SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
SERVICE MANUAL
Wireless type
Models
MSC-C07SV -
MSC-C09SV -
MSC-C12SV -
MSH-C18SV -
MSC-C07SV -
E1
MSC-C09SV -
E1
MSC-C12SV -
E1
NOTE:
This service Manual covers only change points.
•MSC-07/09/12RV -
Please refer to the Service Manual OB227 REVISED EDITION-B for unchanged contents.
•MSH-18NV -
, MUH-18NV -
E4
Please refer to the Service Manual OB229 REVISED EDITION-A for unchanged contents.
E1
E1
E1
E1
, MUH-07/09/12RV -
E1
E1
MSH-C18SV -
E4
Revision
• Set temperature change of Operating Temperature of
Defrosting in MUH-C09SV-
• Change of refrigeration oil amount of MUH-C07/C09SV-
• Installed place change of defrost thermistor RT61 in
MUH-C07/C09/C12SV-
• Please void OB250.
HFC
utilized
R-407C
· MUH-C07SV -
( WH )
· MUH-C09SV -
( WH )
· MUH-C12SV -
( WH )
· MUH-C18SV -
( WH )
CONTENTS
1. TECHNICAL CHANGES ···································2
2. SPECIFICATION················································5
3. NOISE CRITERIA CURVES ······························7
4. WIRING DIAGRAM ···········································8
5. REFRIGERANT SYSTEM DIAGRAM ·············10
6. PERFORMANCE CURVES ·····························11
7. SERVICE FUNCTIONS ···································23
8. TROUBLESHOOTING ····································23
9. PARTS LIST ····················································24
MSC-C07/C09/C12SV -
, MUH-C07/C09/C12SV -
E1
, MUH-C18SV -
E1
E1
.
E1
.
E1
No. OB250
REVISED EDITION-A
E1
.
E1
E1
E1
E1
E1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mitsubishi MSC-C07SV
Summary of Contents for Mitsubishi MSC-C07SV
-
Page 1: Table Of Contents
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS No. OB250 REVISED EDITION-A utilized SERVICE MANUAL R-407C Wireless type Models MSC-C07SV - · MUH-C07SV - ( WH ) MSC-C09SV - · MUH-C09SV - ( WH ) MSC-C12SV - · MUH-C12SV - ( WH ) MSH-C18SV - ·... -
Page 2: Technical Changes
TECHNICAL CHANGES The following are in common details. 1. Refrigerant type has changed from R-22(HCFC) to R-407C(HFC). 2. Rated voltage has changed from 220-240V to 220-230V. 3. Compressor has changed from one for R-22 to one for R-407C. 4. Jumper wire JPE for defrosting temperature change in deicer P.C.board is cut at factory shipping. 5. - Page 3 INFORMATION FOR THE AIR CONDITIONER WITH R-407C REFRIGERANT This room air conditioner adopts HFC refrigerant (R-407C) which is never destroy the ozone layer. Pay attention following points. 1 Take sufficient care not to allow water and other contaminations to enter the R-407C refrigerant during storage and installation, since it is more susceptible to contaminations than HCFC refrigerant.
- Page 4 1.Tools dedicated for the air conditioner with R-407C refrigerant The following tools are required for R-407C refrigerant. Some R-22 tools can be substituted for R-407C tools. Do not use tools that are used with R-22 refrigerant in order to avoid mixing oils. Description R-407C tools Can R-22 tools be used?
-
Page 5: Specification
SPECIFICATION Indoor model MSC-C07SV - MSC-C09SV - MSC-C12SV - Cooling Heating Cooling Heating Cooling Heating Function Single phase Single phase Single phase Indoor unit power supply 220-230V,50Hz 220-230V,50Hz 220-230V,50Hz Air flow(Hi) K /h Capacity Power outlet Running current 0.17 0.17 0.19... - Page 6 Indoor model MSH-C18SV - Function Cooling Heating Single phase Indoor unit power supply 220-230V,50Hz Air flow(Hi) K /h Capacity Power outlet Running current 0.25 Power input Power factor 100.0-95.7 Starting current — Fan motor current 0.25 Model RA4V27-EF Winding WHT-BLK 184 "...
-
Page 7: Noise Criteria Curves
NOISE CRITERIA CURVES MUH-C07SV - MUH-C12SV - MUH-C09SV - NOTCH SPL(dB(A)) LINE NOTCH SPL(dB(A)) LINE FUNCTION FUNCTION COOLING COOLING HEATING HEATING Test conditions, Cooling : DB 35: WB 24: Test conditions, Cooling : DB 35: WB 24: Heating : DB 7: WB 6: Heating : DB 7: WB 6: NC-70 NC-70... -
Page 8: Wiring Diagram
WIRING DIAGRAM MSC-C07SV - MSC-C09SV - MSC-C12SV - MODELS WIRING DIAGRAM INDOOR UNIT TO OUTDOOR UNIT TAB12 RT12 CONNECTING HIC1 CN201 RT11 NR11 CN202 TRANS SR141 CN211 LD101T POWER ELECTRONIC CONTROL P.C. BOARD SUPPLY CORD ~/N 220-230V 50Hz POWER MONITOR, RECEIVER P.C.BOARD... - Page 9 MSH-C18SV - MODEL WIRING DIAGRAM INDOOR UNIT TO OUTDOOR UNIT RT12 CONNECTING HIC1 IC141 220-230V~ CN201 CN211 TRANS POWER SUPPLY CN CN ELECTRONIC CONTROL P.C BOARD RT11 101 102 CORD ~/N 220-230V 50Hz GRN/YLW DISPLAY RECEIVER CIRCUIT BREAKER P.C.BOARD P.C.BOARD REMOTE CONTROLLER NAME...
-
Page 10: Refrigerant System Diagram
REFRIGERANT SYSTEM DIAGRAM Unit:mm MUH-C07SV - MSC-C07SV - MUH-C09SV - MSC-C09SV - INDOOR UNIT OUTDOOR UNIT Refrigerant pipe [ 9.52 (Option) Reversing valve (with heat insulator) Muffler Defrost Indoor coil Indoor Stop valve thermistor Outdoor thermistor heat (with service heat... -
Page 11: Performance Curves
MSH-C18SV - MUH-C18SV - Refrigerant pipe [15.88 Reversing valve (Option) OUTDOOR UNIT INDOOR UNIT Muffler (with heat insulator) Indoor coil Stop valve Indoor thermistor Strainer heat RT12 (with service port) Outdoor exchanger Distributor heat Defrost Flared connection exchanger thermistor RT61 Room temperature thermistor RT11... - Page 12 MUH-S09SV - MUH-C09SV - (kgf/F [Gauge])(MPa [Gauge]) 220V 220V/230V 230V 35(:) 35(:) 70(%) 70(%) Ambient temperature(˚C) Ambient temperature(˚C) Ambient humidity(%) Ambient humidity(%) (kgf/F [Gauge])(MPa [Gauge]) MUH-C12SV - MUH-C12SV - 220V 230V 220V/230V 30 32 35(:) 70(%) 70(%) Ambient temperature(˚C) Ambient temperature(˚C) Ambient humidity(%) Ambient humidity(%) MUH-C18SV -...
-
Page 13: Heat Operation
HEAT operation Condition indoor :Dry bulb temperature 20.0°C Outdoor :Dry bulb temperature 7,15,20°C :Wet bulb temperature 14.5°C :Wet bulb temperature 6,12,14.5°C MUH-C09SV - MUH-C07SV - 220V 220V/230V 230V 25(:) 25(:) Ambient temperature(˚C) Ambient temperature(˚C) MUH-C12SV - MUH-C18SV - 220V 230V 220V/230V 25(:) Ambient temperature(˚C) - Page 14 PERFORMANCE DATA COOL operation (230V) MSC-C07SV - MUH-C07SV - CAPACITY:2.2(KW) SHF:0.74 INPUT:760(W) OUTDOOR DB(:) INDOOR INDOOR DB( : ) WB(:) SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT 2.59 1.45 0.56 2.48 1.39 0.56 2.38 1.33 0.56 2.29 1.28 0.56...
- Page 15 PERFORMANCE DATA COOL operation (230V) MSC-C07SV - MUH-C07SV - CAPACITY:2.2(KW) SHF:0.74 INPUT:760(W) OUTDOOR DB(:) INDOOR INDOOR DB(:) WB(:) SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT 2.16 1.21 0.56 1.98 1.11 0.56 1.90 1.07 0.56 1.83 1.02 0.56 2.27 1.00 0.44...
- Page 16 PERFORMANCE DATA COOL operation (230V) MSC-C09SV - MUH-C09SV - CAPACITY:2.5(KW) INPUT:990(W) SHF:0.70 OUTDOOR DB(:) INDOOR INDOOR DB(:) WB(:) SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT 2.94 1.53 0.52 2.81 1.46 0.52 2.70 1.40 0.52 2.60 1.35 0.52 3.06 1.23 0.40 2.94 1.18 0.40 2.85 1.14 0.40...
- Page 17 PERFORMANCE DATA COOL operation (230V) MSC-C09SV - MUH-C09SV - CAPACITY:2.5(KW) SHF:0.70 INPUT:990(W) OUTDOOR DB( :) INDOOR INDOOR DB(:) WB(:) SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT 2.45 1.27 0.52 2.25 1.17 0.52 1030 2.16 1.12 0.52 1049 2.08 1.08 0.52 1069...
- Page 18 PERFORMANCE DATA COOL operation (230V) MSC-C12SV - MUH-C12SV - CAPACITY:3.4(KW) SHF:0.67 INPUT:1280(W) OUTDOOR DB(:) INDOOR INDOOR DB(:) WB(:) SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT 4.00 1.96 0.49 1024 3.83 1.87 0.49 1075 3.67 1.80 0.49 1126 3.54 1.73 0.49 1178...
- Page 19 PERFORMANCE DATA COOL operation (230V) MSC-C12SV - MUH-C12SV - CAPACITY:3.4(KW) SHF:0.67 INPUT:1280(W) OUTDOOR DB(:) INDOOR INDOOR DB(:) WB(:) SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT 3.33 1.63 0.49 1254 3.06 1.50 0.49 1331 2.94 1.44 0.49 1357 2.82 1.38 0.49 1382...
- Page 20 PERFORMANCE DATA COOL operation (230V) MSH-C18SV - MUH-C18SV - CAPACITY:5.1(KW) INPUT:2140(W) SHF:0.66 OUTDOOR DB(:) INDOOR INDOOR DB(:) WB(:) SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT 5.99 2.88 0.48 1712 5.74 2.75 0.48 1798 5.51 2.64 0.48 1883 5.30 2.55 0.48 1969...
- Page 21 PERFORMANCE DATA COOL operation (230V) MSH-C18SV - MUH-C18SV - CAPACITY:5.1(KW) SHF:0.66 INPUT:2140(W) OUTDOOR DB(:) INDOOR INDOOR DB(:) WB(:) SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT SHC SHF INPUT 5.00 2.40 0.48 2097 4.59 2.20 0.48 2226 4.41 2.12 0.48 2268 4.23 2.03 0.48 2311...
- Page 22 PERFORMANCE DATA HEAT operation (230V) MSC-C07SV - MUH-C07SV - CAPACITY:2.4(KW) INPUT:690(W) OUTDOOR DB(:) INDOOR DB(:) INPUT INPUT INPUT INPUT INPUT INPUT INPUT 1.51 1.82 2.14 2.45 2.76 3.05 3.36 1.44 1.73 2.04 2.33 2.64 2.93 3.23 1.30 1.61 1.90 2.21 2.52...
-
Page 23: Service Functions
SERVICE FUNCTIONS MUH-C07SV - MSC-C07SV - MUH-C09SV - MSC-C09SV - MUH-C12SV - MSC-C12SV - MUH-C18SV - MSH-C18SV - 7-1. COMPULSORY DEFROSTING MODE FOR SERVICE By short circuit of the connector JP607 and R853 on the outdoor deicer P.C. board, defrosting mode can be accomplished regardless of the defrost interval restriction. -
Page 24: Parts List
PARTS LIST MSC-C07SV - (WH) MSC-C09SV - (WH) MSC-C12SV - (WH) 9-2. ACCESSORY PART AND 9-1. INDOOR UNIT STRUCTURAL PARTS REMOTE CONTROLLER 4 (W) 3 (W) (W)These figures show about MSC-C12SV. 9-1. INDOOR UNIT STRUCTURAL PARTS Q'ty/unit Symbol Part No. - Page 25 MSC-C07SV - (WH) MSC-C09SV - (WH) MSC-C12SV - (WH) 9-4. INDOOR UNIT HEAT EXCHANGER 9-3. INDOOR UNIT FUNCTIONAL PARTS AND ELECTRICAL PARTS 19 (W) SLEEVE BEARING ROOM TEMPERATURE THERMISTOR FUSE VARISTOR (W)These figures show about MSC-C12SV. 9-3. INDOOR UNIT FUNCTIONAL PARTS AND ELECTRICAL PARTS...
- Page 26 MUH-C07SV - MUH-C09SV - MUH-C12SV - 9-5. OUTDOOR UNIT STRUCTURAL PARTS Part number that is circled is not shown in the illustration. Q'ty/unit Symbol in Wiring Remarks Part name Part No. MUH-C07SV- MUH-C12SV- MUH-C09SV- Diagram E02 336 232 CABINET E02 336 297 TOP PANEL E02 336 521 GRILLE(OUT)
-
Page 27: Accessory Parts
MUH-C07SV - MUH-C09SV - MUH-C12SV - 9-6. OUTDOOR UNIT 9-7. ACCESSORY PARTS FUNCTIONAL PARTS AND ELECTRICAL PARTS 9-6. OUTDOOR UNIT FUNCTIONAL PARTS AND ELECTRICAL PARTS Part number that are circled are not shown in the illustration. Q'ty/unit Symbol Part No. in Wiring Remarks Part name... - Page 28 MSH-C18SV - (WH) 9-8. INDOOR UNIT 9-9. ACCESSORY PART STRUCTURAL PARTS AND REMOTE CONTROLLER Optional parts 9-8. INDOOR UNIT STRUCTURAL PARTS Part number that is circled is not shown in the illustration. Symbol Q'ty/unit in Wiring Part No. MSH-C18SV- Remarks Part Name (WH) Diagram...
- Page 29 MSH-C18SV - (WH) 9-11. INDOOR UNIT 9-10. INDOOR UNIT HEAT EXCHANGER FUNCTIONAL PARTS AND ELECTRICAL PARTS SLEEVE BEARING INDOOR COIL ROOM TEMPERATURE THERMISTOR THERMISTOR 9-10. INDOOR UNIT FUNCTIONAL PARTS AND ELECTRICAL PARTS Part number that are circled are not shown in the illustration. Q'ty/unit Symbol MSH-C18SV-...
- Page 30 MUH-C18SV - DEFROST THERMISTOR 9-12. OUTDOOR UNIT STRUCTURAL PARTS, FUNCTIONAL PARTS AND ELECTRICAL PARTS Part number that are circled are not shown in the illustration. Q'ty/unit Symbol Part No. Part Name in Wiring Remarks MUH-C18SV- Diagram CABINET E02 141 232 GRILLE E02 141 521 SERVICE PANEL...
- Page 31 MUH-C18SV - 9-13. ACCESSORY PARTS Q'ty/unit Symbol in Wiring Remarks Part No. Part Name MUH-C18SV- Diagram DRAIN SOCKET E02 444 704 DRAIN CAP E02 444 705 DRAIN CAP [16.2 E02 444 706...
- Page 32 HEAD OFFICE MITSUBISHI DENKI BLDG.MARUNOUCHI TOKYO100-8310 TELEX J24532 CABLE MELCO TOKYO C C Copyright 2000 MITSUBISHI ELECTRIC ENGINEERING CO.,LTD Issued in Mar. 2000. No.OB250 REVISED EDITION-A 27 New publication, effective Mar. 2000 Issued in Jan. 2000. No.OB250 27 Specifications subject to change without notice.
