- Page 1 DVR5000-2U Series UICK TART UIDE Digital Video Recorder...
- Page 2 THIS QUICK START GUIDE WILL PROVIDE INSTRUCTIONS FOR CONFIGURING THE NVR (SERVER) AND VIEWING VIDEO FROM THE COMMAND CENTER APPLICATION (CLIENT SOFTWARE). INSTEK DIGITAL SEPARATES THE CLIENT AND SERVER INTO TWO DISTINCT ENTITIES. THIS SETUP ALLOWS PLACEMENT OF THE SERVER IN A SECURE, TAMPER-PROOF LOCATION, FURTHER ENHANCING YOUR SECURITY PROTOCOLS.
-
Page 3: Box Contents
Quick Start Guide DVR5000-2U Series BOX CONTENTS MatriVideo DVR x 1 • HDD Tray x 8 • Document CD x1 • Software CD (CCOne) x 1 • Quick Start Guide x 1 • Screws (Set) x 1 • Power Cable •... -
Page 4: Front Panel
Quick Start Guide DVR5000-2U Series Front Panel LCD display Power button Reset button USB ports Power LED Rear Panel (5316-5416) PS/2 Keyboard Connector Ethernet Connector Speaker out / VGA Port audio line in USB Ports RCA Ports for Analog Audio Input... -
Page 5: Step 1: Install Hard Drives
Quick Start Guide DVR5000-2U Series STEP 1: INSTALL HARD DRIVES Insert HDD into tray and use four screws to secure it in place.their slots. Use your thumb to press the key hole of the HDD tray and push it up to unlock the HDD tray. - Page 6 Quick Start Guide DVR5000-2U Series For extra COM port or RS485 direct connection, please contact Instek for the optional USB to RS232/485 converte STEP 2: POWER ON THE NVR Connect the power cord. Power on the NVR. The booting process will take a few minutes to complete. When...
- Page 7 Quick Start Guide DVR5000-2U Series The NVR uses an Embedded Linux Operating System. Once the keyboard and moni- tor are connected to the NVR, you will see the login prompt on the monitor. The NVR default username is: root and the password is: id.
- Page 8 Quick Start Guide DVR5000-2U Series Change the Time Zone: > > or Area > . Press to confirm. Change the Date/Time: > > Press to stop the process and wait for a few seconds > Use [TAB], Up Arrow, Down Arrow to change Year, Month and Date.
- Page 9 Quick Start Guide DVR5000-2U Series To restart NVR processes go back to the hDSM main menu and navigate to > . This will take a few seconds to complete STEP 5: SUBSCRIBE THE NVR Run the Command Center software. During the first run, you will be asked to subscribe (or add) the NVR to the video recorder subscription list.
-
Page 10: Step 7: Setting Up The Cameras
Quick Start Guide DVR5000-2U Series Type in the IP address of the NVR or an available time server. This will keep the time in sync between the NVR and the PC running the Command Center application. STEP 7: SETTING UP THE CAMERAS Right-click on the NVR (labeled by its IP address) in the camera tree panel and click Video Recorder Setup. -
Page 11: Step 8: View The Video
Quick Start Guide DVR5000-2U Series in the table, type a descriptive Camera Name. Select the Type the IP Address of the IP cameras. Domain names are supported if available on the surveillance network. The Port number is dependent on the IP camera. Ch refers to the channel number of the video server. - Page 12 Here at Instek Digital – we are always standing by to provide you the best service and support. Please do not hesitate to contact us for anything. For general information – please call us at one of the following worldwide office:...
