- Page 1 ROSCH-Q67-FVISA Industrial Computer Board...
-
Page 2: Trademarks
▍ Preface Copyright Notice We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are under continual improve- ment and we reserve the right to make changes without notice. Trademarks All trademarks are the properties of their respective owners. -
Page 3: Safety Instructions
ROSCH-Q67-FVISA Safety Instructions ￭ Always read the safety instructions carefully. ￭ Keep this User’s Manual for future reference. ￭ Keep this equipment away from humidity. ￭ Lay this equipment on a reliable flat surface before setting it up. ￭ The openings on the enclosure are for air convection hence protects the equipment from overheating. -
Page 4: Fcc-B Radio Frequency Interference Statement
▍ Preface FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Weee ( Waste Electrical And Electronic Equipment ) Statement
ROSCH-Q67-FVISA WEEE ( ) Statement Waste Electrical and Electronic Equipment ENGLISH To protect the global environment and as an environmentalist, we must remind you that... Under the European Union (“EU”) Directive on Waste Electrical and Electronic Equipment, Directive 2002/96/EC, which takes effect on August 13, 2005, products of “electrical and electronic equipment”... -
Page 6: Table Of Contents
▍ Preface ▍ CoNTENTS Copyright Notice �������������������������������������������������������������������������������������������������� ii Trademarks ���������������������������������������������������������������������������������������������������������� ii Revision History �������������������������������������������������������������������������������������������������� ii Technical Support ����������������������������������������������������������������������������������������������� ii Safety Instructions ��������������������������������������������������������������������������������������������� iii FCC-B Radio Frequency Interference Statement �������������������������������������������� iv Waste Electrical and Electronic Equipment WEEE ( ) Statement ��������� v Chapter 1 overview ������������������������������������������������������������������������������������������... -
Page 7: Chapter 1 Overview
Chapter 1 overview Thank you for choosing this product, an excellent in- dustrial computer board. Based on the innovative Intel Q67 chipsets for op- ® timal system efficiency, the board accommodates the Intel Core™i7 / i5 / i3 or Celeron processor in ®... -
Page 8: Mainboard Specifications
▍ Overview ainboard pecificationS ■ Intel Core™i7 / i5 / i3 or Celeron processor in ® ® Socket 1155 ■ Chipset Intel Q67 Chipset ® ■ Memory 2 unbuffered DDR3 1066/1333 DIMM slots ■ Supports the maximum of 32GB ■ Intel 82579LM Gigabit Fast Ethernet controller ®... - Page 9 ROSCH-Q67-FVISA Back ■ Back Panel I/O 2 COM ports Panel I/o 1 DVI-I port & Connec- 1 Display port tors/Pin- 10 USB 2.0 ports* headers 2 USB 3.0 ports* 2 Gigabit LAN jacks *Each port can provide 500mA output. ■...
-
Page 10: Mainboard Layout
▍ Overview ainboard ayout System Fan Connector Power CPU Fan DIMM Slots Connector Connector Front Panel Connector J4 Connector Serial Port Connectors Back Panel Power Connector PCIE x16 Slot LVDS Connector LVDS Power Connector Connector PCIE x4 Slot SATA Connectors PCIE x1 Slot PCI Slots Chassis Intrusion Connector... -
Page 11: Chapter 2 Hardware Setup
Chapter 2 Hardware Setup This chapter provides you with the information on mainboard hardware configurations. Incorrect setting of jumpers and connectors may damage your main- board. Please pay special attention not to connect these headers in wrong direction. DO NOT adjust any jumper while the mainboard is powered on. - Page 12 ▍ Hardware Setup uick oMponentS uide System Fan Connector Power CPU Fan DIMM Slots Connector Connector Front Panel Connector J4 Connector Serial Port Connectors Back Panel Power Connector PCIE x16 Slot LVDS Connector LVDS Power Connector Connector PCIE x4 Slot SATA Connectors PCIE x1 Slot PCI Slots...
-
Page 13: Cpu (Central Processing Unit)
ROSCH-Q67-FVISA cpu (c entraL roceSSinG When you are installing the CPU, make sure that you install the cooler to prevent overheating. If you do not have the CPU cooler, consult your dealer before turning on the computer. Important Overheating Overheating will seriously damage the CPU and system. Always make sure the cooling fan can work properly to protect the CPU from overheat- ing. - Page 14 ▍ Hardware Setup CPU & Cooler Installation When you are installing the CPU, make sure the CPU has a cooler at- tached on the top to prevent overheating. Meanwhile, do not forget to apply some thermal paste on CPU before installing the heat sink/cooler fan for better heat dispersion.
- Page 15 ROSCH-Q67-FVISA Secure the lever near the Make sure the four hooks are hook end under the reten- in proper position before you tion tab. install the cooler. Align the holes on the mainboard with the cooler. Push down the cooler until its four clips get wedged into the holes of the mainboard.
-
Page 16: Memory
▍ Hardware Setup eMory These DIMM slots are intended for memory modules. DDR3 240-pin, 1�5V 48x2=96 pin 72x2=144 pin Dual-Channel mode Population Rule In Dual-Channel mode, the memory modules can transmit and receive data with two data bus lines simultaneously. Enabling Dual-Channel mode can enhance the system performance. - Page 17 ROSCH-Q67-FVISA Installing Memory Modules The memory module has only one notch on the center and will only fit in the right orientation. Insert the memory module vertically into the DIMM slot. Then push it in until the golden finger on the memory module is deeply inserted in the DIMM slot.
-
Page 18: Power Supply
▍ Hardware Setup ower uppLy 24-Pin Power Connector: JPWR1 This connector allows you to connect an 24-pin power supply. To con- nect the 24-pin power supply, make sure the plug of the power supply is inserted in the proper orientation and the pins are aligned. Then push down the power supply firmly into the connector. -
Page 19: Back Panel I/O
ROSCH-Q67-FVISA aneL DVI-I Port LAN Ports DisplayPort Serial Port USB 2�0 Port USB 3�0 Port ▶ Serial Port The serial port is a 16550A high speed communications port that sends/ receives 16 bytes FIFOs. You can attach a serial mouse or other serial devices directly to the connector. - Page 20 ▍ Hardware Setup ▶ LAN Port The standard RJ-45 LAN jack is for connection to the Local Area Network (LAN). You can connect a network cable to it. Activity Indicator Speed Indicator Left LED Right LED Active LED 100M/1000M Speed LED LED Color Yellow Green/Orange...
-
Page 21: Connector
ROSCH-Q67-FVISA onnector Chassis Intrusion Connector: JCI1 This connector is provided to connect the chassis intrusion switch cable. If the chassis is opened, the chassis intrusion mechanism will be acti- vated. The system will record this status and show a warning message on the screen. - Page 22 ▍ Hardware Setup Fan Power Connector: CPUFAN1 / SYSFAN1 The fan power connectors support system cooling fan with +12V. When connecting the wire to the connectors, always note that the red wire is the positive and should be connected to the +12V; the black wire is Ground and should be connected to GND.
- Page 23 ROSCH-Q67-FVISA LVDS Flat Panel Connector: JLVDS1 The LVDS (Low Voltage Differential Signal) connector provides a digital interface typically used with flat panels. After connecting an LVDS inter- faced flat panel to the JLVDS1, be sure to check the panel datasheet and set the J2 jumper for proper power voltage.
- Page 24 ▍ Hardware Setup Front Panel Connectors: JFP1 These connectors are for electrical connection to the front panel switches and LEDs. The JFP1 is compliant with Intel® Front Panel I/O Connectivity Design Guide. Front USB Connector: JUSB1 / JUSB2 This connector, compliant with Intel I/O Connectivity Design Guide, is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like.
- Page 25 ROSCH-Q67-FVISA S/PDIF Connector: JSPD1 This connector is used to connect S/PDIF (Sony & Philips Digital Interconnect Format) interface for digital audio transmission. Parallel Port Header: JLPT1 The mainboard provides a 26-pin header for connection to an optional parallel port bracket. The parallel port is a standard printer port that sup- ports Enhanced Parallel Port (EPP) and Extended Capabilities Parallel Port (ECP) mode.
- Page 26 ▍ Hardware Setup Serial Port Connector: CoM3~6 (two for RS-232, two for RS-232/-422/-485) This connector is a 16550A high speed communications port that sends/receives 16 bytes FIFOs. You can attach a serial device to it through an optional serial port bracket.
- Page 27 ROSCH-Q67-FVISA Front Panel Audio Connector: JAUD1 This connector allows you to connect the front panel audio and is compli- ant with Intel Front Panel I/O Connectivity Design Guide. ® Audio Amplifier Connector: JAMP1 The JAMP1 is used to connect audio amplifiers to enhance audio per- formance.
-
Page 28: Jumper
▍ Hardware Setup uMper Clear CMoS Jumper: JBAT1 There is a CMOS RAM onboard that has a power supply from an external battery to keep the data of system configuration. With the CMOS RAM, the system can automatically boot OS every time it is turned on. If you want to clear the system configuration, set the jumper to clear data. - Page 29 ROSCH-Q67-FVISA Serial Port Power Jumper: JCOMP1/ JCOMP2 This jumper specifies the operation voltage of the onboard serial ports. Important Avoid adjusting the jumper when the system is on; it will damage the mainboard. LVDS Power Jumper: JVDD1 Use this jumper to specify the LVDS power.
-
Page 30: Slot
▍ Hardware Setup PCIE (Peripheral Component Interconnect Ex- press) Slot The PCIE slot supports the PCIE interface expansion card. PCIE x16 Slot PCIE x4 Slot PCIE x1 Slot PCI (Peripheral Component Interconnect) Slot The PCI slot supports LAN card, SCSI card, USB card, and other add-on cards that comply with PCI specifications. - Page 31 ROSCH-Q67-FVISA ISA (Industry Standard Architecture) Slot The ISA slot supports the ISA interface expansion card. 2-21...
