- Page 1 USE & CARE MANUAL Rangetops Heritage Classic Platinum™...
-
Page 2: What To Do If You Smell Gas
BlueStar® Rangetop Use & Care Manual MODELS RNB, Heritage Classic, Platinum™ THIS APPLIANCE WAS DESIGNED FOR EASE OF INSTALLATION AND OPERATION. HOWEVER, WE RECOMMEND THAT YOU READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN INSTALLATION. INSTALLATION MUST BE PERFORMED BY AN APPROVED GAS INSTALLER OR GAS SERVICE TECHNICIAN OR THE WARRANTY IS VOID. IN THE COMMONWEALTH OF MASSACHUSETTS A LICENSED PLUMBER OR GAS FITTER CAPABLE OF REVIEWING AND PERFORMING THE MANUFACTURER’S INSTALLATION CHECKLIST SHOULD INSTALL THIS... - Page 3 BlueStar® rangetops are designed for discerning home chefs who demand restaurant-quality results in their own kitchens. As the owner of a new BlueStar® rangetop you can look forward to years of culinary excellence. You will prepare meals with the speed and accuracy of a professional chef right in your own kitchen.
-
Page 4: Service Information
SERVICE INFORMATION Date of Purchase Model Number Serial Number Dealer Name Dealer Phone Dealer Address Date of Installation Installer Name Installer Phone Installer Address Our service team can be reached at 1-800-449-8691 or serviceteam@bluestarcooking.com. Please take a few moments now to fill in the Service Information above for your future reference. In the event you require parts or service, this information will be needed to ensure you receive the highest quality service we can provide. -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS Read all instructions before using your appliance. Follow these important safety precautions to reduce the risk of fire, electric shock, personal injury or property damage. Do not remove permanent labels, warnings or data plates or the serial number from your appliance. Removal may void the manufacturer’s warranty and/or hinder effective servicing and maintenance. -
Page 6: General Safety Instructions
ENERAL AFETY NSTRUCTIONS SAVE THESE INSTRUCTIONS WARNING Your appliance should be installed by a qualified gas installation technician. Have the technician show you the exact location of the gas shutoff valve on the incoming gas line so you know how to turn off the gas if necessary. ... - Page 7 WARNING OOKTOP AFETY NSTRUCTIONS The push-in and turn control knobs on this appliance are designed to be child-safe, however are not a guarantee of safe operation. Do not leave children alone or unattended in the kitchen while the appliance is in use. ...
-
Page 8: Getting Started
GETTING STARTED ® We know you are excited to start cooking with your new BlueStar rangetop. Before you begin, it is essential that you follow these steps for safe and optimal use. Become familiar with all the parts of your rangetop. -
Page 9: Before You Begin
If a burner is replaced in the wrong position it may not function correctly. Become familiar with the location of your burners. Below are the standard burner configurations. RNB Models – 24”, 30”, 36”, 48”, 60” Platinum™ Series Models – 48”, 60”... -
Page 10: Burner Operation
URNER PERATION Push in and turn the control knob counter clockwise to HIGH to start the ignition process. The igniter will spark and make a clicking sound. The clicking will stop after the burner ignites. The initial ignition process may take a few seconds. You may hear multiple clicks before it ignites. -
Page 11: Burner Cleaning
URNER CLEANING Ring Grates and Top Grates TIP: Clean spills as soon as possible to prevent sticking and build up. When burner is cool, remove the ring grate, top grate and center filler grate (30” models only). Wash in hot, soapy water. Rinse well and dry thoroughly to prevent rusting. ... - Page 12 OOKING Every burner is wok fitted and can be used for wok cooking without a separate wok ring. TIP: For best results, use your rangetop’s highest BTU rated burner for stir-frying, which are located in the front of the rangetop. ...
- Page 13 NTEGRATED RIDDLE SOME MODELS Before You Begin You must season your integrated griddle before using. The seasoning process prevents food from sticking and the griddle from rusting. After seasoning, with time and use, your griddle will darken and develop a rich blue/black color, which is normal. If you purchased a cast iron griddle separately, do NOT follow the seasoning directions.
- Page 14 Integrated Griddle Cleaning Allow griddle to cool to room temperature. Scrape off excess food with a spatula and wipe off used cooking oil. For heavy soiling, use a nylon pad coated with a thin layer of cooking oil. ...
- Page 15 HARBROILER SOME MODELS Before You Begin Your charbroiler grate is reversible. One side has narrow slats for use with delicate foods like fish and some vegetables. The other side has wider slats for use with larger foods items like steak and chicken. Before igniting the burner, decide which side is best for the dish you are preparing and place that side face up.
-
Page 16: French Top
RENCH SOME MODELS Before You Begin You must season your French Top surface before use. The seasoning process prevents the surface from rusting. After seasoning, with time and use, your French Top surface will darken and develop a rich patina color which is normal. Seasoning your French Top Surface ATTENTION The complete seasoning process takes approximately 60 minutes and requires attention. - Page 17 French Top Cleaning Allow the French Top to cool to room temperature. After every use, apply a light coating of corn oil or high smoke point oil. Wipe off excess using a dry cotton towel. Never flood a hot French Top ring or surface with cold water. This may cause the French Top’s steel plates to crack or warp, and will void your warranty.
-
Page 18: Raised Griddle / Broiler
– 12” 24” (H AISED RIDDLE ROILER ERITAGE LASSIC ODELS Before You Begin You must season your steel cooktop griddle plate before using. The seasoning process prevents food from sticking and the griddle plate from rusting. After seasoning, with time and use, your griddle plate will darken and develop a rich dark blue/black color which is normal. - Page 19 Griddle: Push in and turn the Raised Griddle/Broiler control knob counter clockwise to HIGH. The spark igniter will click and the burner will light. 24” Model – There are two control knobs that operate the left and right side of the griddle that can be operated independently or at the same time.
-
Page 20: Operation
™ S NTERCHANGEABLE RIDDLE HARBROILER YSTEM LATINUM ERIES ONLY The Platinum™ Series Griddle/Charbroiler system allows for two-zone cooking, with up to 40,000 BTUs of heat. The cast iron, interchangeable, griddle charbroiler system lets you use the griddle or charbroiler anywhere on the rangetop. Visit bluestarcooking.com to see the system in action. -
Page 21: Care And Cleaning
Remove from rangetop. Discard grease and Grease Pan wash in hot soapy water. Apply stainless steel Insert (RNB, cleaner as needed with a rag, following Do NOT use abrasive sponges Heritage, and cleaner manufacturer’s instructions. As needed Platinum™... - Page 22 Do NOT use steel wool, metal pads or abrasive cleaners. Only moving in the direction of the grain, clean with hot, soapy water. Rinse well and Do NOT use any metal objects Exterior Body / dry thoroughly. to scrape the surface. Stainless Steel As needed For tough stains, use a commercial stainless...
-
Page 23: Before Calling For Service
BEFORE CALLING FOR SERVICE ® Check these helpful tips for any problems with your rangetop. If you need additional help call BlueStar Customer Service at 1-800- 449-8691. COOKTOP PROBLEM POSSIBLE CAUSE SOLUTION Plug into a three-prong electrical outlet that is properly grounded. -
Page 24: Maintenance
MAINTENANCE Air Shutters Air shutter adjustments are pre-set at the factory. However depending on a variety of factors including the type of gas supply, these adjustments may need to be fine-tuned after installation. A qualified installer should make these adjustments at the time of installation. Any air shutter adjustments that are needed after installation are not covered by your warranty. - Page 25 URNER LAME DJUSTMENT At its lowest setting, a properly adjusted burner will produce a steady flame about 1/8” above the burner ports. If your flames do not appear, follow the instructions to adjust the flame height. ATTENTION Before you begin, follow the steps in the Air Shutter Checklist. Push and turn the burner fully counterclockwise to the lowest simmer setting.
-
Page 26: Igniter Replacement
GNITER EPLACEMENT For a front burner, remove the ring grate and top grate from the burner that needs the replacement igniter. For a rear burner, remove the ring grates and top grates from both the front and rear burners. Within the burner cavity, locate and disconnect the orange lead wire by pulling on the plastic connector. Remove the burner assembly and attached venturi tube from the burner cavity by pulling it up and towards the back of the rangetop until it is free. -
Page 27: Limited Warranty
LIMITED WARRANTY BlueStar® Cooking Appliances, BlueStar® Ventilation Hoods and Prizer Hoods® Ventilation Hoods Damage or repairs caused by the use of harsh chemicals or Who Is Providing The Warranty? This Warranty is provided to you by Prizer-Painter Stove Works, Inc. - Page 28 Prizer-Painter must be made within the seven (7) day warranty period or they are void. To obtain Warranty service, where applicable, the Owner must call the factory (toll free: 1-800-449-8691) to report a warranty claim, ．Floor Models Not Used For Demonstration: Floor models are and must, at that time, provide (1) the model number of the Product, (2) the serial number of the Product, (3) proof of delivery, covered by a one (1) year limited functional parts and related...
- Page 29 ARBITRATION CLAUSE. IMPORTANT. PLEASE REVIEW THIS ARBITRATION CLAUSE. IT AFFECTS YOUR LEGAL RIGHTS. 1. Parties: This arbitration clause affects your rights against Prizer- 8. Rules of the Arbitration: If the amount in controversy is less Painter Stove Works, Inc. and any of its affiliates or employees or than $50,000, the arbitration will be decided by a single arbitrator.
-
Page 30: Performance Checklist
PERFORMANCE CHECKLIST This checklist has been developed to assure proper installation of your appliance. To validate your warranty you must mail or fax this form within 15 days of installation and a copy of your receipt to: Warranty Department, Prizer-Painter Stove Works Inc., 600 Arlington Street, Reading, PA 19611, or Fax (610) 376-2596.
