- Page 1 Series ® Intel Quad-core / Core 2 Extreme / Core 2 Duo ® ® ® / Pentium D / Pentium 4 / Celeron D mATX Main Board User’s Manual Ver. 1.00...
-
Page 2: Table Of Contents
Contents Notices ......................v Safety information ..................vi iQ965-IGM specifications summary .............ix Chapter 1 : Product introduction Special features ................1-2 Before you proceed ............... 1-5 Motherboard overview ..............1-6 1.3.1 Placement direction ............1-6 1.3.2 Screw holes ..............1-6 1.3.3 Motherboard layout (standard version) ......1-7 1.3.4 Motherboard layout (optional version) ...... -
Page 3: Notices
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. -
Page 4: Safety Information
Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. -
Page 5: About This Guide
About this guide This user guide contains the information you need when installing and configuring the motherboard. How this guide is organized This manual contains the following parts: • Chapter 1: Product introduction This chapter describes the features of the motherboard and the new technology it supports. -
Page 6: Conventions Used In This Guide
Conventions used in this guide To make sure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task. CAUTION: Information to prevent damage to the components when trying to complete a task. -
Page 7: Iq965-Igm Specifications Summary
iQ965-IGM specifications summary LGA775 socket for Intel Quad-core / Core 2 Extreme/ ® ™ Core Core 2 Duo / Pentium D / Pentium 4 / Celeron ™ ® ® ® processor processor Compatible with Intel 05B/05A/06 processors ® Intel Hyper-Threading Technology ready ® Chipset Intel Q965 / ICH8 or ICH8DO (optional) with Intel... - Page 8 iQ965-IGM specifications summary 10 x USB 2.0 ports (6 ports at mid-board, 4 ports at back panel) Back Panel I/O Ports 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x Parallel port 1 x External Serial ATA port 1 x VGA port 1 x IEEE 1394a connector (optional) 1 x RJ45 port 4 x USB 2.0/1.1 ports 8-channel Audio I/O ports (6 jacks)
-
Page 9: Chapter 1 : Product Introduction
This chapter describes the motherboard f e a t u r e s a n d t h e n e w t e c h n o l o g i e s it supports. Product introduction... -
Page 10: Special Features
Special features Intel Core™2 Processor Ready ® This motherboard supports the latest Intel® Core™2 processor in the LGA775 package. With the new Intel® Core™ microarchitecture technology and 1066/800/ 533 MHz FSB, Intel® Core™2 processor is one of the most powerful and energy efficient CPU in the world. - Page 11 DDR2 memory support The motherboard supports DDR2 memory that features data transfer rates of 800/667/533 MHz to meet the higher bandwidth requirements of the latest 3D graphics, multimedia, and Internet applications. The dual-channel DDR2 architecture doubles the bandwidth of your system memory to boost system performance, eliminating bottlenecks with peak bandwidths of up to 12.8 GB/s.
-
Page 12: High Definition Audio
Dual RAID solution (Intel ICH8DO only) ® ® The Intel ICH8DO chipset incorporates six Serial ATA connectors with high performance RAID 0, 1, 5 and 10 functions. The JMicron controller provides another two Serial ATA connectors for RAID 0, 1, and JBOD functions. Making this motherboard an ideal solution to enhance hard disk performance and data back up protection without the cost of add-on cards. -
Page 13: Before You Proceed
Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. • Unplug the power cord from the wall socket before touching any component. • Use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, before handling components to avoid damaging them due to static electricity. -
Page 14: Motherboard Overview
Motherboard overview Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components. -
Page 15: Motherboard Layout (Standard Version)
1.3.3 Motherboard layout (standard version) 24.5cm (9.6in) PWR_FAN CHA_FAN PS/2KBMS T : Mouse CPU_FAN KBPWR B: Keyboard Super I/O ESATA LGA775 USB12 ATX12V Intel LAN_USB34 Q965 RTL8111B AUDIO SATA_RAID1 PCIEX16 JMicron JMB363 COM1 PCI1 TPM_SLOT CHA_FAN2 TSB43AB22A SB_PWR SATA1 SATA2 Intel PCI2 ICH8... -
Page 16: Motherboard Layout (Optional Version)
1.3.4 Motherboard layout (optional version) *South bridge changes to ICH8, and IEEE1394 is applied. 24.5cm (9.6in) PWR_FAN CHA_FAN PS/2KBMS T : Mouse CPU_FAN KBPWR B: Keyboard Super I/O ESATA LGA775 1394_USB12 ATX12V Intel LAN_USB34 Q965 RTL8111B AUDIO SATA_RAID1 PCIEX16 JMicron JMB363 COM1 PCI1 TPM_SLOT... -
Page 17: Layout Contents
1.3.5 Layout contents Slots Page DDR2 DIMM slots 1-18 PCI slots 1-27 PCI Express x 4 slot 1-27 PCI Express x16 slot 1-27 Jumper Page Clear RTC RAM (3-pin CLRTC) 1-28 Keyboard power (3-pin KBPWR) 1-29 Rear panel connectors Page PS/2 mouse port (green) 1-30 Parallel port 1-30 3. IEEE 1394a port 1-30 LAN (RJ-45) port 1-30 Rear Speaker Out port (black) 1-30... - Page 18 Internal connectors Page Floppy disk drive connector (34-1 pin FLOPPY) 1-32 Digital Audio connector (4-1 pin SPDIF_OUT) 1-32 IDE connector (40-1 pin PRI_IDE) 1-33 ICH8DO Serial ATA connectors (7-pin SATA1 [red], SATA2 [red], 1-34 SATA3 [red], SATA4 [red], SATA5 [black], SATA6 [black]) IEEE 1394a port connector (10-1 pin IE1394_2) 1-34 ®...
-
Page 19: Central Processing Unit (Cpu)
Central Processing Unit (CPU) The motherboard comes with a surface mount LGA775 socket designed for the ® ® ® ® Intel Core™2 Extreme/Core™2 Duo/Pentium D/Pentium 4 and Celeron processors. • Make sure the AC power is off before you install the CPU. •... -
Page 20: Installing The Cpu
1.4.1 Installing the CPU To install a CPU: Locate the CPU socket on the motherboard. iQ965-IGM CPU socket 775 Before installing the CPU, make sure that the cam box is facing towards you and the load lever is on your left. Press the load lever with your thumb (A), then move it to the left (B) until it is released from the retention tab. - Page 21 Lift the load plate with your thumb and forefinger to a 100º angle (A), then push the PnP cap from the load plate window to remove (B). Load plate Alignment key Position the CPU over the socket, making sure that the gold triangle is on the bottom-left corner of the socket then fit the socket alignment key into the...
-
Page 22: Installing The Cpu Heatsink And Fan
1.4.2 Installing the CPU heatsink and fan ® The Intel LGA775 processor requires a specially designed heatsink and fan assembly to ensure optimum thermal condition and performance. ® • When you buy a boxed Intel processor, the package includes the CPU fan and heatsink assembly. - Page 23 Push down two fasteners at a time in a diagonal sequence to secure the heatsink and fan assembly in place. Connect the CPU fan cable to the connector on the motherboard labeled CPU_FAN. CPU_FAN iQ965-IGM CPU Fan Connector Do not forget to connect the CPU fan connector! Hardware monitoring errors can occur if you fail to plug this connector.
-
Page 24: Uninstalling The Cpu Heatsink And Fan
1.4.3 Uninstalling the CPU heatsink and fan To uninstall the CPU heatsink and fan: 1. Disconnect the CPU fan cable from the connector on the motherboard. Rotate each fastener counterclockwise. Pull up two fasteners at a time in a diagonal sequence to disengage the heatsink and fan assembly from the motherboard. - Page 25 Rotate each fastener clockwise to ensure correct orientation when reinstalling. Narrow end of the groove The narrow end of the groove should point outward after resetting. (The photo shows the groove shaded for emphasis.) Refer to the documentation in the boxed or stand-alone CPU fan package for detailed information on CPU fan installation.
-
Page 26: System Memory
System memory 1.5.1 Overview The motherboard comes with four Double Data Rate 2 (DDR2) Dual Inline Memory Modules (DIMM) sockets. A DDR2 module has the same physical dimensions as a DDR DIMM but has a 240-pin footprint compared to the 184-pin DDR DIMM. DDR2 DIMMs are notched differently to prevent installation on a DDR DIMM socket. - Page 27 • You may install varying memory sizes in Channel A and Channel B. The system maps the total size of the lower-sized channel for the dual-channel configuration. Any excess memory from the higher-sized channel is then mapped for single-channel operation. •...
- Page 28 iQ965-IGM Motherboard Qualified Vendors Lists (QVL) DDR2-800MHz capability DIMM support Size Vendor Chip No. Part No. • • • 512MB KINGSTON K4T51083QC KVR800D2N5/512 1024MB KINGSTON K4T51083QC KVR800D2N5/1G • • • 1024MB KINGSTON Heat-Sink Package KHX6400D2LL/1G • 1024MB KINGSTON Heat-Sink Package KHX6400D2LLK2/1GN •...
- Page 29 iQ965-IGM Motherboard Qualified Vendors Lists (QVL) DDR2-667MHz capability DIMM support Size Vendor Chip No. Part No. • • • 512MB KINGSTON E5108AE-6E-E KVR667D2N5/512 1024MB KINGSTON E5108AE-6E-E KVR667D2N5/1G • • • 512MB KINGSTON E5108AE-6E-E KVR667D2E5/512 • • • • • • 256MB KINGSTON HYB18T256800AF3...
- Page 30 iQ965-IGM Motherboard Qualified Vendors Lists (QVL) DDR2-553 MHz capability DIMM support Size Vendor Chip No. Part No. • • 256MB KINGSTON E5116AF-5C-E KVR533D2N4/256 • • • 512MB KINGSTON HYB18T512800AF37 KVR533D2N4/512 1024MB KINGSTON 5YDIID9GCT KVR533D2N4/1G • • • 256MB Qimonda HYB18T512160AF-3.7 HYS64T32000HU-3.7-A •...
-
Page 31: Installing A Dimm
1.5.3 Installing a DIMM Unplug the power supply before adding or removing DIMMs or other system components. Failure to do so can cause severe damage to both the motherboard and the components. To install a DIMM: DDR2 DIMM notch Unlock a DIMM socket by pressing the retaining clips outward. -
Page 32: Expansion Slots
Expansion slots In the future, you may need to install expansion cards. The following sub-sections describe the slots and the expansion cards that they support. Make sure to unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components. -
Page 33: Interrupt Assignments
1.6.3 Interrupt assignments Standard interrupt assignments Priority Standard function System Timer Keyboard Controller – Redirect to IRQ#9 IRQ holder for PCI steering* Communications Port (COM1)* IRQ holder for PCI steering* Floppy Disk Controller Printer Port (LPT1)* System CMOS/Real Time Clock IRQ holder for PCI steering* IRQ holder for PCI steering* IRQ holder for PCI steering* PS/2 Compatible Mouse Port*... - Page 34 IRQ assignments for this motherboard A C PCI Slot 1 shared — — — — — — — PCI Slot 2 — shared — — — — — — PCIE x 16_1 shared — — — — — — — PCIE x 4_1 shared —...
-
Page 35: Pci Slots
1.6.4 PCI slots The PCI slots support cards such as a LAN card, SCSI card, USB card, and other cards that comply with PCI specifications. The figure shows a LAN card installed on a PCI slot. 1.6.5 PCI Express x4 slot This motherboard supports PCI Express x4 network cards, SCSI cards and other cards that comply with the PCI Express specifications. -
Page 36: Jumper
Jumper Clear RTC RAM (CLRTC) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords. - Page 37 Keyboard power (3-pin KBPWR) This jumper allows you to enable or disable the keyboard wake-up feature. Set this jumper to pins 2-3 (+5VSB) to wake up the computer when you press a key on the keyboard (the default is the Space Bar). This feature requires an ATX power supply that can supply at least 1A on the +5VSB lead, and a corresponding setting in the BIOS.
-
Page 38: Connectors
Connectors 1.8.1 Rear panel connectors (Optional) PS/2 mouse port (green). This port is for a PS/2 mouse. Parallel port. This 25-pin port connects a parallel printer, a scanner, or other devices. IEEE 1394a port (optional). This 6-pin IEEE 1394a port provides high-speed connectivity for audio/video devices, storage peripherals, PCs, or portable devices. - Page 39 Refer to the audio configuration table below for the function of the audio ports in 2, 4, 6, or 8-channel configuration. Audio 2, 4, 6, or 8-channel configuration Port Headset 4-channel 6-channel 8-channel 2-channel Light Blue Line In Line In Line In Line In Lime Line Out Front Speaker Out...
-
Page 40: Internal Connectors
1.8.2 Internal connectors Floppy disk drive connector (34-1 pin FLOPPY) This connector is for the provided floppy disk drive (FDD) signal cable. Insert one end of the cable to this connector, then connect the other end to the signal connector at the back of the floppy disk drive. Pin 5 on the connector is removed to prevent incorrect cable connection when using a FDD cable with a covered Pin 5. - Page 41 IDE connector (40-1 pin PRI_EIDE) The onboard IDE connector is for the Ultra DMA 133/100/66 signal cable. There are three connectors on each Ultra DMA 133/100/66 signal cable: blue, black, and gray. Connect the blue connector to the motherboard’s IDE connector, then select one of the following modes to configure your device.
- Page 42 Serial ATA connectors (7-pin SATA1[red], SATA2 [red], SATA3 [red], SATA4 [red], SATA5 [black], SATA6 [black]) These connectors are for the Serial ATA signal cables for Serial ATA hard disk drives. *SATA5 and SATA6 exist with ICH8DO only. SATA1 SATA2 SATA1 SATA2 SATA1 SATA2...
- Page 43 ® JMicron JMB363 Serial ATA RAID connector (7-pin SATA_RAID1) This connector is for a Serial ATA signal cable. This connector supports a Serial ATA hard disk drive, which you can combine with an external Serial ATA hard disk drive to configure for RAID via the unboard Serial ATA RAID controller. The JMicron controller mode item in the BIOS is set to [BASIC] by default.
- Page 44 USB connectors (10-1 pin USB56, USB 78, USB910) These connectors are for USB 2.0 ports. Connect the USB module cable to any of these connectors, then install the module to a slot opening at the back of the system chassis. These USB connectors comply with USB 2.0 specification that supports up to 480 Mbps connection speed.
- Page 45 10. CPU, chassis, and power fan connectors (4-pin CPU_FAN, 3-pin CHA_FAN, 3-pin CHA_FAN2, 3-pin PWR_FAN) The fan connectors support cooling fans of 350 mA ~ 2000 mA (24 W max.) or a total of 1 A ~ 7 A (84 W max.) at +12V. Connect the fan cables to the fan connectors on the motherboard, making sure that the black wire of each cable matches the ground pin of the connector.
- Page 46 12. Chassis intrusion connector (4-1 pin CHASSIS) This connector is for a chassis-mounted intrusion detection sensor or switch. Connect one end of the chassis intrusion sensor or switch cable to this connector. The chassis intrusion sensor or switch sends a high-level signal to this connector when a chassis component is removed or replaced.
- Page 47 14. ATX power connectors (24-pin EATXPWR, 4-pin EATX12V) These connectors are for ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. EATX12V +12V DC +12V DC...
- Page 48 15. System panel connector (10-1 pin F_PANEL) This connector supports several chassis-mounted functions. PLED PWRSW F_PANEL RESET IDELED Requires an ATX power supply System Panel Connector iQ965-IGM • System power LED (2-pin PLED) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector.
