Audison bit one Advanced Manual page 10

TARGET mode (Bit One processor connected to the PC)
1. When software starts, it scans the USB ports of the PC, searching for the Bit One;
2. Bit One found: the processor is connected to the PC;
3. Bit One NOT found: the processor is not connected to the PC; Press CANCEL to start the OFFLINE mode;
4. Inputs/outputs confi guration wizard;
5. Select the MASTER inputs being used (low level or high level) and the auxiliary inputs AUX1 - AUX2 -
S/PDIF - OPTICAL - PHONE if used;
6. Assign the processor input channels to the signals coming from the sources (Ch1
7. MASTER input level setup (low / high level). Follow the instruction shown on the windows;
Note: the setup is necessary to adjust the Bit One input sensitivity to the signal coming from the sources;
8. Wait until the setup is completed;
9. Input level too low;
10. Selecting the MASTER High Level input, the OEM source de-equalization function will be active;
11. If the de-equalization function is active, follow the shown instructions;
12. Select the loudspeakers used in the system;
13. Select any passive crossover fi lter;
14. Assign the processor output channels to the corrispondent amplifi er being used (Ch1
15. Specify any amplifi er using AD Link / AC Link system.
1
6
11
3
2
8
7
13
12
10 10
ADVANCED MANUAL / Bit One ADVANCED MANUAL / Bit One
Ch6);
Ch8);
4
9
14
5
10
15
