14 - CONNECTIONS

A data port is located on the bottom of the unit. The cabling inside of the telephone allows the data
port to be connected directly on the same line as the telephone.
Modem

15 - DESK MOUNTING

Premium 100 and 200 can be used in desk position with or without the added feet.
To obtain different inclination, insert the feet in the different holes, proceed as follows:

16 - WALL POSITION

Align slot of wall mounted bracket over the 2 screws. Gently pull down the phone until it is held by
the 2 screws.
Pull the handset hanger out from the base top and turn to 180°.
Press here to release the
feet
Line PSTN
Headset (Only PREMIUM 200)
Handset
High position
Feet mounted inside
position
Low position
Feet mounted outside
position
Drilling points
100 mm
Screw ST4 25 mm
