Summary of Contents for Supero X8DTN+

Page 1 X8DTN+ USER’S MANUAL Revision 1.0b...
Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.
Page 3: About This Manual
Preface Preface About This Manual This manual is written for system integrators, PC technicians and knowledgeable PC users. It provides information for the installation and use of the X8DTN+ motherboard. About This Motherboard X8DTN+ supports the Intel 5500 Series Processors, the ﬁ rst dual- processing platform that offers Intel QuickPath Interconnect (QPI) Technology to provide the next generation point-to-point system interface, replacing the current Front Side Bus.
Page 4 X8DTN+ User's Manual Note: Additional Information given to differentiate various models or to ensure correct system setup.
Page 5 Table of Contents Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...
Page 6: Table Of Contents
X8DTN+ User's Manual Table of Contents Preface Chapter 1 Introduction Overview ......................1-1 Checklist ......................1-1 X8DTN+ Quick Reference ................1-5 Motherboard Features ................... 1-6 Processor and Chipset Overview..............1-9 The Main Features of the 5500 Series Processor and the 5520 Chipset ..1-9 Special Features ...................
Page 7 Table of Contents NMI Button ....................2-17 Power LED ....................2-17 HDD LED ....................2-18 Connecting Cables ..................2-21 Processor Power Connector ..............2-21 Internal Speaker ..................2-23 Overheat LED/Fan Fail (JOH1) ..............2-23 Compact Flash Card PWR Connector ............. 2-26 Jumper Settings ....................
Page 8 X8DTN+ User's Manual Appendix A BIOS Error Beep Codes BIOS Error Beep Codes ................. A-1 Appendix B Software Installation Instructions Installing Software Programs ................B-1 Conﬁ guring Supero Doctor III Settings .............. 2 viii...
Page 9: Chapter 1 Introduction
Chapter 1: Introduction Chapter 1 Introduction Overview Checklist Congratulations on purchasing your computer motherboard from an acknowledged leader in the industry. Supermicro boards are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. Check that the following items have all been included with your motherboard.
Page 10 X8DTN+ User's Manual X8DTN+ Image Note: The drawings and pictures shown in this manual were based on the latest PCB Revision available at the time of publishing of the manual. The motherboard you’ve received may or may not look exactly the same as the graphics shown in the manual.
Page 11 Chapter 1: Introduction X8DTN+ Motherboard Layout P1 DIMM3A PWR I2C Fan7 JPW1 JPW4 JPW3 CPU2 Fan P1 DIMM3B P1 DIMM3C JPP1 P1 DIMM2A JPP0 P1 DIMM2B P1 DIMM2C CPU2 P1 DIMM1A P1 DIMM1B P1 DIMM1C P2 DIMM1C P2 DIMM1B P2 DIMM1A CPU1 P2 DIMM2C P2 DIMM2B...
Page 12 X8DTN+ User's Manual X8DTN+ Quick Reference P1 DIMM3A PWR I2C Fan7 JPW1 JPW4 JPW3 CPU2 Fan P1 DIMM3B P1 DIMM3C P1 DIMM2A JPP1 JPP0 P1 DIMM2B P1 DIMM2C CPU2 P1 DIMM1A P1 DIMM1B P1 DIMM1C P2 DIMM1C P2 DIMM1B P2 DIMM1A CPU1 P2 DIMM2C P2 DIMM2B...
Page 13: X8Dtn+ Quick Reference
Chapter 1: Introduction X8DTN+ Quick Reference Jumper Description Default Setting JBT1 CMOS Clear (See Section 5-10) Watch Dog Enable Pins 1-2 (Reset) C1/JI SMB to PCI-Exp./ SMB to PCI-X Slots Open (Disabled) IDE Enable 1-2 (Normal) JPG1 VGA Enable 1-2 (Enable) JPL1 LAN1/2 Enable Pins 1-2 (Enabled)
Page 14: Motherboard Features
X8DTN+ User's Manual Motherboard Features • ® Two Intel 5500 Series (LGA 1366) processors, each processor supporting two full-width Intel QuickPath Interconnect (QPI) links with a total of up to 51.2 GB/s Data Transfer Rate (6.4 GB/s per direction) Memory •...
Page 15 Auto-switching voltage regulator for CPU cores • System overheat/Fan Fail LED Indicator and control • Chassis intrusion detection • System resource alert via Supero Doctor III ACPI Features • Slow blinking LED for suspend state indicator • Main switch override mechanism •...
Page 16 X8DTN+ User's Manual CPU1 CPU2 Port1 Port0 Ports 82576 Ports Intel 5520 RJ45RJ45 Ports Ports Ports CLINK 9,10 Chnl A SST25 VF016 Chnl B CLINK JMB368 ICH10R #5 x4 SATA SATA #1 SATA #2 83627 SATA #3 SATA #4 SATA #5 SATA #6 ES1000 Floppy...
Page 17: Processor And Chipset Overview
Chapter 1: Introduction Processor and Chipset Overview Built upon the functionality and the capability of the 5500 Series Processor platform, the X8DTN+ motherboard provides the performance and feature set required for dual-processor-based high-end systems with conﬁ guration optimized for intensive application and high-end server platforms. The 5500 Series Proces- sor platform consists of the 5500 Series (LGA 1366) processor, the 5520 (North Bridge), and the ICH10R (South Bridge).
Page 18: Special Features
Warning! To avoid possible system overheating, be sure to provide ad- equate airﬂ ow to the system. System Resource Alert This feature is available when used with Supero Doctor III in the Windows OS environment or used with Supero Doctor II in Linux. Supero Doctor is used to 1-10...
Page 19: Acpi Features
Chapter 1: Introduction notify the user of certain system events. For example, you can also conﬁ gure Supero Doctor to provide you with warnings when the system temperature, CPU temperatures, voltages and fan speeds go beyond a pre-deﬁ ned range.
Page 20: Super I/O
X8DTN+ User's Manual The X8DTN+ can accommodate 24-pin ATX power supplies. Although most power supplies generally meet the speciﬁ cations required by the CPU, some are inad- equate. In addition, the 12V 8-pin power connections are also required to ensure adequate power supply to the system.
Page 21: Chapter 2 Installation
Chapter 2: Installation Chapter 2 Installation Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system board, it is important to handle it very carefully. The following measures are generally sufﬁ cient to protect your equipment from ESD. Precautions •...
Page 22: Processor And Heatsink Installation
X8DTN+ User's Manual Processor and Heatsink Installation When handling the processor package, avoid placing direct pressure on the label area of the fan. Notes: Always connect the power cord last and always remove it before adding, re- moving or changing any hardware components. Make sure that you install the processor into the CPU socket before you install the CPU heatsink.
Page 23 Chapter 2: Installation After removing the plastic cap, using your thumb and the index ﬁ nger, hold the CPU at the north and south center edges. Align the CPU key, the semi- circle cutout, against the socket key, the notch below the gold color dot on the side of the socket.
Page 24: Installing A Cpu Heatsink
X8DTN+ User's Manual Installing a CPU Heatsink Do not apply any thermal grease to the heatsink or the CPU die because the required amount has already been ap- plied. Screw#1 Screw#2 Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the retention mechanism.
Page 25 Chapter 2: Installation Removing the Heatsink Warning: We do not recommend that the CPU or the heatsink be re- moved. However, if you do need to remove the heatsink, please follow the instructions below to uninstall the heatsink and prevent damage to the CPU or other components.
Page 26: Mounting The Motherboard Into The Chassis
X8DTN+ User's Manual Mounting the Motherboard into the Chassis All motherboards have standard mounting holes to ﬁ t different types of chassis. Make sure that the locations of all mounting holes for the motherboard and the chas- sis match. Although a chassis may have both plastic and metal mounting fasteners, metal ones are highly recommended because they ground the motherboard to the chassis.
Page 27: Installing And Removing The Memory Modules
Chapter 2: Installation Installing and Removing the Memory Modules Note: Check the Supermicro web site for recommended memory modules. CAUTION Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Installing & Removing DIMMs Press down the release tabs Insert the desired number of DIMMs into the memory slots, starting with P1-DIMM #1A.
Page 28: Memory Support
X8DTN+ User's Manual Memory Support The X8DTN+ supports up to 144 GB of Registered ECC and up to 48 GB of Unbuf- fered ECC/Non-ECC DDR3 1333 MHz/1066 MHz/800 MHz in 18 DIMMs. Note: Memory Speed support depends on the type(s) of CPU(s) used. DIMM Module Population Conﬁ...
Page 29 Chapter 2: Installation Memory Population Table DIMM DIMMs DIMM Type (Unb.= Speeds (in MHz) Ranks per DIMM Slots per Populated Unbuffered) (any combination; Channel per Channel SR=Single Rank, DR=Dual Rank, QR=Quad Rank) Unb. DDR3 ECC/Non-ECC 800,1066,1333 SR, DR Unb. DDR3 ECC/Non-ECC 800,1066 SR, DR Note 1: Due to OS limitations, some operating systems may not show...
Page 30: Control Panel Connectors/Io Ports
X8DTN+ User's Manual Control Panel Connectors/IO Ports The I/O ports are color coded in conformance with the PC 99 speciﬁ cation. See the picture below for the colors and locations of the various I/O ports. 1. Back Panel Connectors/IO Ports Back Panel I/O Port Locations and Deﬁ...
Page 31: Back Panel Io Port And Onboard Io Connection Pin Deﬁ Nitions
Chapter 2: Installation 2. Back Panel IO Port and Onboard IO Connection Pin Deﬁ nitions ATX PS/2 Keyboard and PS/2 PS/2 Keyboard/Mouse Pin Mouse Ports Deﬁ nitions PS2 Keyboard PS2 Mouse The ATX PS/2 keyboard and PS/2 Pin# Deﬁ nition Pin# Deﬁ...
Page 32: Universal Serial Bus (Usb)
X8DTN+ User's Manual Universal Serial Bus (USB) Back Panel USB Front Panel USB (USB0/1) (USB6/7) There are seven USB 2.0 (Univer- Pin# Deﬁ nitions Pin# Deﬁ nition sal Serial Bus) connections on the motherboard. Backpanel USB Ports Data- 0/1 are located at JUSB1. The other Data+ ﬁ...
Page 33: Serial Ports
Chapter 2: Installation Serial Ports Serial Ports-COM1 Two COM connections (COM1 & Pin Deﬁ nitions COM2) are located on the moth- Pin # Deﬁ nition Pin # Deﬁ nition erboard. COM1 is located next to the Video port on the Backplane IO panel.
Page 34: Vga Connector
X8DTN+ User's Manual VGA Connector VGA/CRT Pin Deﬁ nitions A VGA connector is located next to Pin# Deﬁ nition Pin# Deﬁ nition COM Port1 on the IO backplane. This connector provides video and Green Ground CRT display Refer to the board layout Blue below for the location.
Page 35: Gigabit Lan (Ethernet) Ports
Chapter 2: Installation Gigabit LAN (Ethernet) Ports Two Gigabit Ethernet ports (GLAN1/2) are located at JLAN1/JLAN2 on the IO backplane. These ports accept RJ45 type cables. (Note: Please refer to the LED Indicator Section for GLAN LED information.) A. GLAN1 B.
Page 36: Front Control Panel
X8DTN+ User's Manual 3. Front Control Panel JF1 contains header pins for various buttons and indicators that are normally lo- cated on a control panel at the front of the chassis. These connectors are designed speciﬁ cally for use with Supermicro server chassis. See the ﬁ gure below for the descriptions of the various control panel buttons and LED indicators.
Page 37: Front Control Panel Pin Deﬁ Nitions
Chapter 2: Installation 4. Front Control Panel Pin Deﬁ nitions NMI Button NMI Button Pin Deﬁ nitions (JF1) The non-maskable interrupt button Pin# Deﬁ nition header is located on pins 19 and 20 Control of JF1. Refer to the table on the right Ground for pin deﬁ...
Page 38: Hdd Led
X8DTN+ User's Manual HDD LED HDD LED Pin Deﬁ nitions (JF1) The HDD LED connection is located Pin# Deﬁ nition on pins 13 and 14 of JF1. Attach a hard drive LED cable here to display HD Active disk activity (for any hard drive activi- ties on the system, including Serial ATA and IDE).
Page 39 Chapter 2: Installation Overheat (OH)/Fan Fail LED OH/Fan Fail LED Pin Deﬁ nitions (JF1) Connect an LED Cable to the OH/ Pin# Deﬁ nition Fan Fail connection on pins 7 and 8 of JF1 to provide an advanced Ground warning of chassis overheating or OH/Fan Fail Indicator fan failure.
Page 40 X8DTN+ User's Manual Reset Button Reset Button Pin Deﬁ nitions (JF1) The Reset Button connection is lo- Pin# Deﬁ nition cated on pins 3 and 4 of JF1. Attach Reset it to a hardware reset switch on the Ground computer case. Refer to the table on the right for pin deﬁ...
Page 41: Connecting Cables
Chapter 2: Installation Connecting Cables ATX Power 24-pin Connector Pin Deﬁ nitions Pin# Deﬁ nition Pin # Deﬁ nition ATX Power Connector +3.3V +3.3V There are a 24-pin main power -12V +3.3V supply connector(JPW1) and two 8-pin CPU PWR connectors (JPW3/ PS_ON JPW5) on the motherboard.
Page 42 X8DTN+ User's Manual Fan Headers Fan Header Pin Deﬁ nitions The X8DTN+ has six chassis/system Pin# Deﬁ nition fan headers (Fan1 to Fan6) and two Ground CPU fans (Fan7/Fan8) on the moth- +12V erboard. All these 4-pin fans headers Tachometer are backward compatible with the PWR Modulation traditional 3-pin fans.
Page 43: Internal Speaker
Chapter 2: Installation Internal Speaker Internal Buzzer (SP1) Pin Deﬁ nition The Internal Speaker, located at Pin# Deﬁ nitions SP1, can be used to provide audible Pin 1 Pos. (+) Beep In indications for various beep codes. Pin 2 Neg. (-) Alarm See the table on the right for pin Speaker...
Page 44 X8DTN+ User's Manual Chassis Intrusion Chassis Intrusion Pin Deﬁ nitions (JL1) A Chassis Intrusion header is located Pin# Deﬁ nition at JL1 on the motherboard. Attach an Intrusion Input appropriate cable from the chassis Ground to inform you of a chassis intrusion when the chassis is opened.
Page 45 Chapter 2: Installation Power SMB (I C) Connector PWR SMB Pin Deﬁ nitions Power System Management Bus Pin# Deﬁ nition C) Connector (J15) monitors Clock power supply, fan and system tem- Data peratures. See the table on the right PWR Fail for pin deﬁ...
Page 46: Compact Flash Card Pwr Connector
X8DTN+ User's Manual Compact Flash Card PWR Compact Flash Card PWR Connector Connector Jumper Deﬁ nition A C ompac t Flash Card Power Compact Flash Connector is located at JWF1. For Power On (Default) the Compact Flash card to work Compact Flash properly, you will need to ﬁ...
Page 47 Chapter 2: Installation Trusted Platform Module Header Trusted Platform Module (TPM) Header Pin Deﬁ nitions A Trusted Platform Module (TPM) Pin# Deﬁ nition Pin # Deﬁ nition header (JTPM1) is located next to LPC Clock the SATA connectors. This header LPC FRAME# provides TPM support to ensure LPC Reset#...
Page 48: Jumper Settings
X8DTN+ User's Manual Jumper Settings Explanation of Jumpers Connector Pins To modify the operation of the moth- erboard, jumpers can be used to choose between optional settings. Jumper Jumpers create shorts between two pins to change the function of the connector.
Page 49: Cmos Clear
Chapter 2: Installation CMOS Clear JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads to prevent the accidental clearing of CMOS. To clear CMOS, use a metal object such as a small screwdriver to touch both pads at the same time to short the connection.
Page 50: Vga Enable/Disable
X8DTN+ User's Manual C Bus to PCI-X/PCI-E Slots C to PCI-Exp/PCI-X slots Jumper Settings Jumpers JI C1 and JI C2 allow you Jumper Setting Deﬁ nition to connect the System Management Closed Enabled Bus (I C) to PCI-X/PCI-E slots. The Open Disabled (Default) default setting is Open to disable...
Page 51 Chapter 2: Installation IDE Enable/Disable IDE Enable Jumper Settings Jumper JP3 allows you to enable or Jumper Deﬁ nition disable the onboard IDE connector. IDE Enable The default setting is Pins 1-2 to en- (Default) able the connection. See the table on IDE Disable the right for jumper settings.
Page 52: Onboard Indicators
X8DTN+ User's Manual Activity Onboard Indicators L i n k GLAN LEDs Rear View (when facing the There are two GLAN ports on the rear side of the chassis) motherboard. Each Gigabit Ethernet GLAN Activity (Right) Indicator LED Settings LAN port has two LEDs. The yellow Color Status Deﬁ...
Page 53: Floppy Drive, Simlp, Serial Ata And Hdd Connections
Chapter 2: Installation Floppy Drive, SIMLP, Serial ATA and HDD Connections Note the following when connecting the ﬂ oppy and hard disk drive cables: • The SATA disk drive cable has seven twisted wires. • A red mark on a wire typically designates the location of pin 1. •...
Page 54: Serial Ata Ports
X8DTN+ User's Manual Serial ATA Ports Serial ATA Pin Deﬁ nitions Six Serial ATA Ports (I-SATA0~I- Pin# Deﬁ nition SATA 5) are located at JS1~JS6 on Ground the motherboard. These ports pro- TX_P vide serial-link signal transmission, TX_N which is faster than that of the tradi- Ground tional Parallel ATA.
Page 55 Chapter 2: Installation IDE Connector IDE Drive Connector Pin Deﬁ nitions An IDE Connector is located at Pin# Deﬁ nition Pin # Deﬁ nition JIDE1 on the motherboard. This Reset IDE Ground connector provides HDD IO connec- Host Data 7 Host Data 8 tion.
Page 56 X8DTN+ User's Manual Notes 2-36...
Page 57: Chapter 3 Troubleshooting
Chapter 3: Troubleshooting Chapter 3 Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Note: Always disconnect the power cord before adding, changing or installing any hardware components.
Page 58: No Video
X8DTN+ User's Manual No Video If the power is on but you have no video, remove all the add-on cards and cables. Use the speaker to determine if any beep codes exist. Refer to the Appendix for details on beep codes. Losing the System’s Setup Conﬁ...
Page 59: Technical Support Procedures
Chapter 3: Troubleshooting Technical Support Procedures Before contacting Technical Support, please take the following steps. Also, please note that as a motherboard manufacturer, Supermicro does not sell directly to end- users, so it is best to ﬁ rst check with your distributor or reseller for troubleshooting services.
Page 60: Returning Merchandise For Service
X8DTN+ User's Manual Question: How do I update my BIOS? It is recommended that you do not upgrade your BIOS if you are not experienc- ing any problems with your system. Updated BIOS ﬁ les are located on our web site at http://www.supermicro.com/support/bios/.
Page 61 Chapter 3: Troubleshooting This warranty only covers normal consumer use and does not cover damages in- curred in shipping or from failure due to the alternation, misuse, abuse or improper maintenance of products. During the warranty period, contact your distributor ﬁ rst for any product problems.
Page 62 X8DTN+ User's Manual Notes...
Page 63: Chapter 4 Bios
Chapter 4: AMI BIOS Chapter 4 BIOS Introduction This chapter describes the AMI BIOS Setup Utility for the X8DTN+. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter de- scribes the basic navigation of the AMI BIOS Setup Utility setup screens. Starting BIOS Setup Utility To enter the AMI BIOS Setup Utility screens, press the <Delete>...
Page 64: Starting The Setup Utility
X8DTN+ User’s Manual Starting the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS Setup Utility. From the main menu, you can access the other setup screens.
Page 65 Chapter 4: AMI BIOS Supermicro X8DTN+ • BIOS Build Version : This item displays the BIOS revision used in your sys- tem. • BIOS Build Date : This item displays the date when this BIOS was completed. • AMI BIOS Core Version : This item displays the revision number of the AMI BIOS Core upon which your BIOS was built.
Page 66: Advanced Setup Conﬁ Gurations
X8DTN+ User’s Manual Advanced Setup Conﬁ gurations Use the arrow keys to select Boot Setup and press <Enter> to access the submenu items: Boot Features Quick Boot If Enabled, this option will skip certain tests during POST to reduce the time needed for system boot.
Page 67: Processor And Clock Options
Chapter 4: AMI BIOS Hit 'Del' Message Display This feature displays "Press DEL to run Setup" during POST. The options are Enabled and Disabled. Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture"...
Page 68 X8DTN+ User’s Manual C1E Support Select Enabled to enable Enhanced Halt State support. C1E signiﬁ cantly reduces the CPU's power consumption by reducing the CPU's clock cycle and voltage during a "Halt State." The options are Disabled and Enabled. Hardware Prefetcher (Available when supported by the CPU) If this feature is set to Enabled, the hardware prefetcher will prefetch streams of data and instructions from the main memory to the L2 cache to improve CPU per- formance.
Page 69 Chapter 4: AMI BIOS Active Processor Cores Set to Enabled to use a processor's Second Core and beyond. (Please refer to Intel's web site for more information.) The options are All, 1 and 2. Intel® EIST Technology EIST (Enhanced Intel SpeedStep Technology) allows the system to automatically adjust processor voltage and core frequency in an effort to reduce power consump- tion and heat dissipation.
Page 70: Advanced Chipset Control
X8DTN+ User’s Manual Advanced Chipset Control The items included in the Advanced Settings submenu are listed below: CPU Bridge Conﬁ guration QPI (Quick Path Interconnect) Links Speed This feature selects data transfer speed for QPI Link connections. The options are Slow-Mode, and Full Speed. QPI Frequency (Available if the item - QPI Speed is set to Full Speed) This feature allows the user to select the desired QPI frequency.
Page 71 Chapter 4: AMI BIOS Memory ECC Error Threshold This feature allows the user to set the correctable memory ECC error limit for AMI BIOS to handle it. The Default setting is 255. Throttling - Closed Loop/Throttling - Open Loop Throttling improves reliability and reduces power in the processor by automatic voltage control during processor idle states.
Page 72 X8DTN+ User’s Manual Serial Debug Message Level This feature allows the user to set the level of debug messages to be displayed. The options are None, MIN, MAX and Test. North Bridge Conﬁ guration This feature allows the user to conﬁ gure the settings for the Intel North Bridge. Crystal Beach/DMA (Direct Memory Access) This feature works with the Intel I/O AT (Acceleration Technology) to accelerate the performance of TOE devices.
Page 73 Chapter 4: AMI BIOS South Bridge Conﬁ guration This feature allows the user to conﬁ gure the settings for the Intel South Bridge. USB Functions This feature allows the user to decide the number of onboard USB ports to be enabled.
Page 74 X8DTN+ User’s Manual RAS Sticky Error Handling This option allows the user to decide how to handle Sticky RAS errors. The options are Clear Errors and Leave Errors (unchanged). VGA 16-Bit Decode Select Enabled to enable the function of decoding VGA for the devices installed behind the PXH PCI Controller Hub.
Page 75 Chapter 4: AMI BIOS SATA#2 Conﬁ guration (This feature is available when the option-IDE is selected) Selecting Enhanced will set SATA#2 to native SATA mode. The options are Disabled, and Enhanced. Primary IDE Master/Slave, Secondary IDE Master/Slave, Third IDE Master, and Fourth IDE Master These settings allow the user to set the parameters of Primary IDE Master/Slave, Secondary IDE Master/Slave, Third and Fourth IDE Master slots.
Page 76 X8DTN+ User’s Manual Select 2 to allow the AMI BIOS to use PIO mode 2. It has a data transfer rate of 8.3 MB/s. Select 3 to allow the AMI BIOS to use PIO mode 3. It has a data transfer rate of 11.1 MB/s.
Page 77 Chapter 4: AMI BIOS S.M.A.R.T. For Hard disk drives Self-Monitoring Analysis and Reporting Technology (SMART) can help predict impending drive failures. Select Auto to allow the AMI BIOS to automatically de- tect hard disk drive support. Select Disabled to prevent the AMI BIOS from using the S.M.A.R.T.
Page 78 X8DTN+ User’s Manual Load Onboard LAN1 Option ROM/Load Onboard LAN2 Option ROM Select Enabled to enable the onboard LAN1 or LAN2 Option ROM. This is to boot computer using a network interface. The options are Enabled and Disabled. Onboard LAN Option ROM Select This feature allows the user to select the onboard LAN option ROM type.
Page 79 Chapter 4: AMI BIOS Serial Port Mode This feature allows the user to set the serial port mode for Console Redirection. The options are 115200 8, n 1; 57600 8, n, 1; 38400 8, n, 1; 19200 8, n, 1; and 9600 8, n, 1.
Page 80 X8DTN+ User’s Manual The options are: • The Early Alarm: Select this setting if you want the CPU overheat alarm (includ- ing the LED and the buzzer) to be triggered as soon as the CPU temperature reaches the CPU overheat threshold as predeﬁ ned by the CPU manufacturer. •...
Page 81 Chapter 4: AMI BIOS User intervention: No action is required. However, consider checking the CPU fans and the chassis ventilation for blockage. High – The processor is running hot. This is a ‘caution’ level since the CPU’s ‘Tem- perature Tolerance’ has been reached (or has been exceeded) and may activate an overheat alarm.
Page 82 X8DTN+ User’s Manual ACPI Conﬁ guration Use this feature to conﬁ gure Advanced Conﬁ guration and Power Interface (ACPI) power management settings for your system. ACPI Version Features The options are ACPI v1.0, ACPI v2.0 and ACPI v3.0. Please refer to ACPI's website for further explanation: http://www.acpi.info/.
Page 83: Trusted Computing
Chapter 4: AMI BIOS Trusted Computing TCG/TPM Support Select Yes on this item and enable the TPM jumper on the motherboard to enable TCG (TPM 1.1/1.2)/TPM support in order to improve data integrity and network security. The options are No and Yes. If this feature is set to Yes, the following items will display.
Page 84 X8DTN+ User’s Manual  View BMC System Event Log This feature displays the BMC System Event Log (SEL). It shows the total number of entries of BMC System Events. To view an event, select an Entry Number and pressing <Enter> to display the information as shown in the screen. •...
Page 85 Chapter 4: AMI BIOS Caution: Any cleared information is unrecoverable. Make absolutely sure that you no longer need any data stored in the log before clearing the BMC Event Log.  Set LAN Conﬁ guration Set this feature to conﬁ gure the IPMI LAN adapter with a network address as shown in the following graphics.
Page 86: Mac Address
X8DTN+ User’s Manual request the next available IP address. The options are DHCP and Static. If Static is selected, the following items will be available for conﬁ guration. IP Address The BIOS will automatically enter the IP address of this machine; however it may be over-ridden.
Page 87: Dmi Event Log
Chapter 4: AMI BIOS  Gateway Address Conﬁ guration Enter the gateway address for this machine. This should be in decimal and in dotted quad form (i.e., 192.168.10.253). The value of each three-digit number separated by dots should not exceed 255 as shown in the screen below. Parameter Selector Use this feature to select the parameter of your Gateway Address settings.
Page 88: Security Settings
X8DTN+ User’s Manual Security Settings The AMIBIOS Setup Utility provides a Supervisor and a User password. If you use both passwords, the Supervisor password must be set ﬁ rst. Supervisor Password This feature indicates if a supervisor's password has been entered (installed). User Password This feature indicates if a user's password has been entered (installed).
Page 89: Boot Conﬁ Guration
Chapter 4: AMI BIOS Boot Conﬁ guration Use this feature to conﬁ gure boot settings. Boot Device Priority This feature allows the user to specify the sequence of priority for the Boot Device. The settings are available boot devices and Disabled. •...
Page 90: Exit Options
X8DTN+ User’s Manual Exit Options Select the Exit tab from the AMI BIOS Setup Utility screen to enter the Exit BIOS Setup screen. Save Changes and Exit When you have completed the system conﬁ guration changes, select this option to leave the BIOS Setup Utility and reboot the computer, so the new system con- ﬁ...
Page 91: A-1 Bios Error Beep Codes
Appendix A: BIOS POST Error Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
Page 92 X8DTN+ User's Manual Notes...
Page 93: B-1 Installing Software Programs
Appendix B: Software Installation Instructions Appendix B Software Installation Instructions B-1 Installing Software Programs After you've installed the Windows Operating System, a screen as shown below will appear. You are ready to install software programs and drivers that have not yet been installed.
Page 94: B-2 Conﬁ Guring Supero Doctor Iii Settings
The Supero Doctor III program is a Web-base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called the SD III Client. The Supero Doctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
Page 95 Appendix B: Software Installation Instructions Supero Doctor III Interface Display Screen-II (Remote Control) Note: SD III Software Revision 1.0 can be downloaded from our Web site at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/ Manuals/SDIII/UserGuide.pdf. For Linux, we will still recommend that you...
Page 96 X8DTN+ User's Manual Notes...
Page 97 (Disclaimer Continued) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signiﬁ cant injury or loss of life or catastrophic property damage.
