- Page 1 R A D I A N T O U T D O O R H E A T E R S OPERATION, INSTALLATION AND MAINTENANCE MANUAL F l u s h M o u n t E n c l o s u r e T h e h e a t e r t h a t i s a d e s i g n f e a t u r e !
- Page 2 R A D I A N T O U T D O O R H E A T E R S Mounting options ® The installation of HEATSTRIP Classic is simple and easy with the standard mounting brackets supplied. For other more challenging locations there are range of mounting options available - refer to below diagrams.
- Page 3 Please refer to the Installation Manual for more detailed installation information. SUITABLE FOR PART No HOLE CUTOUT OVERALL WEIGHT MODELS DIMENSIONS (mm) DIMENSIONS (mm) (kg) THH1500A THHAC-009 980 x 230 1030 x 280 x 125 THH1800A THHAC-010 1160 x 230 1210 x 280 x 125 THH2400A THHAC-011...
- Page 4 H E A T E R S FME DIMENSIONS VIEW FROM TOP VIEW FROM UNDERNEATH "B" "A" "C" PART No MODEL “A” (mm) “B” (mm) “C” (mm) THHAC-009 THH1500A 1030 THHAC-010 THH1800A 1210 1154 1150 THHAC-011 THH2400A 1470 1414 1410 THHAC-012...
- Page 5 R A D I A N T O U T D O O R H E A T E R S INSTALLATION CLEARANCE DIMENSIONS Shown in the diagrams below are the minimum clearance required for the installation of the Flush Mount En- closure.
-
Page 6: Installation Instructions
“D” DISTANCE FROM END INSTRUCTIONS TO BRACKET (mm) THH1500A Ensure all minimum clearance requirements are met and the materi- als used are compliant to your local building codes. THH1800A Before installing the FME, ensure the site to be fixed is fully pre-... - Page 7 R A D I A N T O U T D O O R H E A T E R S SAFETY In operation, this heater is VERY HOT— do not touch any part of the heater while it is turned on. Do not touch any part until 30 minutes after it is turned off.
- Page 8 All warranty requests for repairs or replacements must be accompanied by a complete “Warranty Claim Form” available from Thermofilm, together with proof of purchase (and where possible, photos of the installation) and the heater returned to the place of purchase.
