- Page 1 OPERATION, INSTALLATION AND MAINTENANCE MANUAL F l u s h M o u n t E n c l o s u r e f o r H e a t s t r i p E l e g a n c e ( T H E R a n g e )
- Page 2 Flush Mount Enclosure Rev B Oct 16 The Flush Mount Enclosure is an ideal way to neatly install the HEATSTRIP into a ceiling. They are available for all HEATSTRIP Elegance models and are supplied as a one-piece unit suitable for mounting individual heaters. Flush mounting can be used with any building grade ceiling materials.
-
Page 3: View From Top
Flush Mount Enclosure Dimensions VIEW FROM UNDERNEATH VIEW FROM TOP PART No MODEL “A” (mm) “B” (mm) “C” (mm) THEAC-040 THE1800 1080 1024 1020 THEAC-041 THE2400 1310 1254 1250 THEAC-042 THE3600 1910 1854 1850... -
Page 4: Installation Location
Installation Location The diagrams below and on the following page give the minimum clearances required for the installa- tion of the Flush Mount Enclosure. It is imperative that all cables, insulation and other materials are kept clear of the back and the sides of the Flush Mount Enclosure. - Page 5 Installation Clearance Dimensions The diagrams below give the minimum clearances installation of the Flush Mount Enclosure. It is recommended to use only the provided holes in the ends of the enclosure for mounting. The minimum distance between the back of the enclosure and any building material is 150mm. ...
-
Page 6: Installation Instructions
Installation Instructions MODEL “D” DISTANCE FROM END Ensure all minimum clearance requirements are met and the TO BRACKET (mm) materials used are compliant to your local building codes. THE1800 Before installing the FME, ensure the site to be fixed is fully THE2400 prepared with the hole cut the correct size and the mounting points securely in place. -
Page 7: Maintenance
Safety In operation, this heater is VERY HOT— do not touch any part of the heater while it is turned on. Do not touch any part until 30 minutes after it is turned off. This appliance is not intended for use by persons (including children) with reduced physical, sensory or intellectual capabilities, or lack of experience and knowledge, unless they have been given super- vision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 8: Warranty Terms And Conditions
Thermofilm warrants to the original owner that the FLUSH MOUNT ENCLOSURE product will be free from defects in materials and workmanship for a period of 12 months from the date of purchase in accordance with the following warranty terms and conditions.
