media path Clearing media misfeeds Solving problems with media misfeeds Solving other problems Solving problems with printing quality Status, error, and service messages...

  • Page 191: Preventing Media Misfeeds

    Preventing Media Misfeeds Make sure that... Media matches the printer specifications. Media is flat, especially on the leading edge. The printer is on a hard, flat, level surface. You store media in a dry location away from moisture and humidity. You remove transparencies from the output tray immediately after printing to avoid static buildup.

  • Page 192: Understanding The Media Path

    Understanding the printer’s media path will help you locate media misfeeds 1 Toner cartridge 2 Relay unit 3 Fuser unit 4 Duplex option 5 Tray 1 (Manual feed tray) 6 Tray 4 (optional) 7 Tray 3 (optional) 8 Tray 2 9 Laser 10 Print unit 11 Transfer belt unit...

  • Page 193: Clearing Media Misfeeds

    To avoid damage, always remove misfed media gently, without tearing it. Any piece of media left in the printer, whether large or small, can obstruct the media path and cause further misfeeds. Do not reload media that has misfed. Note The image is not fixed on the media before the fusing process.

  • Page 194: Media Misfeed Messages And Clearing Procedures

    Media Misfeed Messages and Clearing Procedures Media Misfeed Message PAPER JAM TRAY 2 PAPER JAM TRAY 3 PAPER JAM TRAY 4 PAPER JAM DUPLEX 1 PAPER JAM DUPLEX 2 PAPER JAM FUSER/EXIT PAPER JAM TRAY 1 PAPER JAM SECOND TRANS PAPER JAM VERTICAL TRANS PAPER JAM...

  • Page 195: Clearing A Media Misfeed In Tray 2

    Clearing a Media Misfeed in Tray 2 Pull the lever, and then open the right side cover. Before opening the right side cover, fold up Tray Carefully pull out the misfed media. Clearing Media Misfeeds...
  • Page 196 CAUTION The area around the fuser unit is extremely hot. Touching anything other than the indicated levers and dials may result in burns. If you get burned, immediately cool the skin under cold water, and then seek professional medical attention. Note Decreased print quality may result if the surface of the image...
  • Page 197 Close the right side cover. Pull out Tray 2, and then remove all media from the tray. Fan the media you removed and then align it well. Clearing Media Misfeeds...
  • Page 198 Load the media face up in Tray 2. Make sure that the media is flat. Do not load paper above the M mark. Close Tray 2. Clearing Media Misfeeds...

  • Page 199: Clearing A Media Misfeed In Tray 3/4

    Clearing a Media Misfeed in Tray 3/4 Open the right side cover of Tray 3 (Tray 4). Before opening the right side cover of Tray 3 (Tray 4), fold up Tray 1. Carefully pull out the misfed media. Close the right side cover of Tray 3 (Tray 4).
  • Page 200 Pull out Tray 3 (Tray 4), and then remove all paper from the tray. Fan the paper you removed and then align it well. Load the paper face up in Tray 3 (Tray 4). Make sure that the paper is flat. Do not load paper above the M mark.

  • Page 201: Clearing A Media Misfeed From The Duplex Option

    Clearing a Media Misfeed from the Duplex Option Open the duplex cover. Carefully pull out the misfed media. Close the duplex cover. Clearing Media Misfeeds...

  • Page 202: Clearing A Media Misfeed From The Fuser Unit

    Clearing a Media Misfeed from the Fuser Unit Pull the lever, and then open the right side cover. Before opening the right side cover, fold up Tray Push up the levers of the fuser unit cover, and then open the cover.
  • Page 203 CAUTION The area around the fuser unit is extremely hot. Touching anything other than the indicated levers and dials may result in burns. If you get burned, immediately cool the skin under cold water, and then seek professional medical attention. Note Decreased print quality may result if the surface of the image...
  • Page 204 Push down the levers. Close the right side cover. Clearing Media Misfeeds...

  • Page 205: Clearing A Media Misfeed From Tray 1 (Manual Feed Tray) And Transfer Roller

    Clearing a Media Misfeed from Tray 1 (Manual Feed Tray) and Transfer Roller Pull the lever, and then open the right side cover. Before opening the right side cover, fold up Tray Carefully pull out the misfed media. Clearing Media Misfeeds...
  • Page 206 CAUTION The area around the fuser unit is extremely hot. Touching anything other than the indicated levers and dials may result in burns. If you get burned, immediately cool the skin under cold water, and then seek professional medical attention. Note Decreased print quality may result if the surface of the image...

  • Page 207: Relay Unit

    Close the right side cover. Relay Unit Open the upper cover. Carefully pull out the misfed media. Clearing Media Misfeeds...

  • Page 208: Staple Finisher (Case 1)

    Staple Finisher (Case 1) If the media misfeed occurred between the relay unit and the top of the staple finisher, follow the procedure described below to remove the misfed media. Open the finisher cover. Carefully pull out the misfed media. Clearing Media Misfeeds...

  • Page 209: Staple Finisher (Case 2)

    Staple Finisher (Case 2) If the media can be seen from the sub output tray, follow the procedure described below to remove the misfed media. Open the finisher cover. Carefully pull out the misfed media. Clearing Media Misfeeds...

  • Page 210: Staple Finisher (Case 3)

    Staple Finisher (Case 3) If the media misfeed occurred in the center section of the staple finisher, fol- low the procedure described below to remove the misfed media. Open the finisher cover. Clockwise turn the knob on the inside until the media is fed into the main output tray.

  • Page 211: Clearing Jammed Staples

    Clearing Jammed Staples If the staples are jammed, follow the procedure described below to remove the jammed staples. Open the stapler cover. Pull out the stapling unit. Pull out the stapler. Clearing Media Misfeeds...
  • Page 212 Push up the guide for the staple cartridge, and then remove any jammed staples. Return the guide to its original position, and then install the sta- pler. Install the stapling unit. Close the stapler cover. Clearing Media Misfeeds...

  • Page 213: Solving Problems With Media Misfeeds

    Recheck the media path and make sure that you have removed all of the misfed media. Use KONICA MINOLTA-approved media. See “Media Specifications” on page 98. Only plain paper, 60–90 g/m lb) can be autoduplexed. See “Media Specifications”...
  • Page 214 Symptom Cause Media is The media is not cor- misfeeding. rectly positioned in the tray. The number of sheets in the tray exceeds the maximum allowed. The media guides are not correctly adjusted to the media size. Warped or wrinkled media is loaded in the tray.
  • Page 215 Remove the transparencies and load them in the tray one sheet at a time. Do not fan transparencies before load- ing them. Use KONICA MINOLTA-approved media. See “Media Specifications” on page Clean the media supply roller. For more details, refer to “Media Roll-...

  • Page 216: Solving Other Problems

    Symptom Cause Printer The power cord is not power is not correctly plugged into the outlet. Something is wrong with the outlet con- nected to the printer. The power switch is not correctly turned on (I position). The printer is con- nected to an outlet with a voltage or fre- quency that does not...
  • Page 217 Symptom Cause You can’t The tray is empty. print the con- figuration The printer’s covers page. aren’t closed securely. There is a media misfeed. Images can- The digital camera not be transfer mode is not printed from set to PictBridge. the digital camera.
  • Page 218 ( DEFAULT MENU/ENERGY SAVER menu) Wait. No action needed. Add more memory. Install a correct KONICA MINOLTA toner cartridge approved for your spe- cific printer. INCOR- Check the toner cartridges. The image will not print if one or more cartridges are empty.
  • Page 219 Symptom Cause Not all pages The printer has the print. wrong kind of cable, or the printer is not configured for the correct cable and port. The Cancel key was pressed. The tray is empty. A document is printed with an overlay file which has been cre- ated by a non-bizhub C30P driver.
  • Page 220 Symptom Cause You are Media or settings are experienc- not correct. ing duplex (Double- Sided) prob- lems. With N-up on Both the driver and multiple cop- the application have ies, the out- been set for collation. put is incorrect. You hear The printer is not unusual level.
  • Page 221 Administrator password has a 6-char- acter minimum and a 16-character maximum. For details of the Page- Scope Web Connection administrator password, refer to the bizhub C30P Reference Guide on the Utilities and Documentation CD-ROM. Remove the moist media and replace it with new, dry media.

  • Page 222: Solving Problems With Printing Quality

    Symptom Cause Nothing is One or more of the printed, or print units may be there are defective. blank spots The printer driver is on the not set correctly. printed page. The media is moist from humidity. The media set in the printer driver mis- matches the media loaded in the printer.
  • Page 223 Symptom Cause Image is too Laser lens is dirty. light; there is The media is moist low image from humidity. density. There is not much toner left in the car- tridge. One or more of the print units may be defective.
  • Page 224 Adjust the humidity in the media stor- age area. Remove the moist media and replace it with new, dry media. Use KONICA MINOLTA-approved media. See “Media Specifications” on page 98. Remove the print units and check it for damage. If it is damaged, replace it.
  • Page 225 Symptom Cause There are One or more of the toner print units may be smudges or defective or installed residual incorrectly. images. There are The media transfer toner roller is dirty. smudges on the back side of the page The media path is (whether or dirty with toner.
  • Page 226 Symptom Cause Image The laser lens is dirty. Clean the laser lens. defects. A toner cartridge may be leaking. A print unit may be defective. Lateral lines The printer is not or bands level. appear on The media path is image.
  • Page 227 Symptom Cause The color One or more of the has a poor print units may be reproduction defective. or has poor color density. If the problem is not resolved, even after all of the above have been per- formed, contact Technical Support with the error information. Solving Problems with Printing Quality Solution Remove the print units and check them...

  • Page 228: Status, Error, And Service Messages

    Status, error, and service messages are displayed in the control panel mes- sage window. They provide information about your printer and help you locate many problems. When the condition associated with a displayed mes- sage has changed, the message is cleared from the window. Standard Status Messages This message...

  • Page 229: Error Messages (Warning:)

    MINOLTA print unit of the appropriate type (EU). See page 139. The X toner cartridge Install a is an unapproved KONICA MINOLTA type. toner cartridge of the appropriate type (EU). See page 133. do this... No action needed.
  • Page 230 This message... MEMORY CARD NEAR FULL NON SUPPORT CARD PAPER EMPTY TRAY X I-UNIT END means... The memory card is Delete resources (fonts, nearly full. forms, etc.) which saved on the memory card by using Download Man- ager or PSWC. Since incompatible Use CompactFlash CompactFlash was...
  • Page 231 This message... I-UNIT LOW I-UNIT LIFE STAPLER EMPTY TONER EMPTY TONER LOW Status, Error, and Service Messages means... do this... The X print unit is low Prepare the specified and should be color print unit. replaced within 2,000 pages at 5% cover- age of letter/A4 pages.
  • Page 232 This message... TRANS. BELT END OF LIFE TRANS.ROLLER END OF LIFE UNABLE TO COLLATE JOB UNABLE TO STAPLE JOB WASTE TONER NEAR FULL means... The transfer belt unit Replace the transfer belt has reached the end unit and reset the of its life.

  • Page 233: Error Messages (Operator Call:)

    Error Messages (Operator Call: This message... ADJUST TRAY1 COVER OPEN DUPLEX COVER COVER OPEN FINISHER COVER COVER OPEN FRONT COVER COVER OPEN SIDE COVER COVER OPEN STAPLER COVER COVER OPEN TRAYX COVER COVER OPEN UPPER COVER FUSER MISSING CHECK UNIT HOLD JOB ERROR UNABLE TO STORE JOB...
  • Page 234 This message... MANUAL FEED “SIZE” “MEDIA” MEMORY FULL PRESS CANCEL OUTPUT FULL REMOVE PAPER YYYY PAPER EMPTY “SIZE” “MEDIA” PAPER ERROR “SIZE” “MEDIA” means... The Paper Source in Press the the printer driver is print, or remove and set to Tray 1 (Manual reload the media in Tray Feed), but there is already media in the...
  • Page 235 This message... PAPER JAM DUPLEX1 PAPER JAM DUPLEX2 PAPER JAM FINISHER PAPER JAM FUSER/EXIT PAPER JAM MAIN EXIT PAPER JAM SECOND TRANS PAPER JAM STAPLER PAPER JAM SUB EXIT PAPER JAM TRAY1 PAPER JAM TRAYX PAPER JAM UPPER TRANS PAPER JAM VERTICAL TRANS Status, Error, and Service Messages means...
  • Page 236 This message... I-UNIT END REPLACE I-UNIT MISSING CHECK X STAPLER EMPTY REPLACE STAPLE CARTRIDGE TONER EMPTY REPLACE TONER MISSING CHECK X TRAY X EMPTY “SIZE” “MEDIA” TRAYX PAPER ERR “SIZE” “MEDIA” means... The X Print unit has Replace the Print unit. completely reached the end of its life.
  • Page 237 This message... TRAYX SIZE ERR “SIZE” TRAYX TYPE ERR “MEDIA” WASTE TONER FULL REPLACE BOTTLE CONFIGURATION ERR INCORRECT TONER X Status, Error, and Service Messages means... do this... The media size set in Load the correct media the printer driver is size into the specified different from the size tray.

  • Page 238: Service Messages

    Service Messages: These messages indicate a more serious error that can only be corrected by a customer service engineer. If one of these messages appears, turn the printer off, then turn it on again. If the problem persists, contact your local vendor or authorized service provider.
  • Page 239 Installing Accessories...

  • Page 240: Installing Accessories

    Note Use of accessories not manufactured or supported by KONICA MINOLTA will void your warranty. This chapter provides information about the following accessories. Dual In-Line Memory Module (DIMM) Duplex Option Lower Feeder Unit (Tray 3/4) Hard Disk Kit Compact Flash...

  • Page 241: Dual In-Line Memory Module (Dimm)

    You may need additional memory (DIMM) for complex graphics and for duplex (Double-Sided) printing. Dual in-line memory module (or DIMM) is compact circuit board with sur- face-mount memory chips. The printer, which has two memory slots, has a 256 MB memory module already installed in one of the slots.
  • Page 242 Using a screwdriver, loosen the seven screws. (Do not remove them from the printer.) Slide the panel slightly to the right and lift it off the printer. Insert the new DIMM straight into the DIMM connector until the latches snap into the locked position.
  • Page 243 Reconnect the power cord, and turn on the printer. Declare the additional Printer Memory in the Windows printer driver (Properties/Configure tab). Print a configuration page ( ) and PRINT MENU/CONFIGURATION PG verify that the total amount of the RAM installed in your printer is listed. Dual In-Line Memory Module (DIMM)

  • Page 244: Hard Disk Kit

    If a hard disk drive is installed, fonts can be downloaded and saved, and the overlay function can be used. Installing the Hard Disk drive Note It’s very important to protect the printer controller board and any associated circuit boards from electrostatic damage. Before performing this procedure, review the antistatic caution on page 226.
  • Page 245 Using a screwdriver, loosen the seven screws. (Do not remove them from the printer.) Slide the panel slightly to the right and lift it off the printer. Plug the cable on the hard disk drive into the connector on the controller board.
  • Page 246 Insert the three mounting pins on the hard disk drive into the holes in the controller board in the order shown in the illustra- tion at the right to mount the hard disk drive onto the control- ler board. Reinstall the panel and tighten the seven screws. Attach the rear cover.

  • Page 247: Compactflash

    If a CompactFlash card is installed, resources such as fonts, macros and pro- files can be downloaded, and image files can be printed directly. Only CompactFlash cards with a capacity of 256 MB, 512 MB or 1 GB can be used. The Hold Job function is not available with a CompactFlash card.
  • Page 248 Using a screwdriver, remove the screw. Then, slide the rear cover to the right and remove it. Using a screwdriver, loosen the seven screws. (Do not remove them from the printer.) Slide the panel slightly to the right and lift it off the printer. CompactFlash...
  • Page 249 Fully insert the CompactFlash card into the appropriate slot. When the CompactFlash card is correctly inserted, the button on the top side of the slot (circled in the illustration) slightly pops out. Before removing the CompactFlash card, press in this button. Reinstall the panel and tighten the seven screws.

  • Page 250: Duplex Option

    Duplex (Double-Sided) printing can be performed automatically with the duplex option and enough memory installed. See “Duplexing” on page 126. Installing the Duplex Option Turn off the printer. Remove the cover on the right side cover. Duplex Option...
  • Page 251 Remove the door at the side of the right side cover. Prepare the duplex option. Before installing the duplex option, open the duplex cover, and then check that the knob is positioned as shown in the illustration. Then, close the duplex cover. Attach the duplex option, as shown in the illustration.
  • Page 252 Open the duplex cover, and then turn both knobs counterclock- wise until they are horizontal to secure the duplex option to the right side cover. Then, close the duplex cover. Declare the Duplex Unit in the Windows printer driver (Properties/Config- ure tab).

  • Page 253: Lower Feeder Unit

    You can install up to two optional lower feeder units (Trays 3 and 4). Each lower feeder unit increases your printer’s media feed capacity by 500 sheets. Kit Contents Lower feeder unit with a tray (500-sheet capacity) Four metal brackets –...

  • Page 254: Installing A Lower Feeder Unit

    Installing a Lower Feeder Unit Note Since consumables are installed in the printer, be sure to keep the printer level when moving it in order to prevent accidental spills. Turn off the printer and discon- nect the power cord and inter- face cables.
  • Page 255 With another person’s help, place the printer on top of the lower feeder unit, making sure that the positioning pins on the lower feeder unit correctly fit into the holes on the bottom of the printer. If two lower feeder units are to be installed, stack the two lower feeder units and secure them together before installing them to the printer.
  • Page 256 Pull out the trays. Install the two securing brackets at the front of the printer. Close the trays. Attach the transport guide to the right door of Tray 3. It is not necessary to attach the transport guide to the right door of Tray 4. Lower Feeder Unit...
  • Page 257 Close the right side cover of the lower feeder unit. Declare Paper Source Unit 3/4 in the Windows printer driver (Properties/ Configure tab). Lower Feeder Unit...

  • Page 258: Staple Finisher

    When the staple finisher is installed, job separation, offset and staple printing can be performed. Accessories 1 Staple Finisher 2 Relay Unit 3 Main output tray 4 Sub output tray 5 Hooks (For securing the relay unit) 6 Hooks (For installing the staple finisher) 7 Mounting clips for the main output tray...

  • Page 259: Unpacking And Installing The Staple Finisher

    Unpacking and installing the Staple Finisher Open the box for the optional finisher. Unpack the relay unit, and then open the relay unit cover Remove all packing tape. Close the relay unit cover. Staple Finisher...
  • Page 260 Remove the two mounting hooks in the bag taped to the back of the relay unit. Since the gears (1) are exposed, be careful not to grab them or hit them. Since the performance of the transport roller and springs (2) may be greatly reduced if they are firmly grabbed, treat them with special care.
  • Page 261 Remove the output tray from the machine. While lightly bending the output tray as much as possible, remove the out- put tray. Remove the inside cover (three locations) at the top of the machine. Use a coin to remove the front cover (two locations) at the top of the machine.
  • Page 262 Install the relay unit on the machine. Open the relay unit cover. Staple Finisher...
  • Page 263 With your fingers, press the left and right pins. Make sure that the pins are pushed in. Secure the relay unit on the machine with the two mounting hooks. Lock the relay unit lever. Staple Finisher...
  • Page 264 Close the relay unit cover. Remove the two finisher-mount- ing hooks from the box. Remove the main output tray and the sub output tray, and then unpack them. Hold the left and right sides of the staple finisher and lift it out of the box.
  • Page 265 Remove the packing tape and packing materials from the con- nectors and the outside of the staple finisher. Open the stapler cover, and then remove the tape securing the staple cartridge. Use a coin to remove the cover (two locations) on the left side of the machine.
  • Page 266 Secure the two mounting hooks on the staple finisher to the left side of the machine. Align the side of the relay unit with that of the staple finisher, and then hook them onto the fin- isher to install them. When grabbing the staple finisher, be sure to grab the areas indicated in the...
  • Page 267 Remove the two mounting clips from the main output tray. Insert the main output tray. Secure the main output tray with the mounting clips. Staple Finisher...
  • Page 268 Install the sub output tray. Insert the connector on the fin- isher into the connector on the machine. Reconnect the power cord, and turn on the machine. Declare the staple finisher in the printer driver (Properties/Config- ure tab). Staple Finisher...

  • Page 269: A Appendix

    Appendix...

  • Page 270: Safety Specifications

    Printer Safety standards EMC standards Technical Specifications Printer Type Print system Exposure system Developing system Resolution First print European model EU Directive 73/23/EEC EU Directive 93/68/EEC EN 60950-1 (IEC 60950) European model EU Directive 89/336/EEC EU Directive 93/68/EEC EN 55022 (CISPR Pub. 22) class B EN 61000-3-2 EN 61000-3-3 Desktop Tandem Full Color A4 laser beam...
  • Page 271 Print speed Media sizes Paper/Media Input capacity Technical Specifications Simplex Monochrome: 35/37 page per minutes for A4/ Letter (plain paper) Full color: 30/31.7 page per minutes for A4/ Letter (plain paper) Duplex (Double-Sided) Monochrome: 22.5 page per minutes for A4/ Letter (plain paper) Full color: 19.4 page per minutes for A4/...
  • Page 272 Output capacity Finisher output capacity Operating temperature Operating humidity Power supply Power consumption Amperage Warm-up time Acoustic Noise External dimensions Weight Interface Standard memory Output tray: 250 sheets (A4, Letter) Main output tray: 500 sheets (A4 or Letter) Sub output tray: 100 sheets (A4 or Letter) 10 to 35°C (50 to 95°F) 15 to 85% 220 to 240 V, 50 to 60 Hz...

  • Page 273: Consumable Life Expectancy Chart

    Consumable Life Expectancy Chart User-Replaceable Item Toner cartridge Print unit Waste toner bottle Transfer roller Ozone Filter (Bundle with transfer roller) Transfer belt unit Note: A constant environment is one with a temperature between 15 °C [59 °F] and 25 °C [77 °F] and humidity between 35% and 70%. The values shown for the toner cartridge and waste toner bottle indi- cate the number of pages for simplex printing using A4/Letter-size media with 5% coverage.

  • Page 274: Our Concern For Environmental Protection

    Our Concern for Environmental Protection ® As an ENERGY STAR Partner, we have determined that this machine meets the ENERGY STAR Guidelines for energy efficiency. What is an ENERGY STAR product? An ENERGY STAR product has a special feature that allows it to automati- cally switch to a “low-power mode”...
  • Page 275 Index Accessories 226 CompactFlash 233 DIMMs 227 Duplex option 236 Hard disk Kit 230 Lower feeder unit 239 Staple Finisher 244 Antistatic protection 226 Camera direct 94 CompactFlash 233 Configuration menu 32 Consumables Backup battery 158 Ozone filter 151 Print unit 139 Staple 161 Toner cartridge 132 Index...
  • Page 276 Glossy Media 106 Hard disk Kit 230 Imageable area 107 Labels 102 Letterhead 103 Loading media 108 Lower feeder unit 239 Maintenance 166 Media Clearing misfeeds 179 Imageable area 107 Loading 108 Path 178 Preventing misfeeds 177 Media misfeed Duplex option 187 Fuser unit 188 Relay Unit 193 Staple Finisher 194...

Table of Contents
