SPECIFICATIONS
Working Environment
Power Source
Internal Battery
Battery Life
UHF Transmitter
Frequency
Modulation
Range
RF Passive Tag
Frequency
Range
Status Indicators
Power LED
Push-buttons
I
MPRO
ImproX (QT) Quad Transmitter
INSTRUCTIONS FOR USE
: Designed to work in an indoor or outdoor
environment similar to IP55. The ImproX QT is,
therefore, sealed against water.
: 3.0 V, 220 mAh, CR2032 lithium coin cell.
: Up to 2 years, at 10 operations per day, at
+25°C (+77°F).
: 433.92 MHz.
: ASK.
: Up to 20 to 50 m (22 to 55 yd) (line of sight),
when used with the ImproX RF 4-Channel UHF
Receiver (UHR903-0-1-GB-XX).
: 125 kHz.
: 25 to 50 mm (1 to 2 in).
: A steady Red LED. Switches ON during the
time that any one of the Push-buttons is
pressed.
: Four ribbed Push-buttons.
Blank Space
MODEL NUMBER: XQT904-1-1-GB-XX
X QT
Advertisement
Summary of Contents for impro IMPROX QT XQT904-1-1-GB
-
Page 1: Specifications
MODEL NUMBER: XQT904-1-1-GB-XX X QT MPRO ImproX (QT) Quad Transmitter INSTRUCTIONS FOR USE SPECIFICATIONS Working Environment : Designed to work in an indoor or outdoor environment similar to IP55. The ImproX QT is, therefore, sealed against water. Power Source : 3.0 V, 220 mAh, CR2032 lithium coin cell. Internal Battery : Up to 2 years, at 10 operations per day, at Battery Life... -
Page 2: User Information
USER INFORMATION Accessories Find the following when unpacking the Transmitter: An ImproX Quad Transmitter housed in an opaque Dark Blue, Polycarbonate Plastic housing. The Transmitters housing consists of a Lid and Base, secured with 3 Self-tapping Screws (M2 x 6 mm). A 3 V CR2032 lithium coin cell Battery (installed in the Transmitter). - Page 3 Procedure to Confirm the Current Mode Press and hold down Push-buttons 2 and 4 at the same time until the LED flashes, release the Push-buttons. After three seconds the Red Power LED indicates the Mode: In “Dynamic Code Transmission Mode” the LED flashes rapidly. In “Standard Mode”...
- Page 4 A Serial Number Label is stuck to the Base of each ImproX Quad Transmitter; keep this label in a safe place for warranty purposes. GUARANTEE OR WARRANTY This product conforms to our Guarantee or Warranty details placed on our Web Site, to read further please go to www.impro.net. XQT300-0-0-GB-06 June 2007 Page 4...
-
Page 5: User Notes
USER NOTES XQT300-0-0-GB-06 June 2007 Page 5... - Page 6 USER NOTES XQT300-0-0-GB-06 June 2007 Page 6...
- Page 7 USER NOTES XQT300-0-0-GB-06 June 2007 Page 7...
- Page 8 This manual is applicable to the ImproX (QT) Quad Transmitter, XQT904-1-1-GB-00. (The last two digits of the Impro stock code indicate the issue status of the product). ImproX QT\English Manuals\ XQT300-0-0-GB-06 Issue 07 Jun 2007 LATEST ISSUE\ImprXQT-ifu-en-07.docx XQT300-0-0-GB-06 June 2007...
