USER MANUAL
VERSION 1.0 November 2013
TeosWide 10D2E 10D2P
TeosWide 1007E 1007P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TeosWide 10D2E and is the answer not in the manual?

Questions and answers

Summary of Contents for AURES TeosWide 10D2E

  • Page 1 USER MANUAL VERSION 1.0 November 2013 TeosWide 10D2E 10D2P TeosWide 1007E 1007P...
  • Page 2: Important Safety Instructions

    Copyright 2013 All Rights Reserved Manual Version 1.0 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 3: Caution On Lithium Batteries

    CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
  • Page 4 LEGISLATION AND WEEE SYMBOL 2012/19/EU Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.
  • Page 5: Revision History

    Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release November 2013...
  • Page 6: Table Of Contents

    Table of Contents 1. Packing List ........1 1-1. Standard Items ..............1 2. System View ........2 2-1. Front & Side View ............2 2-2. Rear View .................2 2-3. I/O View ................3 2-4. Dimensions ..............4 3. System Assembly ......5 3-1. Open the Chassis Cover ..........5 3-2.
  • Page 7 The page is intentionally left blank.
  • Page 8: Packing List

    Packing List 111. Standard Items System Power adapter Power cord RJ45-DB9 cable (x4) USB cable (x2) Power extended cable LAN extender cable Manual CD Note: Power cord will be supplied differently according to various region or country.
  • Page 9: System View

    System View 211. Front & Side View Item No. Description Touch screen Built-in web cam Ventilation MSR cable hole 212. Rear View Item No. Description VESA mounting holes Cable cover Power button...
  • Page 10: I/O View

    212. I/O View C56 Motherboard Item No. Description power button Power button DC IN VGA) COM port 1, 2, 3, 4 (from left to right) USBx4 Cash drawer USB(x2) (only one USB if capacitive touch panel) C76 Motherboard Item No. Description power button Power button...
  • Page 11: Dimensions

    212. Dimensions 263mm 38mm...
  • Page 12: System Assembly

    System Assembly 211. Open the Chassis Cover The motherboard and RAM module can be replaced by opening the chassis cover, which is located on the back side of the system. Please follow the steps below to open the chassis cover. 1.
  • Page 13: Ram Module Replacement

    212. RAM Module Replacement To remove and replace the RAM module, please open the chassis cover firstly as steps dscribed in chapter 3-1. Removing a RAM module 1. Find the memory slot at the right side of the motherboard. 2. Flip the ejector clips outwards to remove the memory module from the memory slot.
  • Page 14: Hdd Replacement

    212. HDD Replacement To remove and replace the HDD, please open the cable cover firstly as stpes dscribed in chapter 3-1-1. 1. Loosen the screws(x2) to remove the HDD bracket from the system 2. The HDD is secured by the bracket, remove the screws(x2) to release the bracket and replace the HDD.
  • Page 15: Cash Drawer Installation

    212. Cash Drawer Installation You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 16 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...
  • Page 17: Specification

    Specification Model Name TeosWide 10D2E, 10D2P TeosWide 1007E, 1007P Mainboard Intel CedarView D2550 processor Intel Ivy Bridge CPUCeleron 1.86GHz 1MB Cache 1037U 1.8G, LLC 2MB, 17W CPU integrated graphic + Intel Chipset Intel NM10 HM76 PCH, 4.1W 1 x DDR3 SO-DIMM up to 8GB,...
  • Page 18 Model Name TeosWide 10D2E, 10D2P TeosWide 1007E, 1007P Mainboard Audio Speaker 2 x 2W Power Power Adapter DC 18.5V / 65W Environment FCC /CE Class A/ LVD EMC & Safety FCC /CE Class A/ LVD EN 60601-1-2/ UL Operating Temperature 0°C ~ 35°C ( 32°F ~ 95°F )
  • Page 19: Configuration

    Configuration 511. C56 Motherboard 51111. Motherboard Layout CN11 RJ11_1 SATA2 CN12 USB1 SATA1 USB2 SATA4 RJ45_1 CN19 CN13 CN14 SKT1 RJ45_2 MINI_PCIE1 CN18 CN15 CN10 VGA1 DDR3_A1 PWR1 PWR2 CN16 JP7 JP4 CN17...
  • Page 20: Connectors & Functions

    51112. Connectors & Functions Connector Function Inverter / LED backlight connector LVDS Connector Power LED Connector SATA LED Connector Speaker & MIC Connector SATA Power Connector COM5(Touch) Connector CN10 Printer Port Connector CN11/12 USB Port(Internal) CN13 LAN LED Connector CN14 PS2 Keyboard Connector CN15 Card Reader Connector(COM6)
  • Page 21: Jumper Setting

    51112. Jumper Setting Cash Drawer Power Setting Function ▲ +19V +12V Inverter Selection Function CCFL ▲LED COM2/COM3/COM4 Power Setting COM2, COM3 and COM4 can be set to provide power to your serial device. The voltage can be set to +5V or +12V by setting jumper JP5 and JP6 on the mother- board.
  • Page 22 4. To enable the power, select COM2 ,COM3 or COM4 Power setting and press <Enter>. Select Power and press <Enter>. Save the change by pressing F10. COM2 Power Setting Function ▲No Power COM2 +5V COM2 +12V COM3/COM4 Jumper setup Function ▲+5V COM3 +12V...
  • Page 23 LCD ID Setting LVDS Output Panel# Resolution Bits Channel Interface LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 1024 x 600 Single Panel LVDS 1024 x 768 Single Panel LVDS 1024 x 768 Single...
  • Page 24: C76 Motherboard

    512. C76 Motherboard 51211. Motherboard Layout CN12 JP10 RJ11_1 CN13 SATA1 USB2 RJ45_1 SATA2/SATA3 USB3 CN14 CN24 CN2 CN15 CN18 CN11 MINI_PCIE1 USB1 CN23 CN16 CN17 DDR3_A CN10 CN19 CN20...
  • Page 25: Connectors & Functions

    51212. Connectors & Functions Connector Function Inverter Select Inverter / LED backlight connector Power LED Connector HDD LED Connector Speaker & MIC Connector SATA Power Connector CN10 CMOS battery connector CN11 Printer Port Connector CN12 USB (Internal) CN13 USB (Internal) CN14 PS/2 Keyboard Connector CN15...
  • Page 26: Jumper Setting

    51212. Jumper Setting Inverter Selection Function ▲LED CCFL Cash Drawer Power Setting Function JP10 ▲ +19V +12V COM1 Power Setting Function ▲COM1 +5V COM1 +12V COM2/COM3 Power Setting Function ▲+5V COM2 +12V COM3 ▲+12V ▲ = Manufacturer Default Setting...
  • Page 27 COM1/COM2/COM3 Power Setting COM1, COM2 and COM3 can be set to provide power to your serial device. The voltage can be set to +5V or +12V by setting jumper JP8 and JP9 on the mother- board. When enabled, the power is available on pin 10 of the RJ45 serial connector. If you use the serial RJ45 to DB9 adapter cable, the power is on pin 9 of the DB9 connector.
  • Page 28 LCD ID Setting LVDS Output Panel# Resolution Bits Channel Interface LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 1024 x 768 Single Panel LVDS 1024 x 768 Single Panel LVDS 1366 x 768 Single Panel LVDS 1366 x 768 Single...
  • Page 29: Appendix: Drivers Installation

    Appendix: Drivers Installation To downoad the most recent drivers and utilities, and obtain advice regarding the installation of your equipment, please visit the AURES Technical Support Website: www.aures-support.fr (French) www.aures-support.fr/UK (English) www.aures-support.fr/GE (German)
